Cradlepoint 90W PoE Injector, 56V, 802.3bt, 2.5 GbE (170827-000)

MPN 170827-000
  • 46–100 W

Made for Cradlepoint

$237.90$259.99Save $22.09

In stock · only 1 leftFree 2-day shipping

1
Request a quote · volume, multi-site or with plans

Overview

The Cradlepoint PoE Injector 170827-000 is a single-port 802.3bt injector that delivers 56 V nominal output and 90 W total output power. It passes Ethernet data at 2.5 Gbps. It is built to power Cradlepoint W1850, W2005 and W4005 wideband adapters and the CBA850 Series LTE Adapter over one cable run. A C13 line cord is required and sold separately in regional versions.

  • Single-port 802.3bt PoE injector with 90 W total output power
  • 56 V nominal output (54 V minimum, 57 V maximum)
  • 2.5 Gbps Ethernet data speed
  • Load range of 15 mA minimum to 1.6 A maximum
  • Operating temperature of -20 °C to +40 °C
  • Compatible with W1850, W2005, W4005 and CBA850 Series LTE Adapter
  • C13 line cord required and sold separately
  • Power and connect a remotely mounted wideband adapter over one Ethernet cable

The Cradlepoint PoE Injector, part number 170827-000, is the high-power injector specified for Cradlepoint's wideband adapters. It carries both power and data to a remotely mounted unit over a single Ethernet cable. This means a W1850, W2005 or W4005 wideband adapter, or a CBA850 Series LTE Adapter, can be installed on a roof, wall or window where signal is strongest, with no separate power run. Cradlepoint also lists it as an injector option in the AP2600 data sheet.

The injector is a single-port 802.3bt design with 90 W total output power and 2.5 Gbps Ethernet data speed. That throughput suits multi-gigabit cellular links. Output voltage is 56 V nominal, and voltage accuracy including line and load regulation stays within 54 V minimum and 57 V maximum. Load range is 15 mA minimum to 1.6 A maximum, and ripple and noise are rated at 250 mVp-p. The unit operates from -20 °C to +40 °C, tolerates -20 °C to +65 °C in storage, and handles 5 to 90% humidity.

The package contains the PoE injector only, and no line cord is included. Order the C13 line cord for your region: North America Type A (170671-001), EU Type F (170671-002), UK Type G (170671-003) or AU Type I (170671-004). The injector is listed for North America, Europe and Asia-Pacific.

Ideal for

  • Powering a roof- or wall-mounted W4005, W2005 or W1850 wideband adapter over one Ethernet run
  • Supplying power and data to a CBA850 Series LTE Adapter installed away from the router
  • Multi-gigabit cellular WAN installs that need a 2.5 Gbps PoE link
  • Standardizing injector hardware across North American, European and Asia-Pacific sites

Specifications

General

MPN
170827-000
Brand
Cradlepoint
Ports
Single port
Standard
IEEE 802.3bt
Product Name
PoE Injector, 56 V
Product Status
Active
Accessory Family
Adapters & Cables
Country OF Origin
China

Network

Ethernet Data Speed
2.5 Gbps

Package

Contents
PoE injector only, no line cord

Electrical

Maximum Load
1.6 A
Minimum Load
15 mA
Voltage Maximum
57 V
Voltage Minimum
54 V
Voltage Nominal
56 V
Ripple And Noise
250 mVp-p
Total Output Power
90 W
Voltage Accuracy Note
Voltage accuracy includes line/load regulation

Line Cords

AU Type I
170671-004
EU Type F
170671-002
UK Type G
170671-003
Line Cord Included
No line cord included (C13 line cord required)
North America Type A
170671-001

Compatibility

Regions
North America, Europe, Asia-Pacific
Also Listed IN
Listed as an injector option in the AP2600 data sheet
Compatible Products
Cradlepoint W4005, W1850, W2005, CBA850 Series LTE Adapter

Environmental

Humidity
5 to 90%
Operating Temperature
-20 °C to +40 °C
Non Operating Temperature
-20 °C to +65 °C

Questions buyers ask

Is a power cord included with the 170827-000?

No. The package contains the PoE injector only. A C13 line cord is required: 170671-001 (North America Type A), 170671-002 (EU Type F), 170671-003 (UK Type G) or 170671-004 (AU Type I).

Which Cradlepoint products does this injector power?

Cradlepoint lists it as compatible with the W4005, W1850 and W2005 wideband adapters and the CBA850 Series LTE Adapter. It is also listed as an injector option in the AP2600 data sheet.

What data speed does the injector support?

It supports an Ethernet data speed of 2.5 Gbps on its single port.

What are the output voltage and power ratings?

The output is 56 V nominal, with 54 V minimum and 57 V maximum including line and load regulation. Total output power is 90 W and the load range is 15 mA to 1.6 A.

Can it be installed outdoors in cold conditions?

The operating range is -20 °C to +40 °C with 5 to 90% humidity. Non-operating storage is rated from -20 °C to +65 °C.
