Compulocks Galaxy Tab A8 10.5-Inch Space Enclosure Wall Mount with PlusHub - Black

MPN 201M105GA8SBH01
  • Wall

Fits Galaxy Tab A8

$213.81$239.00Save $25.19

In stockFree 2-day shipping

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

This Compulocks bundle (201M105GA8SBH01) turns a Samsung Galaxy Tab A8 10.5-inch (2022, SM-X200/SM-X205) into a secure, wall-mounted workstation. It combines the black Space enclosure (105GA8SB), the 201M Wall Mount Bracket with Security Slot and the H01 PlusHub VESA Box. The hub adds six ports: USB-C PD input up to 90 W, USB-C, HDMI with 3840 x 2160 at 30 Hz, USB-A 3.0, USB-A 2.0 and 100 Mbps Ethernet. Staff can connect displays, printers, scanners and wired networking to the tablet.

  • Space enclosure for Galaxy Tab A8 10.5-inch (2022, SM-X200, SM-X205)
  • 201M Wall Mount Bracket with security slot for standard T-Bar lock designs
  • H01 PlusHub with six ports: USB-C PD, USB-C, HDMI, 2x USB-A, RJ45
  • HDMI output up to 3840 x 2160 at 30 Hz; USB-A 3.0 at 5 Gbps
  • USB-C PD 2.0 power input up to 90 W; 100 Mbps Ethernet
  • Mounts on the 100 x 100 VESA standard, with a 1000 mm hub cable routed inside the box
  • Turns a Galaxy Tab A8 into a wall-mounted check-in, ordering or information station
  • Wired Ethernet provides a stable network connection for fixed deployments

The Compulocks Galaxy Tab A8 Space Enclosure Wall Mount with PlusHub is built for businesses that want a fixed Galaxy Tab A8 10.5-inch kiosk or workstation with wired peripherals. The bundle has three parts. The Space enclosure (105GA8SB) is shaped for the 2022 Galaxy Tab A8, models SM-X200 and SM-X205. The 201M Wall Mount Bracket carries a security slot compatible with standard T-Bar lock designs. The H01 PlusHub VESA Box sits behind the enclosure on the 100 x 100 VESA pattern.

The PlusHub expands the tablet's single USB-C connection into six ports. The USB-C PD 2.0 input accepts up to 90 W and is for charging in only. A USB-C 2.0 port provides charging out only. HDMI drives displays at up to 3840 x 2160 at 30 Hz and is downward compatible. The hub also has one USB-A 3.0 port at 5 Gbps, one USB-A 2.0 port at 480 Mbps and RJ45 Ethernet at 100 Mbps. Ports support hot-swap. With PD power connected, the two USB-A ports share 1.9 A combined, a single USB-A port supplies 1.5 A and the USB-C port supplies 0.5 A. The hub cable is 1000 mm long, with 300 mm out of the box. The hub has ventilation holes and a built-in lock slot.

The listed weights are 1.60 lb for the enclosure, 0.13 lb for the bracket and 0.60 lb for the hub. Compulocks product sheets for each component and installation instructions are available.

Ideal for

  • Wall-mounted patient or guest check-in stations
  • Retail endless-aisle and product lookup kiosks
  • Conference room and meeting-space booking panels
  • Front-desk workstations with printer and scanner peripherals
  • Digital signage driven from a Galaxy Tab A8 with an external display

Specifications

General

MPN
201M105GA8SBH01
UPC
819472029330
Brand
Compulocks
Colour
Black
Shipping Weight
2.40 lb
Enclosure Family
Space
Bundle Components
201M Wall Mount Bracket + 105GA8SB Space Enclosure + H01 PlusHub VESA Box

Package

Documentation
Product sheets and installation instructions

Plushub H01

Sku
H01
UPC
819472028630
Hdmi
3840 x 2160 at 30 Hz, downward compatible
Name
PlusHub VESA Box
Ports
USB-C PD, USB-C, HDMI, 2x USB-A, RJ45
USB C
USB-C 2.0, charging out only
Colour
Black
Version
H
Ethernet
RJ45, 100 Mbps
Hot Swap
Supported
Mounting
100 x 100 VESA
PD Input
PD 2.0, 90 W max, charging in only
USB A 2 0
USB-A 2.0, 480 Mbps
USB A 3 0
USB-A 3.0, 5 Gbps
Cable Length
1000 mm total; 300 mm out of the box, 700 mm inside
Weight Listed
0.60 lb (compulocks.com)
Host Connection
Supports USB-C in / HDMI out
Weight Product Sheet
0.41 lb (product sheet)
Output Single USB A With PD
1.5 A (with PD charging in)
Output Single USB C With PD
0.5 A (with PD charging in)
Output 2x USB A Combined With PD
1.9 A combined (with PD charging in)

Wall Mount 201m

Sku
201M
UPC
819472023147
Name
Wall Mount Bracket with Security Slot
Colour
Black
Weight
0.13 lb
Compatibility
Universal; compatible with standard T-Bar design lock slots

Enclosure 105ga8sb

Sku
105GA8SB
UPC
819472024267
Name
Galaxy Tab A8 10.5-inch Space Enclosure - Black
Colour
Black
Weight
1.60 lb
Compatible Devices
Samsung Galaxy Tab A8 10.5-inch (2022) SM-X200, SM-X205

Questions buyers ask

Which Galaxy Tab models fit this enclosure?

The Space enclosure in this bundle fits the Galaxy Tab A8 10.5-inch (2022), models SM-X200 and SM-X205.

What ports does the PlusHub provide?

It has six ports: USB-C PD 2.0 input (up to 90 W, charging in only), USB-C 2.0 (charging out only), HDMI up to 3840 x 2160 at 30 Hz, USB-A 3.0 (5 Gbps), USB-A 2.0 (480 Mbps) and RJ45 Ethernet (100 Mbps).

How much power can accessories draw from the hub?

With PD power connected, the two USB-A ports share 1.9 A combined, a single USB-A port supplies 1.5 A and the USB-C port supplies 0.5 A.

How is it installed on the wall?

The 201M bracket is installed with screws and wall anchors, which are not included. The PlusHub attaches using the 100 x 100 VESA standard. Installation instructions are available.

What warranty does Compulocks provide?

Compulocks states that its products come with a 2-year manufacturer's warranty.
