Socket Mobile DuraSled DS860 1D/2D/MRZ Barcode Sled Scanner for iPhone 17e/16e, Black, Sled Only

MPN CX4399-3539

Fits iPhone 16e

$542.98

In stock · only 5 leftShips from the US

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Socket Mobile DuraSled DS860 (CX4399-3539) is the sled-only configuration of Socket Mobile's professional scanner for iPhone 17e and iPhone 16e, in black. It reads 1D and 2D barcodes, passport MRZ lines, and OCR-A/B and MICR E13B fonts. A rubber casing protects the phone from drops. It is a good fit for adding units to a fleet that already uses DuraSled docks or 6-bay chargers, or for single-user deployments charged by cable.

  • Sled-only DS860 configuration for iPhone 17e and iPhone 16e, in black
  • Reads 1D and 2D barcodes plus passport MRZ, OCR-A/B and MICR E13B fonts, and DotCode
  • Decode range of 4.1 to 91.7 cm on a 1280 x 960 pixel imager
  • Rubber casing rated for 2,500 tumbles at 1 m onto a metal plate
  • Field-replaceable 700 mAh battery rated for 10,000 scans within 11 hours
  • Class 2 Bluetooth 2.1 + EDR, native in Square and Shopify, CaptureSDK 2.0.29 or higher
  • Lowest-cost way to add DS860 units to a fleet that already charges on DuraSled docks or 6-bay chargers
  • Scan merchandise and verify passports on one one-handed iPhone device

The DuraSled DS860 for Apple is Socket Mobile's professional sled scanner for reading barcodes and travel documents from an iPhone. CX4399-3539 is the black Sled Scanner Only configuration for iPhone 17e and iPhone 16e, with no charging dock. It suits teams that already run DuraSled charging infrastructure, or users who charge by cable. The manufacturer's cable package lists the data reader, wrist strap, charging cable and Get Started Guide. The iPhone and power adapter are not included.

The DS860 reads the full 1D and 2D symbology set plus OCR-A and OCR-B by default. It also supports MICR E13B, passport MRZ, postal codes and DotCode. Its 1280 x 960 pixel imager decodes from 4.1 to 91.7 cm depending on barcode size and media. For example, 20 mil Code 39 reads to 91.7 cm, 15 mil Code 128 to 70.6 cm and 20 mil QR to 44.5 cm. It reads printed and on-screen codes omnidirectionally in light from 0 to 100,000 lux.

The rubber sled is rated for 2,500 tumbles at 1 m onto a metal plate and operates from 0 to 45 °C. The field-replaceable 700 mAh lithium-polymer battery delivers 10,000 scans within 11 hours at one scan every 4 seconds, with 25 hours of standby, and charges in 8 hours.

The scanner pairs over Class 2 Bluetooth 2.1 + EDR with a range of up to 10 m. It supports HID, SPP and the default iOS Application Mode. Square and Shopify support it natively, and CaptureSDK 2.0.29 or higher integrates it into native and web apps. DuraSled core components and charging infrastructure stay the same across iPhone models. The DS860 is designed and assembled in Fremont, CA, and includes a 1-year warranty.

Ideal for

  • Expanding an existing DuraSled fleet that already charges on docks or 6-bay chargers
  • Travel, hotel and hospitality check-in with passport MRZ reading
  • Retail point of sale on iPhone with Square or Shopify
  • Field service, mobile delivery and track-and-trace scanning
  • Inspections, audits and healthcare workflows needing durable iPhone scanning

Specifications

General

MPN
CX4399-3539
UPC
758497125514
Fits
iPhone 17e / iPhone 16e
Brand
Socket Mobile
Color
Black
Model
DuraSled DS860 for Apple
Reads
1D Barcodes, 2D Barcodes, MRZ OCR Fonts, Postal Codes
Assembly
Designed and assembled in the USA (Fremont, CA)
Warranty
1-year warranty included (extended options available)
Highlights
Drop Protection | Passport Reader | Scans on Screen
Product Type
Durable Professional 1D/2D/MRZ Barcode Sled Scanner
Configuration
DS860 (Black), iPhone 17e/16e, Sled Scanner Only

Packaging

Not Included
iPhone not included; adapter sold separately
Data Reader With 6 Bay Charger
Data Reader, Wrist Strap, 6 Bay Charger, Get Started Guide
Data Reader With Charging Dock
Data Reader, Wrist Strap, Charging Dock, Get Started Guide
Data Reader With Charging Cable
Data Reader, Wrist Strap, Charging Cable, Get Started Guide

Dimensions

Shipping Weight
0.60 lbs
USB Cable Length
USB 2.0 cable, 1.2 m
USB Cable Weight
~2.72 oz (77.1 g)
Charging Dock Size
7.33 x 1.12 x 3.23 in (186.2 x 28.4 x 82.0 mm)
Charging Dock Weight
~16.9 oz (478.5 g) (dock sold separately with this SKU)
Durasled Iphone 15 Size
L 5.77 x H 2.82 x W 0.31 in (147.6 x 71.6 x 7.8 mm)
Durasled Iphone 16e Size
L 5.77 x H 2.82 x W 0.31 in (147.6 x 71.6 x 7.8 mm)
Durasled Iphone 15 Weight
~4.2 oz (113.5 g)
Durasled Iphone 16e Weight
~4.2 oz (113.5 g)

Compatibility

Sdk
Socket Mobile CaptureSDK version 2.0.29 or higher
Native Support
Square, Shopify
Compatible With
Apple iOS, Bluetooth Classic

Operating Systems

Supported
Apple iOS

User Environments

Ambient Light
0 to 100,000 lux (pitch black to direct sunlight)
Relative Humidity
95% at 60 °C (140 °F), non-condensing
Storage Temperature
-40° to 70 °C (-40° to 158 °F)
Charging Temperature
Charging above 40 °C / 100 °F ambient may result in charging issues
Tumble Specification
2,500 cycles at 3.3 ft (1 m) to a metal plate, IEC6008-2-31, IEC60068-2-32
Operating Temperature
0° to 45 °C (32° to 113 °F)

Battery Information

Voltage
3.7 V
Capacity
700 mAh
Cell Type
Proprietary
Charge Time
8 hours
Battery Type
1 rechargeable lithium-ion polymer, replaceable
Battery Weight
12.5 g
Commodity Code
8507.60.0000
Life Per Charge
Standby: 25 hours; Active: 10,000 scans within 11 hours (one scan every 4 seconds); varies with temperature, light and battery age
Lithium Content
4.5 g
Rohs Compliance
Yes, included with scanner
Hazmat UN Number
UN3481, P.I. 967
Cells Per Battery
1
Country OF Origin
China (battery)
Watts Per Battery
2.59
Battery Cycle Life
500 charge-discharge cycles
Percentage Lithium
36.3%
Chemical Composition
Lithium-polymer

Reading Performance

Scan Angle
44.5° (horizontal) x 33.5° (vertical)
Decode Range
4.1 to 91.7 cm (1.6 to 35.1 in), depends on barcode size, symbology, label media
Print Contrast
Down to 25%-20%
Sensor Resolution
1280 horizontal x 960 vertical pixels
Decode 5 Mil Pdf417
Near 3.0 in / 7.6 cm, Far 7.9 in / 20.1 cm
Decode 3 Mil Code 39
Near 3.0 in / 5.8 cm, Far 7.6 in / 14.7 cm
Default Ocr Typeface
OCR (default): OCR-A, OCR-B
Decode 20 Mil Code 39
Near 1.6 in / 4.1 cm, Far 36.1 in / 91.7 cm
Decode 20 Mil QR Code
Near 1.1 in / 2.8 cm, Far 17.5 in / 44.5 cm
Decode 5 Mil Code 128
Near 2.3 in / 5.8 cm, Far 9.8 in / 24.9 cm
Decode 15 Mil Code 128
Near 2.4 in / 6.1 cm, Far 27.8 in / 70.6 cm
Decode 6 67 Mil Pdf417
Near 2.5 in / 6.3 cm, Far 10.1 in / 25.7 cm
Default Symbologies 1d
1D (default): Bookland EAN, Codabar, Code 128, Code 39, Code 93, EAN/JAN 13, EAN/JAN 8, GS1-128, GS1 DataBar Expanded, Limited and Omnidirectional, Interleaved 2 of 5, ISBT 128 UDI, Trioptic, UPC-A, UPC-E
Default Symbologies 2d
2D (default): Aztec, Composite, Data Matrix, Han Xin, MaxiCode, MicroPDF417, Micro QR, PDF417, QR
Supported Ocr Typeface
OCR (supported): MICR E13B
Supported Postal Codes
Australia Post, Japan Postal, Mailmark, Netherlands KIX, UK Postal, US Planet, US Postnet, USPS 4CB / Intelligent Mail
Decode 100 Percent UPC A
Near 1.6 in / 4.1 cm, Far 24.9 in / 63.2 cm
Decode 10 Mil Datamatrix
Near 2.1 in / 5.3 cm, Far 11.0 in / 27.8 cm
Supported Symbologies 1d
1D (supported): Code 11, Matrix 2 of 5, MSI

Bluetooth Information

Bluetooth Radio
Class 2 Bluetooth, version 2.1 + EDR with 56-bit data encryption
Bluetooth Range
Up to 10 m (33 ft), depending on environment and host device
Bluetooth Profiles
Basic Mode: HID; Application Mode: SPP; iOS Application Mode (default). Some OS or device models may support only one profile

Certification Regulatory

Emi Rfi
FCC Part 15 Class C, RSS 210, ICES 003, C-Tick, CISPR 22, CE EN55022, EN55024
LED Safety
IEC/EN 62471 (Exempt Group); FCC ID: LUBMA41; IC ID: 2529A-MA41S8; Telec ID: R 201-125709
Environmental
RoHS compliant
Electrical Safety
Certified to IEC 60950-1; UL 60950-1; CAN/CSA C22.2

Questions buyers ask

Does CX4399-3539 include a charging dock?

No. This is the Sled Scanner Only configuration. The manufacturer's cable package lists the data reader, wrist strap, charging cable and Get Started Guide. The dock version is CX4394-3534.

Which iPhones does it fit?

This sled fits the iPhone 17e and iPhone 16e. Socket Mobile offers a separate DS860 sled for iPhone 16/15.

Can it read passports and ID documents?

Yes. The DS860 reads passport MRZ lines plus OCR-A, OCR-B and MICR E13B fonts, alongside standard 1D and 2D barcodes.

Can I charge it in an existing DuraSled dock or 6-bay charger?

Yes. Socket Mobile keeps DuraSled charging infrastructure the same across models, and its 6-bay charger charges up to six DuraSleds and DuraScan 800 Series scanners at once.

What documentation is available?

Socket Mobile publishes a DS860 datasheet, a DuraSled user guide, a programming guide, a battery replacement guide and a Get Started Guide for this scanner.
