Socket Mobile DuraScan Terminal DT841 Bluetooth LE 1D/2D Barcode Scanner for iPhone 17e and 16e

MPN CX4678-3959

Fits iPhone 16e

$345.83$449.00Save $103.17

Backordered · ships as soon as it arrives

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Socket Mobile DuraScan Terminal DT841 (CX4678-3959) turns an iPhone 17e or iPhone 16e into a one-handed 1D/2D barcode scanner. A rubberized, IP54-rated housing protects the phone from drops. The camera, touchscreen and USB-C charging stay fully accessible. An omnidirectional engine reads printed and on-screen barcodes from 0.6 to 20 inches, and a Bluetooth LE link sends the data to apps built with Socket Mobile CaptureSDK. This SKU is the data reader only; no iPhone is included.

  • Omnidirectional 1D/2D scanning of printed and on-screen barcodes
  • Reads 5 mil to 15 mil barcodes at 0.6 to 20 inches with a high-visibility aimer
  • Rubberized, IP54-rated housing for iPhone 17e, also compatible with iPhone 16e
  • Full access to the iPhone camera and touchscreen, plus USB-C passthrough charging
  • Bluetooth LE connection to apps built with CaptureSDK 2.0.29 or higher
  • Rechargeable, field-replaceable battery rated for a full shift
  • LED status indicators and audible feedback tones
  • One-handed scanning: the phone and scanner work as a single handheld device

The DuraScan Terminal DT841 is a slim, durable scanning terminal for mobile teams that run their workflows on iPhone. It is designed for the iPhone 17e and is also compatible with the iPhone 16e. The phone sits inside a ruggedized, rubberized housing that absorbs impact from drops and daily handling. The native camera, touchscreen and USB-C charging remain fully usable without removing the phone. USB-C passthrough keeps the iPhone powered while it is docked.

The scan engine is omnidirectional and reads 1D and 2D barcodes on printed labels and screens. It reads barcode sizes from 5 mil to 15 mil at distances of 0.6 to 20 inches, and a high-visibility aimer helps with targeting. Advanced decoding handles scratched, damaged, smudged and low-contrast codes, down to 25%-20% print contrast. The 1280 x 960 pixel sensor supports Code 128, UPC-A/E, EAN, GS1 DataBar, QR, Data Matrix, PDF417, Aztec, MaxiCode and more. LED indicators and multiple audible tones confirm each read.

The DT841 connects over Bluetooth Low Energy, which is separate from Socket Mobile's Bluetooth Classic readers. It runs in Application Mode and requires an app built with Socket Mobile CaptureSDK version 2.0.29 or higher. Apps that already integrate CaptureSDK work with it out of the box. Its rechargeable, field-replaceable battery is rated for a full shift.

The terminal is designed and assembled at Socket Mobile's headquarters in Fremont, California, and ships with a 1-year warranty. Socket Mobile also sells this model with a factory-new 256GB iPhone 17e pre-installed under MPN HC2133-3961. This SKU, CX4678-3959, is the data reader only.

Ideal for

  • Delivery drivers capturing proof of delivery and parcel scans
  • Ticketing and event entry, including on-screen QR codes
  • Asset tracking, track and trace, inspections and audits
  • Retail, hospitality and healthcare workflows on iPhone
  • Field service and food handling data capture

Specifications

General

MPN
CX4678-3959
UPC
758497129741
Brand
Socket Mobile
Model
DuraScan Terminal DT841
Reads
1D and 2D barcodes
Highlights
All-in-One-Hand usage, BYOD, IP54 Rating
Configuration
Data reader only, iPhone not included
Shipping Weight
1.70 lbs

Physical

Battery
Rechargeable, field-replaceable, rated for a full shift
Housing
Rubberized protective housing
Charging
USB-C passthrough charging for the iPhone
Ingress Protection
IP54

Bluetooth

Bluetooth Radio
Bluetooth LE
Bluetooth Range
Up to 10 m (33 ft.), depending on environment and host device
Bluetooth Profiles
Application Mode, requires a compatible app with Socket Mobile CaptureSDK

Compatibility

Sdk Requirement
Requires an app built with CaptureSDK 2.0.29 or higher
Compatible Devices
iPhone 17e (also compatible with iPhone 16e)
Supported Operating Systems
Apple iOS

Reading Performance

Scan Angle
44.5° horizontal, 33.5° vertical
Print Contrast
Down to 25%-20%
Reading Distance
2.8 to 91.7 cm (1.1 to 36.1 in.), depends on barcode size, symbology and label media
Sensor Resolution
1280 horizontal x 960 vertical pixels
Barcode Size Range
5 to 15 mil
Reading Distance 15 Mil QR
0.59 to 11.06 in (1.5 to 28.1 cm)
Default Barcode Symbologies
1D: Bookland EAN, Codabar, Code 128, Code 39, Code 93, EAN/JAN-13, EAN/JAN-8, GS1-128, GS1 DataBar Expanded/Limited/Omnidirectional, Interleaved 2 of 5, ISBT 128 UDI, Trioptic, UPC-A, UPC-E; 2D: Aztec, Composite, Data Matrix, Han Xin, MaxiCode, MicroPDF417, Micro QR, PDF417, QR
Reading Distance 13 Mil UPC A
1.50 to 20.04 in (3.8 to 50.9 cm)
Supported Barcode Symbologies
1D: Chinese 2 of 5, Code 11, Matrix 2 of 5, MSI; Postal: Australia Post, Japan Postal, Mailmark, Netherlands KIX, US Planet, US Postnet, USPS 4CB/Intelligent Mail
Reading Distance 5 Mil Code 39
1.10 to 6.54 in (2.8 to 16.6 cm)
Reading Distance 6 67 Mil Pdf417
0.91 to 7.05 in (2.3 to 17.9 cm)
Reading Distance 10 Mil Datamatrix
1.22 to 7.48 in (3.1 to 19.0 cm)

Questions buyers ask

Which iPhone models does the DT841 fit?

It is designed for the iPhone 17e and is also compatible with the iPhone 16e.

Is an iPhone included?

No. CX4678-3959 is the data reader only. Socket Mobile offers a version with a factory-new 256GB iPhone 17e pre-installed under MPN HC2133-3961.

Will it work with any app?

The DT841 uses Bluetooth LE in Application Mode. It works with apps built with Socket Mobile CaptureSDK version 2.0.29 or higher, and apps that already integrate CaptureSDK work with it out of the box.

Can I charge the iPhone and use its camera while it is in the terminal?

Yes. The housing keeps the camera and touchscreen fully accessible, and USB-C passthrough charges the iPhone while it is docked.

How durable is it?

The terminal has a rubberized housing that protects against drops and carries an IP54 rating.
