Wilson Electronics 311125 12-Inch Magnet Mount Omni Cellular Antenna with SMA-Male Connector

4G LTEMPN 311125
  • Single (SISO)
  • 6–8 dBi
  • 3–5 m
$15.09$27.99Save $12.90

Backordered · ships as soon as it arrives

1
Request a quote · volume, multi-site or with plans

Overview

The Wilson Electronics 311125 is a 12.25-inch omni-directional magnet mount antenna for vehicle cellular signal boosters. It has a 50 Ohm impedance and 12.5 ft of RG174 cable ending in an SMA-Male connector, and a mounting magnet is included. It installs on a metal roof in seconds, with no drilling, for fleet, work and personal vehicles.

  • 12.25 in. omni-directional magnet mount antenna
  • 50 Ohm impedance, 6.1 dBi rated gain
  • Covers bands from 700 MHz to 2170 MHz
  • 12.5 ft RG174 cable with SMA-Male connector
  • Mounting magnet included
  • Listed compatible with Wilson Sleek 460006 and 460106 boosters
  • Installs on a metal roof with no drilling or permanent hardware
  • The taller 12.25 in. whip provides more height than mini antennas

The Wilson Electronics 311125 12" Magnet Mount Antenna is a taller outside antenna for mobile signal booster kits. At 12.25 inches, it stands higher than compact mini antennas, and its omni-directional pattern picks up towers in every direction as the vehicle moves. The included mounting magnet holds it to any metal roof without drilling, so it is easy to move between vehicles or remove for car washes and parking garages.

The antenna covers 700-800, 824-894, 880-960, 1710-1880, 1850-1990 and 2110-2170 MHz with a rated gain of 6.1 dBi. Impedance is 50 Ohm, which matches 50 Ohm mobile boosters. A 12.5 ft RG174 coax cable is attached, ending in an SMA-Male connector. The cable is long enough to route through a door seal to a booster inside the cabin.

The 311125 is listed as compatible with the Wilson Sleek cellular signal boosters 460006 and 460106. It is a practical choice for drivers and fleet managers who want a stronger outside antenna for an SMA-based booster without a permanent install.

Ideal for

  • Vehicle cellular signal booster kits
  • Fleet vehicles that need a no-drill antenna
  • Rental or shared vehicles
  • Upgrading from a compact mini magnet antenna

Specifications

General

MPN
311125
Brand
Wilson Electronics
Antenna Type
Omni-Directional
Product Name
12" Magnet Mount Antenna (SMA-Male)

Cellular

Gain
6.1 dBi
Frequency Bands
700-800, 824-894, 880-960, 1710-1880, 1850-1990, 2110-2170 MHz

Features

Cable
12.5 ft RG174
Mount
Magnet (Mounting Magnet Included)
Height
12.25 in
Connector
SMA-Male
Impedance
50 Ohm

Compatibility

Compatible Boosters
Wilson Sleek 460006, 460106

Questions buyers ask

How long is the cable on the 311125?

It has 12.5 ft of RG174 coax ending in an SMA-Male connector.

Is the magnet included?

Yes. The mounting magnet is included.

Which boosters is it listed as compatible with?

It is listed as compatible with the Wilson Sleek 460006 and 460106 cellular signal boosters.

What is the impedance?

50 Ohm.
