Lantronix ANT-0100 LTE/5G L-Hinged Antenna with SMA Male Connector, Single Unit

5GMPN ANT-0100
  • Single (SISO)
  • 3–5 dBi
  • No cable

Made for Lantronix

$8.13

Backordered · ships as soon as it arrives

1
Request a quote · volume, multi-site or with plans

Overview

The Lantronix ANT-0100 is a single LTE/5G 3dBi antenna with an L-hinged SMA male connector, listed by Lantronix as an accessory for its NTC-500 Series cellular routers. It covers 617-960 MHz and 1710-6000 MHz, has a rated maximum gain of 1/3 dBi and a VSWR of 3.5 or lower, and stands 171 mm tall. Use it to replace a damaged antenna or fill a single port on an NTC-500 deployment.

  • Single LTE/5G antenna, sold as one unit
  • Frequency coverage of 617-960 MHz and 1710-6000 MHz
  • Rated maximum gain of 1/3 dBi (3dBi-class antenna)
  • VSWR rated at 3.5 or lower
  • L-hinged design with SMA male connector
  • 171 mm height
  • Listed by Lantronix as compatible with the NTC-500 Series
  • Manufacturer-matched antenna for Lantronix NTC-500 Series routers

The Lantronix ANT-0100 is the manufacturer's LTE/5G antenna for the NTC-500 Series. This part number is a single unit, so it suits spares, replacements and installs that need one more antenna. Each unit is an L-hinged whip with an SMA male connector that attaches directly to the router's antenna port. The hinge lets the element stand upright or fold to an angle, which helps when a router sits against a wall, inside a cabinet or on a DIN rail.

Lantronix specifies two frequency ranges: 617-960 MHz for low-band cellular and 1710-6000 MHz for mid- and high-band LTE and 5G. The rated maximum gain is 1/3 dBi, which Lantronix summarizes as a 3dBi antenna, and VSWR is rated at 3.5 or lower. The antenna measures 171 mm in height.

For IT teams and field-operations leads standardizing on the NTC-500 Series, a manufacturer-matched antenna keeps the RF path consistent with the hardware Lantronix designed around. Lantronix covers the ANT-0100 with a 1-year warranty. Sites that need several antennas at once can order the ANT-0100-B04, which bundles four of these units under one part number.

Ideal for

  • Replacing a lost or damaged antenna on a Lantronix NTC-500 Series router
  • Keeping spare antennas on hand for field-deployed NTC-500 gateways
  • Angling antennas around cabinet walls or enclosures using the L-hinge
  • Completing an NTC-500 installation that needs one additional antenna

Specifications

General

MPN
ANT-0100
Brand
Lantronix
Description
Antenna, LTE/5G 3dBi, L-Hinged, SMA Male, Single Unit
Product Type
LTE/5G L-Hinged Antenna

Package

Quantity
Single Unit
Shipping Weight
3.00 lbs

Warranty

Warranty
1 Year

Compatibility

Compatible Products
Compatible With: Lantronix NTC-500 Series

Specifications

Vswr
≤ 3.5
Height
171 mm
Connector
SMA Male
Frequency
617-960 / 1710-6000 MHz
Mount Style
L-Hinged
Maximum Gain
1/3 dBi

Questions buyers ask

Is the ANT-0100 one antenna or a set?

The ANT-0100 is a single antenna. Lantronix sells a bundle of four identical antennas as the ANT-0100-B04.

Which routers is the ANT-0100 compatible with?

Lantronix lists the ANT-0100 as compatible with its NTC-500 Series.

What frequencies does the ANT-0100 cover?

It covers 617-960 MHz and 1710-6000 MHz for LTE and 5G, with a rated maximum gain of 1/3 dBi and VSWR of 3.5 or lower.

What connector does it use?

It has an L-hinged SMA male connector that attaches directly to the router's antenna port.

What warranty does Lantronix provide?

Lantronix lists a 1-year warranty for the ANT-0100.
