Taoglas Olympian II MA145 3-in-1 GNSS, 5G/4G and Wi-Fi Screw Mount Antenna, 4m TGC-200 Cables

4G LTEMPN MA145.K.LBC.015
  • Single (SISO)
  • GNSS
  • Wi-Fi
  • 3–5 m
$147.66$175.78Save $28.12

In stockFree 2-day shipping

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Taoglas Olympian II MA145.K.LBC.015 is a compact 3-in-1 permanent-mount antenna for vehicles and outdoor assets. It combines an active GPS/GLONASS/Galileo antenna, a wideband 5G/4G cellular antenna with 3G/2G fallback, and a dual-band 2.4/5.8 GHz Wi-Fi antenna. The IP67, IK10-rated housing is 48.5mm tall and 50mm in diameter. This variant is supplied with 4m TGC-200 cables: SMA(M) on the GNSS and cellular leads and RP-SMA on the Wi-Fi lead.

  • 3-in-1: active GPS/GLONASS/Galileo GNSS, wideband 5G/4G cellular and dual-band 2.4/5.8 GHz Wi-Fi
  • Cellular coverage across 617-4200 MHz bands, including 5G NR FR1 and 3G/2G fallback
  • Compact puck housing, 48.5mm tall and 50mm in diameter, weighing 100g
  • IP67 waterproof and IK10 impact-rated UV-resistant ABS enclosure
  • M12 nickel-plated brass screw mount with rubber O-ring seal; no ground plane required
  • 4m TGC-200 cables: GNSS and cellular SMA(M), Wi-Fi RP-SMA
  • Rated -40°C to 85°C; RoHS and REACH compliant
  • One small, vandal-resistant puck replaces three separate antennas on vehicles and outdoor cabinets

The Taoglas Olympian II MA145.K.LBC.015 puts GNSS, cellular and Wi-Fi antennas in one vandal-resistant puck for external use on vehicles, kiosks and outdoor equipment. It is a cable and connector ordering variant of the MA145 platform. This version has 4m TGC-200 cables, with SMA(M) connectors on the GNSS and cellular leads and RP-SMA on the Wi-Fi lead. Typical applications include smart metering and remote monitoring, digital signage, and transportation and telematics.

The cellular element covers the worldwide LTE bands, many sub-6 GHz 5G FR1 bands and 3G/2G fallback. That includes Band 71 at 617-698 MHz, the 1710-2200 MHz mid-band (including Band 66) and 3300-4200 MHz 5G NR (Bands 22, 42, 48, 77, 78, 79). The Wi-Fi element covers 2400-2500 and 5150-5850 MHz. Both use 50 Ω impedance, linear polarization and an omnidirectional pattern, and are rated for 10 W maximum input power. The active GNSS antenna receives GPS L1, GLONASS L1, Galileo L1 and SBAS (WAAS/EGNOS). Its LNA delivers about 27.5 dB of gain at 3.0 V while drawing 10 mA.

No ground plane is required, although the low cellular bands perform best when the antenna is mounted on a metal ground plane. It installs from inside the enclosure through a nickel-plated brass M12 thread, and a rubber O-ring seals against water ingress. Taoglas notes that it is not suitable for metal enclosures where the cable runs inside the enclosure. The UV-resistant ABS housing carries IP67 and IK10 ratings and is rated from -40°C to 85°C and for 200 thermal shock cycles.

Ideal for

  • Roof or body-mounted antenna for fleet vehicles running a cellular router with GPS and Wi-Fi
  • Smart metering and remote monitoring cabinets
  • Digital signage and kiosks needing cellular backhaul and Wi-Fi
  • Transportation and telematics installations

Specifications

GNSS

Noise 1 8v
3.3 / 4.0 dB
Noise 3 0v
3.3 / 4.3 dB
Noise 5 5v
4.0 / 4.9 dB
Power 1 8v
4.5 mA @1.8V
Power 3 0v
10 mA @3.0V
Power 5 5v
24 mA @5.5V
Passive Vswr
2.0:1 max at 1575.42/1602 MHz
Polarization
RHCP
Lna Gain 1 8v
23.7 / 25.6 dB
Lna Gain 3 0v
27.5 / 28.1 dB
Lna Gain 5 5v
30.2 / 29.7 dB
Total Gain 3v
27 ± 3 dBi (1575.42) / 28 ± 3 dBi (1602)
Bands Supported
GPS L1, GLONASS L1, Galileo L1, SBAS WAAS/EGNOS
Output Impedance
50 Ω
Passive Efficiency
62% (1575.42 MHz) / 67% (1602 MHz)
Passive Gain Zenith
-1.98 dBi / -1.67 dBi at zenith

General

MPN
MA145.K.LBC.015
Vswr
VSWR 2:1
Brand
Taoglas
Gain Max
3.31 dBi max (product attribute)
Impedance
50 Ω
Technology
External antennas, combination
Polarization
Linear (cellular/Wi-Fi), RHCP (GNSS)
Configuration
3-in-1: cellular + Wi-Fi + active GNSS
Product Family
Olympian II
Standard Model
Ordering variant of MA145.A.LBC.001
Frequency Range
600-6000 MHz
Typical Applications
Smart metering and remote monitoring, digital signage, transportation and telematics

Package

Shipping Weight
0.22 lb

Compliance

Rohs
RoHS compliant
Reach
REACH compliant

Mechanical

Height
48.5 mm
Weight
100 g
Sealant
Rubber O-ring
Diameter
Ø50.15 mm
Enclosure
UV-resistant ABS
Ground Plane
No ground plane required
Mounting Style
Screw mount
Base And Thread
Nickel-plated brass
Thread Diameter
M12

Environmental

Humidity
Non-condensing, 65°C, 95% RH
Drop Test
1 m drop on concrete, 6 axes
Protection
IP67
Impact Rating
IK10
Thermal Shock
200 cycles, -40°C to +90°C
Temperature Range
-40°C to 85°C

Wi-Fi Electrical

Wi-Fi 2 4ghz
2400-2500 MHz: free space 44.4%, -3.5 dB, 0.7 dBi; 30x30cm ground plane 50.5%, -3 dB, 3.5 dBi
Wi-Fi 5 8ghz
5150-5850 MHz: free space 34.9%, -4.6 dB, 2.7 dBi; ground plane 34.5%, -4.6 dB, 3.6 dBi
Max Input Power
10 W

Cables Connectors

Cable Type
TGC-200 on all leads
Cable Length
4 m
GNSS Connector
SMA male
Wi-Fi Connector
RP-SMA
Cellular Connector
SMA male

Cellular Electrical

B617 698
617-698 MHz (Band 71): free space 29.4%, -5.5 dB, -0.2 dBi; 30x30cm ground plane 14%, -8.6 dB, -0.7 dBi
B698 806
698-806 MHz (Bands 12,13,14,17,28,29): free space 26.5%, -5.8 dB, -0.5 dBi; ground plane 38.3%, -4.2 dB, 1.3 dBi
B824 960
824-960 MHz (Bands 5,8,18,19,20,26,27): free space 20.3%, -6.9 dB, 0 dBi; ground plane 30.9%, -5.1 dB, 0.4 dBi
B1427 1518
1427-1518 MHz (Bands 21,32,74,75,76): free space 52.8%, -2.8 dB, 3.6 dBi; ground plane 51.8%, -2.9 dB, 2.2 dBi
B1710 2200
1710-2200 MHz (Bands 1,2,3,4,9,23,25,35,39,66): free space 40.8%, -4 dB, 3.8 dBi; ground plane 58.2%, -2.3 dB, 2.6 dBi
B2490 2690
2490-2690 MHz (Bands 7,38,41): free space 43.2%, -3.6 dB, 2.7 dBi; ground plane 40.4%, -3.9 dB, 1.8 dBi
B3300 4200
3300-4200 MHz 5G NR (Bands 22,42,48,77,78,79): free space 36.9%, -4.3 dB, 3.1 dBi; ground plane 25%, -6 dB, 2.7 dBi
Technologies
5G NR FR1, LTE, LTE-A, WCDMA, HSPA, HSPA+, TD-SCDMA
Max Input Power
10 W
Radiation Pattern
Omnidirectional

Questions buyers ask

How does MA145.K.LBC.015 differ from the standard MA145?

It is a cable and connector variant. It ships with 4m TGC-200 cables, with SMA(M) on the GNSS and cellular leads and RP-SMA on the Wi-Fi lead, instead of the standard 1m RG-174.

Does it cover 5G?

Yes. The cellular element covers worldwide LTE bands and many sub-6 GHz 5G FR1 bands, including 3300-4200 MHz (Bands 77, 78 and others), with 3G/2G fallback.

Does it need a metal ground plane?

No ground plane is required. For the lower cellular bands, it performs best when mounted on a metal ground plane.

Can I mount it on a metal enclosure?

Yes, but Taoglas notes it is not suitable for a metal enclosure where the cable runs inside that enclosure. It mounts from the inside using an M12 thread with a rubber O-ring seal.

Is the GNSS antenna active?

Yes. It has an LNA delivering roughly 23.7-30.2 dB of gain depending on supply voltage (1.8-5.5 V), drawing 10 mA at 3.0 V.
