Cradlepoint RX30-PoE Managed Accessory 4-Port GbE PoE Switch for R1900 (MB-RX30-POE)

MPN MB-RX30-POE

Made for Cradlepoint

$274.50$299.99Save $25.49

In stockShips from the US

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Cradlepoint RX30-PoE (MB-RX30-POE) is a compact, ruggedized managed accessory for the Ericsson Cradlepoint R1900 5G ruggedized router. It adds four Gigabit Ethernet RJ45 ports with 802.3bt Type 3 PoE and a 60 W total power budget, so cameras, access points and other Ethernet devices in vehicles, rail cars and field sites draw data and power from one cable. It is IP64-rated, runs on 9–36 VDC and carries E-Mark, EN 50155 and MIL-STD-810G certifications.

  • Adds 4 x Gigabit Ethernet RJ45 ports (LAN/WAN switchable) to the Cradlepoint R1900
  • 802.3bt Type 3 PoE on all four ports, up to 60 W per port, 60 W total PoE budget
  • IP64 ruggedized housing rated for -30 °C to 70 °C operation
  • 9–36 VDC input via 6-pin (2x3) Molex Micro-fit connector with ISO 7637-2 protection
  • E-Mark, EN 50155 Class S1, EN 50121-3-2, MIL-STD-810G and SAE J1455 certified
  • Includes 3 m 18AWG GPIO and power cable, small accessories kit and mounting template
  • Power cameras, access points and terminals directly from the R1900 installation with no separate power runs
  • Flexible port roles: each of the four GbE ports can be set as LAN or WAN

The Ericsson Cradlepoint RX30-PoE Managed Accessory is a PoE switch built specifically for the Cradlepoint R1900 5G ruggedized router. It gives the R1900 four additional Gigabit Ethernet RJ45 ports, each switchable between LAN and WAN, and each able to deliver 802.3bt Type 3 PoE at up to 60 W per port within a 60 W total power budget. For fleet, public-safety and transit teams, that means an IP camera, a Wi-Fi access point or a rugged terminal can be powered and connected from the router installation without separate power runs.

The housing matches the environments the R1900 is designed for. It is rated IP64 (dust tight and protected against splashing water), operates from -30 °C to 70 °C, and is certified to E-Mark for vehicles, EN 50155 Class S1 and EN 50121-3-2 for rail, and MIL-STD-810G and SAE J1455 for shock, vibration and humidity. Power comes from a 9–36 VDC supply through a 6-pin (2x3) Molex Micro-fit connector, with reverse polarity and transient voltage protection per ISO 7637-2. Vehicle installations require an in-line fuse: 10 A for 9–24 VDC systems and 5 A above 24 VDC.

The unit measures 173 x 152 x 30 mm and weighs 0.84 kg. A 6-pin GPIO connector is provided, and the box includes a 3-meter 18AWG GPIO and power cable, a small accessories kit and a mounting template. Calculated MTBF is 1,231,708 hours (Telcordia SR332 at 25 °C).

Activation and use of the RX30-PoE require an Ericsson Cradlepoint R1900 router licensed to an Ericsson NetCloud service plan. The RX30 data sheet is available for detailed installation planning.

Ideal for

  • Powering IP cameras on police, fire and EMS vehicles connected through an R1900
  • Adding PoE Wi-Fi access points to transit buses and rail cars
  • Connecting and powering rugged terminals and sensors at mobile command posts
  • Extending wired LAN or WAN ports on R1900 installations in utility and field-service trucks

Specifications

PoE

PoE Ports
4 x PoE 802.3bt Type 3
Per Port Power
Up to 60 W per port
Total PoE Budget
60 W total PoE power budget

Power

Protection
Reverse polarity and transient voltage protection per ISO 7637-2
Fuse 9 24 Vdc
10 A fuse for 9–24 VDC installations
Input Voltage
9–36 VDC steady state (in-line fuse required for vehicle installations)
Power Connector
6-pin (2x3) Molex Micro-fit External Power Connector
Consumption Idle
14 W (minimum; up to an additional 60 W with attached PoE devices)
Fuse Over 24 Vdc
5 A fuse for > 24 VDC installations
Consumption Heavy
23 W (minimum; up to an additional 60 W with attached PoE devices)
Consumption Sleep
0.07 W
Consumption Typical
21 W (minimum; up to an additional 60 W with attached PoE devices)
Consumption Conditions
R1900-5GB + RX30, 12 V input, 25 °C (77 °F) ambient

General

MPN
MB-RX30-POE
UPC
810007805597
Brand
Cradlepoint (Ericsson)
Model
RX30-PoE Managed Accessory — PoE Switch
Regions
North America, Europe, Asia-Pacific
Accessory Family
Modular

Package

Included
Managed Accessory — PoE Switch; GPIO & power cable, 2x3, 3 m, 18AWG (170858-000); small accessories kit; mounting template
Shipping Weight
3.00 lb (shipping)

Ethernet

Ports
4 x GbE RJ45 (LAN/WAN switchable)

Physical

Weight
0.84 kg (1 lb 13.5 oz)
Dimensions
173 x 152 x 30 mm (6.81 x 5.98 x 1.18 in)

Expansion

Connector Type
2x3 Molex micro-fit (3 mm locking type)
Gpio Connector
1 x 6-pin GPIO connector

Reliability

Calculated MTBF
1,231,708 hours (Telcordia SR332 at 25 °C)

Compatibility

Supported Routers
Ericsson Cradlepoint R1900
Licensing Requirement
Requires an R1900 licensed to an Ericsson NetCloud service plan

Environmental

Storage Humidity
5% to 95%
Ingress Protection
IP64 (dust tight and splashing water)
Operating Humidity
10% to 90%
Storage Temperature
-40 °C to 85 °C (-40 °F to 185 °F)
Operating Temperature
-30 °C to 70 °C (-22 °F to 158 °F)

Certifications

Rail
EN 50121-3-2 (Power Surge 0.5 & 1 kV Criteria A; 1.5 kV Criteria C); EN 50155 Class S1
Safety
UL/cUL; CB Scheme; EN 60950-1; EN 62368-1
Vehicle
E-Mark
Substance Compliance
WEEE; RoHS; REACH; California Prop 65
Shock Vibration Humidity
MIL STD 810G; SAE J1455

Questions buyers ask

Which routers work with the RX30-PoE?

The RX30-PoE is designed for the Ericsson Cradlepoint R1900 router. Activation and use require an R1900 licensed to an Ericsson NetCloud service plan.

How much PoE power can it deliver?

Each of the four ports supports 802.3bt Type 3 PoE at up to 60 W, with a 60 W total PoE power budget across all ports.

What power input does it need?

It accepts 9–36 VDC through a 6-pin (2x3) Molex Micro-fit connector. Vehicle installations require an in-line fuse: 10 A for 9–24 VDC and 5 A for systems above 24 VDC.

Is it suitable for vehicle and rail installations?

Yes. It is IP64-rated, operates from -30 °C to 70 °C and carries E-Mark, EN 50155 Class S1, EN 50121-3-2, MIL-STD-810G and SAE J1455 certifications.

What comes in the box?

The PoE switch, a 3-meter 18AWG 2x3 GPIO and power cable, a small accessories kit and a mounting template.
