Taoglas Raptor X RAPX.4.4C.8M.S2.B 4-in-1 5G/4G MIMO Screw-Mount Antenna, 8m SMA Male

5GMPN RAPX.4.4C.8M.S2.B
  • 4x4 MIMO
  • Over 5 m
$191.91$228.46Save $36.55

In stockShips from the US

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Taoglas Raptor X RAPX.4.4C.8M.S2.B is a 4-in-1 permanent screw-mount antenna with four 5G/4G MIMO elements covering 617MHz to 6GHz, for 4x4 cellular routers and gateways. The 350 x 70 x 40mm enclosure is IP67 and IP69K waterproof and IK10 impact rated. This variant has four long 8m TGC-200 leads with SMA male connectors, for installs where the router sits well away from the antenna.

  • 4-in-1 antenna with 4x 5G/4G MIMO elements
  • Covers 617MHz to 5925MHz, worldwide 5G/4G bands with 3G/2G fallback
  • 5G NR n77, n78, n79 and Band 48 coverage with up to 7.74dBi peak gain
  • IP67 and IP69K waterproof, IK10 impact-rated 350 x 70 x 40mm housing
  • Permanent screw mount, -40°C to +85°C operation
  • 8m TGC-200 leads with four SMA male connectors
  • Place the antenna for the best signal and run 8m back to a router in a remote cabinet or equipment room
  • Feed all four ports of a 4x4 MIMO 5G router from a single housing

The Raptor X MA890 combines four 5G MIMO antennas in one compact enclosure. It is built for routers and gateways that use four cellular antenna ports to lift throughput across uplink and downlink bands. Taoglas targets digital signage, transportation and autonomous vehicles, private 5G networks, and public safety.

All four elements cover 617MHz to 5925MHz, including worldwide 5G/4G bands with 3G and 2G fallback. Coverage spans Band 71; bands 12, 13, 14, 17, 28 and 29; bands 5, 8, 18, 19, 20, 26 and 27 including NB-IoT and Cat-M; 1427-1518MHz; 1710-2200MHz; bands 7, 30, 38, 40 and 41; and 3300-5000MHz for bands 22, 42, 48, n77, n78 and n79. It extends to 5150-5925MHz. Peak gain reaches up to 7.74dBi at 3.3-5GHz, and maximum input power is 2W to 10W.

The housing is IK10 impact rated and IP67 and IP69K waterproof, for rooftops, shelters and displays exposed to weather. It operates from -40°C to +85°C.

RAPX.4.4C.8M.S2.B is a cable and connector variant of the standard MA890.A.BIVW.001, with four 8m TGC-200 leads terminated in SMA male connectors. The 8m length suits larger vehicles, buildings and sites where the router is installed in a remote cabinet or interior equipment room. The Taoglas MA890.A.BIVW.001 datasheet documents the full electrical performance.

Ideal for

  • Buses, rail cars and large vehicles with the router mounted far from the roof antenna
  • Building rooftop installs feeding an interior equipment room
  • Private 5G network sites with remote cabinets
  • Digital signage and public-safety deployments
  • Industrial sites needing long antenna cable runs

Specifications

Cabling

Cable Type
TGC-200
Connectors
4x SMA male
Cable Length
8 m

General

MPN
RAPX.4.4C.8M.S2.B
Brand
Taoglas
Elements
4x 5G/4G MIMO
Technology
External combination antenna
Product Name
Raptor X MA890 4-in-1 5G/4G MIMO Antenna
Standard Model
Variant of standard model MA890.A.BIVW.001

Compliance

Environmental Compliance
RoHS and REACH compliant

Mechanical

Weight
950 g
Dimensions
350 x 70 x 40 mm
Enclosure Impact Rating
IK10

Environmental

Temperature Range
-40°C to +85°C
Waterproof Rating
IP67 and IP69K

LTE Electrical

Band 71
36.4-49.8%, up to 2.25 dBi
Impedance
50 Ω
698 824mhz
35.4-50.3%, up to 2.94 dBi
824 960mhz
4G/3G/NB-IoT/Cat M 824-960 MHz (B5/8/18/19/20/26/27): 37.5-50.8%, up to 2.64 dBi
1427 1518mhz
24.5-27.9%, up to 1.21 dBi
1710 2200mhz
4G/3G 1710-2200 MHz (B1/2/3/4/9/23/25/35/39): 42.5-53.7%, up to 5.63 dBi
2300 2690mhz
45.2-56.8%, up to 6.97 dBi
3300 5000mhz
5G NR/4G 3300-5000 MHz (B22/42/48/n77/n78/n79): 55.6-58.9%, up to 7.74 dBi
5150 5925mhz
40.1-48.9%, up to 6.48 dBi
Polarization
Linear
Test Condition
Tested with 0.3 m of cable
Max Input Power
2W to 10W
Radiation Pattern
Omnidirectional

Product Attributes

Rohs
Yes
Vswr
<2
Width
70 mm
Height
40 mm
Length
350 mm
Weight
455 g
Gain Max
4.6 dBi
Impedance
50 Ω
IP Rating
IP67
Polarization
Linear
Mounting Style
Screw
Frequency Range
600 - 6000 MHz
Max Operating Temperature
85°C
Min Operating Temperature
-40°C

Questions buyers ask

How long are the cables on the RAPX.4.4C.8M.S2.B?

Each of the four leads is 8m of TGC-200 cable terminated in an SMA male connector.

Which bands does it cover?

617MHz to 5925MHz on all four elements. That includes Band 71, the 700MHz and 800/900MHz bands, 1427-1518MHz, 1710-2200MHz, 2300-2690MHz, 3300-5000MHz (bands 22, 42, 48, n77, n78, n79) and 5150-5925MHz.

What is the maximum input power?

2W to 10W.

Is it rugged enough for exposed locations?

Yes. The enclosure is IK10 impact rated and IP67 and IP69K waterproof, and operates from -40°C to +85°C.
