Overview
Create a sealed mounting surface for Megalodon antennas on ribbed, curved, thick or uneven vehicle roof panels. This black panel adaptor kit combines central and main foam sealing pads to accommodate panel features while protecting the antenna entry point. It supports installations using a 34 mm mounting hole and up to 20 mm mounting depth.
- Closed-cell central pad seals the antenna entry point
- Semi-closed EPDM main pad conforms to roof ribs and curvature
- 34 mm mounting-hole compatibility
- 20 mm maximum panel and rib mounting depth
- IPX6 installation water-ingress protection
- Accommodate ribbed, curved and uneven vehicle roof panels with a two-pad mounting adaptor.
- Seal a 34 mm antenna mounting hole with 3 mm inner-foam compression or the hard stop.
- Support up to 20 mm total mounting depth, including panel and rib height.
Create a weather-resistant antenna mounting surface on vehicle roofs that are not flat. The Panorama SAB-346 Megalodon ribbed panel adaptor kit fits beneath a compatible Megalodon antenna mount, allowing its sealing surface to follow ribs, roof curvature and other uneven panel features. It is intended for motorhomes, vans and buses where a conventional flat-panel mounting surface is unavailable.
The adaptor combines a closed-cell central sealing pad with a semi-closed-cell main pad. The central pad seals the antenna entry point, while the main pad accommodates the shape of the roof panel. Compress the inner foam pad by 3 mm, or until the hard stop is reached, to form the seal. When installed to the applicable instructions, the completed installation provides IPX6 water-ingress protection.
SAB-346 supports a 34 mm mounting hole and a maximum 20 mm mounting depth, including panel and rib height. Panel variation or rib height must not exceed 10 mm. The assembly measures 23 mm high and uses stainless steel, semi-closed EPDM foam and closed-cell silicone foam. Its black finish matches the Megalodon mounting application while the pad structure addresses thicker panels and uneven roof surfaces.
Ideal for
- Mounting a Megalodon antenna on a ribbed van roof without leaving gaps around the antenna base.
- Installing a roof antenna on a curved motorhome panel where a flat sealing surface is not available.
- Adapting an antenna mount to a bus roof panel with raised features up to 10 mm high.
Specifications
General
- Brand
- Panorama Antennas
- Product Type
- Megalodon ribbed/uneven panel adaptor kit
- Manufacturer Part Number
- SAB-346
Mounting
- Mounting Type
- Fixed panel mount
- Mounting Method
- Panel
- Mounting Hole Size
- 34 mm (1.33 in)
- Maximum Mounting Depth
- 20 mm (0.8 in), inclusive of panel and rib height
- Required Foam Compression
- 3 mm (0.12 in) of inner foam pad, or until hard stop
- Maximum Panel Variation OR Rib Height
- 10 mm (0.4 in)
Logistics
- Shipping Weight
- 1.06 lb
Mechanical
- Color
- Black
- Height
- 23 mm (0.9 in)
- Material
- Stainless steel / semi-closed EPDM foam / closed-cell silicone foam
- Operating Temperature
- -40 to +80 °C (-40 to +176 °F)
Protection
- IP Rating
- IPX6 when installed in accordance with applicable instructions
Questions buyers ask
How do I confirm SAB-346 is the right part for my antenna installation?
Choose SAB-346 when a compatible Megalodon antenna must be mounted through a ribbed, curved, thick or uneven vehicle panel. The installation requires a 34 mm mounting hole, no more than 20 mm combined panel and rib depth, and no more than 10 mm panel variation.
What is included with the SAB-346 panel adaptor kit?
The adaptor uses a closed-cell central sealing pad and a semi-closed-cell main pad. Together, these pads seal around the antenna entry point while allowing the outer pad to conform to roof ribs, curvature and uneven surface features.
What panel dimensions can this adaptor accommodate?
The adaptor fits a 34 mm mounting hole and supports a maximum 20 mm mounting depth, including the panel and rib height. The panel material variation or rib height must not exceed 10 mm for the intended mounting arrangement.
Does the adaptor provide water-ingress protection?
An installation using this adaptor achieves an IPX6 water-ingress protection rating when fitted in accordance with the applicable instructions. Correct foam-pad compression is required: compress the inner pad by 3 mm or continue until the hard stop is reached.
