- Single (SISO)
- No cable
$19.99
In stockShips from the US
- 30-day returns on unopened devices
- Secure checkout · pay by card
Datasheets & documents
Overview
The Skymirr TAMP141 is an ultra-wideband omnidirectional external antenna that covers the entire 4G LTE and 5G Sub-6 spectrum across three ranges: 617-960 MHz, 1447-2690 MHz and 3300-5925 MHz. It has a hinged SMA (male) connector, reaches up to 82% efficiency and 2.1-6.4 dBi peak gain, and performs especially well in the low 600 MHz bands used by newer 5G networks. It fits routers, gateways, CPE, automotive and IoT devices.
- Covers the entire 4G LTE and 5G Sub-6 spectrum: 617-960 MHz, 1447-2690 MHz and 3300-5925 MHz
- Efficiency of up to 82% (82.2% measured at 2170 MHz)
- Peak gain of 2.1 to 6.4 dBi, with 6.41 dBi at 3300 MHz
- Omnidirectional, vertically polarized, 50 Ω impedance
- External antenna with a hinged SMA (male) connector
- 196.32 mm x 36 mm x Φ13 mm, available in black or white
- RoHS compliant
- One antenna covers low-, mid- and high-band 4G LTE and 5G Sub-6, so the same part works across carriers and regions
The Skymirr TAMP141 is a high-performance omnidirectional cellular antenna for any wireless device that uses 4G LTE or 5G Sub-6 frequencies. Skymirr designed it for Consumer Premise Equipment (CPE), wireless routers and gateways, automotive devices and IoT hardware such as sensors and trackers. It covers three operating ranges: 617-960 MHz, 1447-2690 MHz and 3300-5925 MHz. This spans the low 600 MHz bands where newer Sub-6 5G service runs, the mid bands that carry most LTE traffic, and the 3.3-5.9 GHz range used for high-capacity 5G.
Skymirr publishes measured results across the whole range. Efficiency peaks at 82.2% at 2170 MHz and stays at 57.7% or higher at every tested frequency. Peak gain runs from 2.1 to 6.4 dBi, with the highest figure, 6.41 dBi, at 3300 MHz. The antenna is vertically polarized with a 50 Ω impedance and an omnidirectional pattern, so it picks up signal from every direction without aiming.
The antenna measures 196.32 mm x 36 mm x Φ13 mm, comes in black or white, and connects through an SMA (male) connector on a hinge. The hinge lets you angle the element upright on the device it is attached to. As a passive antenna it needs no batteries or external power. The TAMP141 is RoHS compliant, and Skymirr publishes a datasheet with full gain, efficiency, VSWR and radiation-pattern data.
Ideal for
- Replacing or upgrading the stock antennas on a 4G LTE or 5G router or gateway with SMA ports
- Fixed wireless CPE installations in homes and branch offices
- Automotive and in-vehicle cellular devices
- IoT deployments such as sensors, trackers and smart devices
- Improving low-band 600 MHz 5G reception in fringe or indoor locations
Specifications
General
- MPN
- TAMP141
- Brand
- Skymirr
- Color
- Black / White
- Connector
- SMA (male)
- Peak Gain
- 2.1 to 6.4 dBi
- Efficiency
- Up to 82%
- Antenna Size
- 196.32 mm x 36 mm x Φ13 mm
- Antenna Type
- External antenna with hinge
- Product Name
- 4G LTE / 5G Ultra Broadband Omni Antenna
- Operating Frequency Bands
- 617-960 MHz; 1447-2690 MHz; 3300-5925 MHz
Compliance
- Rohs
- RoHS compliant
Electrical
- Impedance
- 50 Ω
- Directivity
- Omnidirectional
- Polarization
- Vertical
Gain And Efficiency
- AT 617 MHz
- 57.7% efficiency, 2.12 dBi peak gain
- AT 960 MHz
- 77.2% efficiency, 3.23 dBi peak gain
- AT 1447 MHz
- 72.8% efficiency, 2.90 dBi peak gain
- AT 2170 MHz
- 82.2% efficiency, 2.24 dBi peak gain
- AT 2305 MHz
- 70.8% efficiency, 1.82 dBi peak gain
- AT 2690 MHz
- 77.5% efficiency, 2.07 dBi peak gain
- AT 3300 MHz
- 75.3% efficiency, 6.41 dBi peak gain
- AT 4200 MHz
- 76.3% efficiency, 2.99 dBi peak gain
- AT 5000 MHz
- 77.5% efficiency, 3.76 dBi peak gain
- AT 5925 MHz
- 66.0% efficiency, 4.16 dBi peak gain
Questions buyers ask
What frequencies does the Skymirr TAMP141 cover?
It covers 617-960 MHz, 1447-2690 MHz and 3300-5925 MHz, which spans the entire 4G LTE and 5G Sub-6 bands.
What connector does the TAMP141 use?
It uses an SMA (male) connector on a hinge, so it attaches directly to devices with SMA antenna ports and can be angled upright.
How much gain does the antenna provide?
Peak gain ranges from 2.1 to 6.4 dBi depending on frequency. The highest figure, 6.41 dBi, is at 3300 MHz.
Does the TAMP141 need power?
No. It is a passive antenna and needs no batteries or external power source.
Which devices is it intended for?
Skymirr lists wireless routers, gateways, CPE, automotive devices and IoT devices, including sensors, trackers and smart devices, that use 4G and/or 5G Sub-6 bands.
