HoneywellPhones

Honeywell CT45 4G LTE Rugged Mobile Computer, 5-Inch HD, 4GB/64GB, FlexRange Scanner

4G LTEMPN CT45-L1N-28D120G
  • 64 GB
  • Rugged
$2,029.44$2,890.81Save $861.37

In stockShips from the US

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Honeywell CT45-L1N-28D120G is a rugged 4G LTE mobile computer with Honeywell's FlexRange scan engine for both near and far barcode reads. This global configuration pairs a 5-inch HD touchscreen with 4GB RAM, 64GB flash, 13MP and 8MP cameras, Bluetooth 5.1, push-to-talk and Google Mobile Services in an IP68/IP65 housing built on the Mobility Edge platform.

  • Honeywell FlexRange scan engine for near and far 1D/2D reads, Mid Range (0-5 m)
  • 4G LTE Advanced: up to 390 Mbps Cat 13 downlink, 75 Mbps Cat 5 uplink, AT&T FirstNet compliant
  • 5-inch HD (1280 x 720) touchscreen with Gorilla Glass 5
  • Qualcomm QCS4290/QCM4290 octa-core 2.0GHz, 4GB RAM, 64GB flash, microSD up to 512GB
  • 13MP autofocus rear and 8MP front cameras
  • 4020 mAh Quick Charge 3.0 smart battery, metal battery latch, USB 3.0 Type-C OTG
  • IP68/IP65, 1.8 m drops per MIL-STD-810H, push-to-talk support
  • Cover close-up and distant scanning with one device, reducing the number of models to manage

The Honeywell CT45 is a rugged, all-purpose mobile computer for front-line workers in retail, logistics and fieldwork. This CT45-L1N-28D120G configuration is the global WWAN model with the FlexRange scan engine, a 5-inch HD (1280 x 720) touchscreen, 4GB RAM and 64GB flash, 13MP rear and 8MP front cameras, Android with Google Mobile Services, a battery, a metal battery latch button, USB 3.0 Type-C with OTG, and push-to-talk support.

FlexRange lets one device cover near and far scanning workflows, with mid-range reads from 0 to 5 m, so a store associate can scan a label in hand and a warehouse worker can read a shelf tag overhead without switching devices. The 13MP autofocus rear camera handles proof-of-delivery and condition photos.

The LTE Advanced radio reaches up to 390 Mbps Cat 13 downlink and 75 Mbps Cat 5 uplink across LTE bands including 2, 4, 5, 12, 13, 14, 17, 66 and 71, with UMTS/HSPA+ fallback and two Nano SIM slots, and it is AT&T FirstNet compliant. Indoors, 802.11 a/b/g/n/ac Wi-Fi with 802.11k/r/v support and WPA3, Bluetooth 5.1 and BLE, NFC and multi-constellation GNSS complete the radios. A Qualcomm QCS4290/QCM4290 octa-core 2.0GHz processor, microSD expansion up to 512GB, and Android support from Android 11 to at least 13 (with Android 14 and 15 committed, pending feasibility) support long deployments.

The CT45 weighs 282 g with battery, survives multiple 1.8 m (6 ft) drops to concrete per MIL-STD-810H (2.4 m with boot) and more than 1,500 tumbles at 1 m, and is sealed to IP68/IP65 under Gorilla Glass 5. Its 4020 mAh smart battery is Quick Charge 3.0 compliant and charges fully in under three hours.

Ideal for

  • Warehouse teams scanning shelf and pallet labels at a distance
  • Retail back-room and floor inventory counts mixing close and far reads
  • Last-mile delivery with LTE connectivity, scanning and photo capture
  • Field service and manufacturing crews using push-to-talk and work-order apps
  • FirstNet public service deployments needing a rugged LTE handheld

Specifications

General

MPN
CT45-L1N-28D120G
Brand
Honeywell
Model
CT45 Mobile Computer
Region
Global configuration
Push TO Talk
Push-to-talk supported
Battery Latch
Metal battery latch button
Google Mobile Services
Android with Google Mobile Services

Network

NFC
Integrated NFC reader (ISO 14443 A/B, 15693, MIFARE, FeliCa, 18092)
SIM
Dual Nano SIM
VPN
IPSec V4/L2TP, PPTP
GNSS
GPS, GLONASS, Galileo, BeiDou, A-GPS
Wwan
4G LTE Advanced
Firstnet
AT&T FirstNet compliant
Bluetooth
Bluetooth 5.1 and BLE
LTE Bands
LTE bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 66, 71
LTE Uplink
Up to 75 Mbps Cat 5 LTE uplink
Quad Bands
850/900/1800/1900 MHz quad bands
LTE Downlink
Up to 390 Mbps Cat 13 LTE downlink
Wlan Security
Open, WEP, WPA/WPA2/WPA3 Personal and Enterprise
Wlan Standards
802.11 a/b/g/n/ac with d/e/h/i/k/r/v/u/w/mc
Umts Hspa Bands
UMTS/HSPA+ (3G) bands 1, 2, 4, 5, 6, 8, 9, 19
Wlan Certification
Wi-Fi certified
Wwan Radio Variants
AT&T, Verizon, Sprint, T-Mobile, NA, EU

Features

Camera
13 MP autofocus rear / 8 MP front
Application
Retail, transportation & logistics, manufacturing, healthcare, public service
Environment
Standard
Connectivity
Wi-Fi and cellular (WWAN)

Hardware

USB
USB 3.0 Type-C with OTG
Keypad
Full touchscreen
Sensors
Ambient light, proximity, accelerometer, gyroscope, magnetometer, hall, high-g
Backlight
LED
Processor
Qualcomm QCS4290/QCM4290 octa-core, 2.0 GHz
Cover Glass
Corning Gorilla Glass 5
Scan Engine
Honeywell FlexRange
Touch Panel
Rugged multi-touch capacitive, optically bonded
Display Size
12.7 cm (5.0 in)
Scan Distance
Mid Range (0-5 m)
Display Resolution
HD (1280 x 720)

Scanning

Decode Capability
Honeywell FlexRange, 1D/2D symbologies; Honeywell SDKs for Android

Dimensions

Weight
282 g (9.9 oz) with battery pack
Shipping Weight
1.10 lb shipping weight
Overall Dimensions
163 mm x 79 mm x 19.2 mm

Electrical

Charging
Quick Charge 3.0; full charge in under 3 hours
Battery Type
Smart battery with integrated diagnostics
Battery Capacity
Li-Ion, 3.85 V, 4020 mAh

Memory Data

RAM
4GB DDR4x RAM
Flash
64GB UFS flash
Expansion
User-accessible microSD up to 512GB (SDXC/SDHC/SDIO)

Environmental

Operating Humidity
5% to 95% non-condensing
Storage Temperature
-30°C to +70°C (-22°F to +158°F)
Operating Temperature
-20°C to +50°C (-4°F to +122°F)

Service Terms

Warranty
1-year factory warranty

Software Firmware

Platform
Honeywell Mobility Edge
Operating System
Android 11 (GMS)
Operating System Support
Android 11 to at least 13 guaranteed; Android 14 and 15 committed, pending feasibility

Standards Approvals

Drop
1.8 m (6 ft) drops; 2.4 m (8 ft) with boot, -20°C to +50°C, MIL-STD-810H
Tumble
1,500+ tumbles at 1 m per IEC 60068-2-32
Protection Rating
IP68 / IP65

Questions buyers ask

What does the FlexRange scan engine add?

FlexRange supports both near and far scanning workflows in one device, with mid-range reads from 0 to 5 m, so workers can scan labels in hand or on high shelves.

Is this CT45 a 5G device?

No. It uses 4G LTE Advanced with up to 390 Mbps Cat 13 downlink and 75 Mbps Cat 5 uplink, plus UMTS/HSPA+ fallback.

Does it support push-to-talk?

Yes. Push-to-talk is supported on this configuration.

How quickly does the battery charge?

The 4020 mAh smart battery is Quick Charge 3.0 compliant and reaches a full charge in less than three hours.

Which Android versions are supported?

Honeywell guarantees Android 11 through at least Android 13, with committed support for Android 14 and 15 pending feasibility.
