Honeywell CT47 5G Rugged Handheld Computer, 8GB/128GB, S0803 FlexRange, NI/ATEX, GMS

5GMPN CT47-X1N-58D1E1G
  • 128 GB
  • Rugged
$2,936.95$4,183.49Save $1,246.54

In stockShips from the US

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Honeywell CT47-X1N-58D1E1G is the global NI/ATEX configuration of Honeywell's ultra-rugged CT47 mobile computer. It is built for front-line workers in logistics, warehousing, manufacturing and field operations who need a hazardous-area configured device. The unit combines 5G and Wi-Fi 6E with an S0803 FlexRange scan engine, 8GB RAM and 128GB flash storage, a 5.5-inch Full HD touchscreen, and Android with Google Mobile Services on Honeywell's Mobility Edge platform.

  • 5G FR1 and LTE Advanced (CAT13 downlink up to 390 Mbps) with CBRS and private network support
  • NI/ATEX battery configuration for hazardous-area use, warm-swappable
  • S0803 FlexRange scan engine for 1D/2D barcode capture
  • Qualcomm QCS6490/QCM6490 octa-core 2.7 GHz with 8GB DDR4x RAM and 128GB UFS flash
  • 5.5-inch Full HD (2160 x 1080) rugged multi-touch display with Gorilla Glass 5
  • Wi-Fi 6E 2x2 MU-MIMO, Bluetooth 5.2 with BLE, 1 nano SIM + 1 eSIM
  • IP65/IP68, multiple 8 ft drops to concrete per MIL-STD-810H
  • Deploy a single 5G handheld into hazardous areas with the NI/ATEX battery configuration

The Honeywell CT47-X1N-58D1E1G is an ultra-rugged 5G handheld computer configured with an NI/ATEX battery for hazardous-area deployments. This is the worldwide (WW) SKU. Like every CT47, it runs on Honeywell's Mobility Edge platform. It was released with Android 12, and Honeywell guarantees OS support through Android 15, which helps with long-lifecycle fleet planning. This configuration ships with Google Mobile Services.

Connectivity is built for the modern enterprise. The 5G FR1 radio covers a broad band set, including n41, n48, n71, n77 and n78, with 4x4 MIMO on key 5G and LTE bands. It supports CBRS and private networks, and LTE Advanced reaches up to 390 Mbps down (CAT13). Indoors, Wi-Fi 6E with 2x2 MU-MIMO and dual band simultaneous operation keeps devices online. The CT47 also offers Bluetooth 5.2 with BLE, one nano SIM plus one eSIM, and push-to-talk.

Data capture runs through the S0803 FlexRange scan engine for 1D and 2D barcodes, along with a 13 MP rear camera and an 8 MP front camera. A Qualcomm QCS6490/QCM6490 octa-core 2.7 GHz processor drives the device, with 8GB DDR4x RAM, 128GB UFS flash and microSD expansion up to 2 TB. For security, a fingerprint sensor and front-camera facial recognition provide multi-factor biometric login.

The housing is certified to IP65 and IP68, and the display is protected by Gorilla Glass 5. Under MIL-STD-810H, the device survives multiple 8 ft (2.45 m) drops to concrete, or 9 ft (2.75 m) with the protective boot. It also exceeds 3,500 tumbles at 0.5 m. The battery is warm-swappable, and the device charges over USB-C 3.0. Honeywell's datasheet and an NI/ATEX quick start guide are available for this model.

Ideal for

  • Hazardous-area inspections and operations in plants requiring NI/ATEX-configured devices
  • Warehouse picking, receiving and inventory with 1D/2D scanning
  • Field service and maintenance on public or private 5G networks
  • Transport and logistics proof-of-delivery with push-to-talk communications

Specifications

Wlan

Eap
TLS, PEAP, TTLS, PWD, LEAP; CCX compatible
MIMO
2x2 MU-MIMO
Security
OPEN, WEP, WPA/WPA2/WPA3 (Personal and Enterprise)
Standard
IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax
IP Support
IPv4, IPv6
Certification
Wi-Fi certified, Wi-Fi 6E certified
Dual Band Simultaneous
Dual Band Simultaneous (DBS)

Camera

Rear
13 MP rear camera
Front
8 MP front camera

Memory

RAM
8GB DDR4x RAM
Storage
128GB UFS flash
Expansion
User-accessible microSD up to 2 TB (SDXC/SDHC/SDIO-compliant)

Display

Size
5.5 in (13.97 cm)
Resolution
Full HD 2160 x 1080
Cover Glass
Corning Gorilla Glass 5
Touch Panel
Rugged multi-touch

General

MPN
CT47-X1N-58D1E1G
Brand
Honeywell
Model
CT47 Handheld Computer
Region
Worldwide (WW) configuration
Industry
Aerospace, Logistics & Warehouses, Manufacturing
Application
Transportation & Logistics, Warehouse, Manufacturing, Field Operations
Connectivity
Wi-Fi & Cellular (5G & Wi-Fi 6E)
Sku Description
CT47, 5G, 8GB/128GB, S0803, eSIM, GMS, NI/ATEX, Worldwide

Service

Warranty
1 year

Cellular

SIM
1 nano SIM and 1 eSIM
Firstnet
AT&T FirstNet Compliant
MIMO 4x4
4x4 MIMO on 5G n7, n38, n41, n48, n77, n78, n79 and 4G B7, B41, B42, B43, B48
Gsm Bands
GSM quad-band 850/900/1800/1900 MHz
LTE Bands
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B38, B39, B40, B41, B42, B43, B66, B71
Generation
5G WWAN
Wwan Radio
ATT/VZW/SPRINT/TMO/NA/EU
LTE Advanced
Up to 390 Mbps CAT13 LTE downlink, up to 75 Mbps CAT5 LTE uplink
NR Fr1 Bands
5G FR1: n1, n2, n3, n4, n5, n7, n8, n12, n14, n20, n25, n28, n30, n38, n40, n41, n48, n66, n71, n77, n78, n79
Umts Hspa Bands
UMTS/HSPA+ (3G): Bands 1, 2, 4, 5, 6, 8, 9, 19
Private Networks
Private 5G and CBRS network support

Hardware

Port
USB Type-C 3.0
Keypad
Full touchscreen
Sensors
Ambient light, proximity, accelerometer, gyroscope, magnetometer, barometer, eCompass, Hall and High-G sensors
Processor
Qualcomm QCS6490/QCM6490 octa-core, 2.7 GHz
Biometrics
Fingerprint sensor and front-camera facial recognition
Push TO Talk
Push-to-talk

Scanning

Scan Engine
Honeywell S0803 FlexRange scan engine
Symbologies
1D and 2D barcodes
Scan Distance Family
CT47 family scan distance options: Long Range 0-20 m, Mid Range 0-5 m, Standard Range 0-1 m

Software

Platform
Honeywell Mobility Edge
Google Services
Google Mobile Services (GMS)
Operating System
Released with Android 12 and guaranteed through Android 15

Bluetooth

Version
Bluetooth 5.2 and BLE

Standards

Drop
Multiple 2.45 m (8 ft) drops to concrete per MIL-STD-810H; 2.75 m (9 ft) with protective boot
Tumble
Exceeds 2,000 tumbles at 1 m (3.28 ft) and 3,500 tumbles at 0.5 m (1.64 ft) per IEC 60068-2-32
Protection Rating
Certified for IP65 & IP68

Dimensions

Weight
314 g (11.1 oz) with standard battery pack
Overall
170 x 79 x 19.2 mm (6.69 x 3.11 x 0.75 in) with standard battery pack

Electrical

Battery
NI/ATEX battery, warm swap
Battery Type
Lithium-ion
Battery Options
4775 mAh standard, 4680 mAh wireless, 7692 mAh extended

Environmental

Environment
Hazardous Area (NI/ATEX) configuration
Storage Temperature
-30°C to +70°C (-22°F to +158°F)
Operating Temperature
-20°C to +50°C (-4°F to +122°F)

Questions buyers ask

What does NI/ATEX mean on the CT47-X1N-58D1E1G?

This CT47 configuration ships with Honeywell's NI/ATEX battery and is part of Honeywell's hazardous-area CT47 range. Honeywell also publishes a dedicated NI/ATEX quick start guide for it.

Does it work on private 5G and CBRS networks?

Yes. Honeywell specifies private 5G and CBRS support, including band 48, alongside public 5G FR1 and LTE Advanced.

Which Android version does it run?

The CT47 was released with Android 12, and Honeywell guarantees support through Android 15. This SKU includes Google Mobile Services.

What SIM options does it support?

It has one nano SIM slot and one eSIM.

How rugged is it?

It is certified to IP65 and IP68. It survives multiple 8 ft drops to concrete per MIL-STD-810H, or 9 ft with the protective boot, and exceeds 3,500 tumbles at 0.5 m.
