SonimPhones

Sonim XP5plus Rugged 4G LTE Push-to-Talk Phone with Top-Mount Knobs, Black

4G LTEMPN F16CDP1-132-000
  • Rugged
$389.07$449.00Save $59.93

In stockShips from the US

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Sonim XP5plus is a rugged 4G LTE push-to-talk phone that combines cellular calling with radio-like features. This black configuration has top-mount knobs for volume and channel control, plus an emergency key, so it can be used without looking. It has a large glove-friendly PTT button and 100dB+ dual speakers. Protection includes IP68 and IPX9K ratings, MIL-STD-810H testing and Non-Incendive Class I, II and III Div 2 certification. The removable 3500mAh battery lasts through long shifts.

  • Large glove-friendly PTT button with top-mount knobs for volume and channel control, plus a dedicated emergency key
  • IP68 and IPX9K, MIL-STD-810H, and Non-Incendive Class I, II and III Div 2 ratings
  • Survives 6.5 ft drops on concrete; operates from -4°F to 131°F
  • Dual 100dB+ front-facing speakers with Goodix noise and echo cancellation
  • Removable 3500mAh battery rated for 30 hours of talk and 600 hours of standby
  • 4G LTE with dual nano-SIM, VoLTE, RTT, Wi-Fi hotspot for up to 10 connections and Bluetooth 5.0
  • SecureAudio Connector that locks RSMs and audio accessories in place
  • Operate without looking: top-mount knobs and the emergency key sit where gloved hands can find them

The Sonim XP5plus is a rugged push-to-talk phone for professionals who need cellular coverage with the reliability of a radio. Typical users are field crews, public safety teams and industrial workers who don't need smartphone extras. This SKU comes in black with top-mount knobs for volume and channel control, alongside an easy-access emergency key, for no-look operation. The large PTT button works with work gloves on, and three dynamic front buttons make the 2.8-inch Gorilla Glass 3 display easier to use.

Sonim builds the XP5plus to its Rugged Performance Standards: - IP68 and IPX9K rated; submersible to 6.5 feet for 30 minutes - Survives 6.5 ft drops onto concrete and up to 4J of impact energy - Withstands up to one metric ton of pressure - Resists petroleum oils and corrosive cleaning agents, and can be disinfected with detergent, bleach and rubbing alcohol - Tested to MIL-STD-810H - Non-Incendive Class I, II and III Div 2 certified - Operates from -4°F to 131°F

Dual front-facing speakers deliver 100dB+ output. Dual microphones with Goodix echo and noise cancellation keep voice clear on loud sites. The SecureAudio Connector locks remote speaker mics and other audio accessories in place. Inside is a Qualcomm SM6115 octa-core chipset running Sonim's OS, which is based on AOSP Android 11. It has 2GB RAM, 16GB ROM and microSD support up to 512GB. Dual nano-SIM slots cover LTE bands including 12, 13, 14, 66 and 71. VoLTE, RTT, Wi-Fi 802.11ac with hotspot support for up to 10 connections, and Bluetooth 5.0 round out connectivity. Sonim SCOUT and Push-to-Talk come preloaded.

The removable 3500mAh battery is rated for 30 hours of talk and 600 hours of standby. Sonim backs the XP5plus with a 3-year warranty and SonimCare support, and offers FirstCare for FirstNet customers. SonimWare tools help teams install and manage the fleet. Sonim publishes datasheets, user guides and brochures for the XP5plus.

Ideal for

  • Firefighters and public safety teams using push-to-talk over cellular
  • Oil, gas and chemical sites that require Class I, II and III Div 2 non-incendive devices
  • Construction, utilities and manufacturing crews working with gloves in high-noise environments
  • Replacing or supplementing two-way radios with LTE push-to-talk
  • Food processing and healthcare settings where devices are washed down or disinfected

Specifications

Audio

Hac
M3/T4 Hearing Aid Compatible
Speaker
Dual front-facing loud speakers, 100dB+ output
Microphone
Dual mic solution with Goodix noise and echo cancellation

Battery

Capacity
3500mAh Li-Ion, removable
Talk Time
30 hours
Standby Time
600 hours

Display

Colors
262K colors
Size Type
2.8" TFT, Gorilla® Glass 3
Resolution
240 x 320

General

MPN
F16CDP1-132-000
UPC
096962277864
Brand
Sonim
Color
Black
Model
Sonim XP5plus
Network
4G LTE
Warranty
3-year warranty
Configuration
With top-mount knobs

Package

Shipping Weight
1.05 lb shipping weight

Physical

Ports
USB-C, SecureAudio™ Connector, charging pins
SIM Type
Dual 4FF Nano SIM
Dedicated Keys
PTT key, volume keys, emergency key
Size With Knobs
163.7 x 65.9 x 21 mm
Weight With Knobs
284 g (with knobs)
Hazardous Location
Class I, Div 2, Groups A, B, C, D; Class II, Div 2, Groups F, G; Class III, Div 2
Size Without Knobs
148.7 x 65.9 x 21 mm
Weight Without Knobs
275 g (without knobs)
Operating Temperature
-4°F to 131°F / -20°C to 55°C
Rugged Certifications
MIL-STD-810H; IP68, IPX9K

IN The Box

Accessories
Battery, battery cover, wall charger, USB-C cable, screwdriver, SIM card, quick start guide, accessory guide

Multimedia

Camera
8MP camera with flash
FM Radio
Yes (requires wired headset for antenna)
Flashlight
Yes
Media Player
Yes
Audio Formats
AMR-NB, AMR-WB, AAC, AAC+, AAC+V2, MP3, FLAC, APTX, Vorbis
Video Capture
Video capture/playback up to 1080p
Video Formats
3GPP, MP4, AVI, MOV, MPEG-4, VP8, VP9, H.263, H.264, H.265
Graphic Formats
JPEG, PNG, BMP, GIF, WebP, HEIF

Connectivity

GPS
GPS/A-GPS, GLONASS, Galileo, BD
Rtt
Yes
Volte
Yes
Sensors
Barometer, Accelerometer
Bluetooth
Bluetooth 5.0 with BLE
Languages
English, Spanish
Messaging
SMS, MMS (Text, Image, Audio, Video)

Core Platform

Memory
2GB RAM / 16GB ROM
Chipset
Qualcomm SM6115 Octa-core 4x 2.0GHz, 4x 1.8GHz
Hotspot
Supports up to 10 hotspot connections
Gsm Bands
850/900/1800/1900MHz
LTE Bands
B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B25/B26/B29/B30/B39/B40/B41/B66/B71
Umts Bands
B1/B2/B4/B5
User Memory
10GB available user memory
Wi-Fi Standard
Wi-Fi 802.11 a/b/g/n/ac
Wi-Fi Frequency
2.4/5GHz
External Memory
Supports up to 512GB microSD
Operating System
Sonim Proprietary OS (based on AOSP Android 11)
Preloaded Applications
Sonim SCOUT, Push-to-Talk

Questions buyers ask

What do the knobs on this XP5plus do?

This SKU has top-mount knobs for volume and channel control. Together with the easy-access emergency key and the large PTT button, they allow no-look operation similar to a radio.

Is the Sonim XP5plus a 5G phone?

No. The XP5plus is a 4G LTE phone. It supports LTE bands including B2, B4, B12, B13, B14, B66 and B71, plus UMTS and GSM, with dual nano-SIM slots, VoLTE and RTT.

Can the XP5plus be used in hazardous locations?

It is certified Non-Incendive for Class I, Div 2, Groups A, B, C, D; Class II, Div 2, Groups F, G; and Class III, Div 2.

How long does the battery last, and can it be replaced?

The 3500mAh Li-ion battery is user-removable. It is rated for up to 30 hours of talk time and 600 hours of standby.

What comes in the box?

The box includes the battery, battery cover, wall charger, USB-C cable, screwdriver, SIM card, quick start guide and accessory guide.
