ZebraPhones

Zebra TC701 5G Rugged Mobile Computer with Wi-Fi 7, 8GB/128GB, AC670 Long-Range Imager

5GMPN TC701G-321E1A1A01-NA
  • 128 GB
  • 8 GB
  • Rugged
$2,925.31$4,255.00Save $1,329.69

In stockShips from the US

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Zebra TC701 (TC701G-321E1A1A01-NA) is an ultra-rugged 6-inch Android mobile computer for delivery, field service, warehouse and retail teams. This North America configuration pairs 5G WWAN and Wi-Fi 7 with a Qualcomm Dragonwing Q-6690 at 2.0 GHz, 8 GB RAM and 128 GB flash. It adds the AC670 advanced long-range color imager, which captures barcodes and color photos up to 100 ft (30 m) away. It also has a 50 MP rear camera, an 8 MP front camera, a hot-swappable standard battery and a Secure Element.

  • 5G NR Sub-6 (NSA/SA, Release 17) WWAN plus tri-band Wi-Fi 7 and Bluetooth 6.0
  • Qualcomm Dragonwing Q-6690 at 2.0 GHz with 8 GB LPDDR5 RAM and 128 GB UFS 3.1 flash
  • AC670 advanced range color imager that captures barcodes and color photos up to 100 ft (30 m)
  • 6.0-inch Full HD+ AMOLED display, 1500 nits peak, Gorilla Glass Victus
  • Integrated UHF RFID (over 200 tags/sec up to 2 m), NFC with contactless payment support
  • 12 ft drop, 3,500 tumbles, IP68/IP65 sealing
  • Hot-swappable 5000 mAh standard battery with fast charging; Secure Element and Android Strongbox
  • Scan pallets, racking labels and overhead stock from up to 100 ft away without a ladder or lift

The Zebra TC701 is the most rugged handheld in Zebra's TC7 Series. It replaces the TC72 and TC77, and this TC701G-321E1A1A01-NA configuration is built for North America. The Qualcomm Dragonwing Q-6690 has a dedicated AI engine and runs at 2.0 GHz in this SKU, with 8 GB LPDDR5 RAM and 128 GB UFS 3.1 flash. A user-accessible microSD slot supports cards up to 2 TB. The 6.0-inch Full HD+ AMOLED display reaches 1500 nits peak and sits under Gorilla Glass Victus. It works with bare or gloved fingers and rejects water droplets.

Data capture is the reason to choose this SKU. The AC670 advanced range color scan engine reads barcodes and captures high-resolution color photos up to 100 ft (30 m) away. Every TC701 also includes short-range UHF RFID that reads more than 200 tags per second at up to 6.5 ft (2 m). NFC supports EMVCo contactless payment, Apple VAS and Google Smart Tap. The 50 MP auto-focus rear camera and 8 MP front camera round out capture.

Connectivity covers 5G NR Sub-6 (NSA and SA) on Release 17, Gigabit LTE-A, private cellular and CBRS. The radio takes one physical SIM plus dual eSIM with Dual SIM/Dual Standby. Wi-Fi 7 runs tri-band with MLO, and the device also has Bluetooth 6.0 and triple-band GNSS. Voice support includes VoNR, VoLTE and push-to-talk, with a dedicated PTT button.

The TC701 exceeds MIL-STD-810H with 12 ft (3.66 m) drops to concrete at room temperature and 3,500 1 m tumbles. It is sealed to IP68 and IP65 and operates from -4°F to +122°F. The standard 5000 mAh battery is hot-swappable, and Secure Element with Android Strongbox protects the hardware. Zebra's spec sheet, Quick Start Guide and Product Reference Guide are available for this model.

Ideal for

  • Warehouse picking, put-away and inventory counts with long-range scanning of high racking
  • Proof of pickup and delivery, last-mile routing and package dimensioning for parcel carriers
  • Field service documentation, parts inventory and mobile POS
  • Retail price checks, backroom inventory and BOPIS order fulfillment
  • Airline baggage reconciliation and asset management

Specifications

Power

Hot Swap
Hot swap capable
Battery Type
Rechargeable Li-Ion with PowerPrecision+ real-time metrics
Fast Charging
Fast charging, 0 to 70% in 45 minutes (with fast charging options)
Battery Capacity
Standard battery: 5000 mAh (19.45 Wh)
Extended Battery Option
Optional extended battery: 7240 mAh (28.16 Wh)

Display

Size
6.0 in (15.2 cm)
Type
AMOLED, optically bonded, adaptive refresh rate
Brightness
600 nits typical, 1000 nits HBM, 1500 nits peak
Resolution
2160 x 1080 Full HD+
Cover Glass
Corning Gorilla Glass Victus
Touch Panel
Capacitive, glove and passive-stylus capable, water droplet rejection, anti-smudge

General

MPN
TC701G-321E1A1A01-NA
Brand
Zebra Technologies
Model
TC701 Mobile Computer
Region
North America (NA) SKU
Replaces
Replaces TC72, TC77
IN The Box
Mobile computer, Regulatory Guide, Quick Start Guide
Operating System
Android (supported versions listed at zebra.com/android-versions)

Sensors

Interactive Sensor Technology
Light, motion, eCompass, barometer, proximity sensors

Physical

SIM
1 physical SIM + dual eSIM
Keypad
On-screen keypad
Weight
10.02 oz (284 g) with 5000 mAh battery
Buttons
Programmable dual scan, PTT and volume buttons
Dimensions
6.5 x 3.07 x 0.61 in (165.0 x 77.9 x 15.5 mm)
Imager Window
Corning Gorilla Glass
Notifications
Audible tone, multi-color LEDs, vibration
Expansion Slot
User-accessible microSD, up to 2 TB
Interface Ports
USB-C (USB 3.1), back I/O USB 2.0

Compliance

Warranty
1 year from shipment, per Zebra hardware warranty statement
Environmental
RoHS, REACH, EPEAT Certified
Recommended Services
Zebra OneCare Essential/Select, VisibilityIQ Foresight

Performance

CPU
Qualcomm Dragonwing Q-6690 with integrated AI engine
RAM
8 GB LPDDR5 RAM
Storage
128 GB UFS 3.1 Flash
Security
Secure Element, Android Strongbox, FIPS 140-3, Common Criteria, Secure Boot and Verified Boot
Clock Speed
2.0 GHz (this SKU)

Voice Audio

Voice And Audio
Stereo speakers, dual mics, VoNR, VoLTE, HD voice, PTT

Data Capture

NFC
NFC with contactless payment and wallet support
Rfid
Integrated UHF RFID, >200 tags/sec up to 2 m
Rear Camera
50 MP auto focus, flash LED, Torch mode and HDR
Scan Engine
AC670 advanced range color imager, barcodes and color photos up to 100 ft (30 m)
Front Camera
8 MP fixed focus

Wireless LAN

Radio
Wi-Fi 7 tri-band, 2x2 MU-MIMO, MLO
Security
WPA3 incl. 192-bit Enterprise, WPA2, OWE, EAP-SIM/AKA
Fast Roam
802.11r, PMK caching, Cisco CCKM, OKC
Data Rates
Up to 344 Mbps (2.4 GHz), 2882 Mbps (5 GHz), 5764 Mbps (6 GHz, 320 MHz)
Multimedia
WMM, WMM-PS, TSPEC
Certifications
Wi-Fi Alliance certified: Wi-Fi 7, 6E, Voice-Enterprise, Passpoint and more
Operating Channels
2.4, 5 and 6 GHz channels; 20-320 MHz bandwidth (subject to regulatory rules)

Wireless Pan

Bluetooth
Bluetooth 6.0 with BLE beaconing

Wireless WAN

GNSS
Triple-band GNSS with a-GPS and XTRA
Radio
5G NR Sub-6 NSA/SA Rel-17, Gigabit LTE-A, DSDS
Bands 2g
rest-of-world SKUs only (not this NA SKU)
Bands 3g
B1/2/4/5/6/8/19
Bands 4G
4G LTE: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/34/38/39/40/41/42/43/48/53/66/68/70/71/106
Bands 5G
5G FR1: n1/2/3/5/7/8/12/13/14/20/25/26/28/29/30/38/40/41/48/53/66/70/71/75/76/77/78/79
MIMO 4x4 DL
4x4 DL MIMO on listed 5G and LTE bands
Private Cellular
B48/53/106/68; CBRS (US only)

User Environment

Esd
±15 kV air, ±8 kV direct/indirect
Drop
12 ft (3.66 m) to concrete; 8 ft across operating temperature
Tumble
3,500 1.0 m tumbles
Sealing
IP68 and IP65 per IEC 60529
Humidity
5% to 95% non-condensing
Storage Temp
-40°F to +158°F (-40°C to +70°C)
Operating Temp
-4°F to +122°F (-20°C to +50°C)

Questions buyers ask

Is this TC701 configuration for the US market?

Yes. TC701G-321E1A1A01-NA is the North America SKU. It supports CBRS (US only), and 2G is limited to rest-of-world SKUs.

How far can the AC670 imager scan?

The AC670 advanced range color scan engine captures barcodes and high-resolution color photos up to 100 ft (30 m) away.

Can I change the battery without shutting down?

Yes. The standard 5000 mAh Li-Ion battery is hot-swappable, and fast charging options take a battery from 0 to 70% in 45 minutes.

Does it need a separate RFID sled?

No. Every TC701 has integrated short-range UHF RFID that reads more than 200 tags per second at up to 6.5 ft (2 m).

What SIM options does it support?

It takes one physical SIM and dual eSIM, with Dual SIM/Dual Standby. It also supports private cellular on B48/53/106/68.
