Zebra TC78 5G Rugged Mobile Computer with SE55 Scanner, Wi-Fi 6E and CBRS, 8GB/128GB (North America)

5GMPN TC78A1-3T1K6B1A10-NA
  • 128 GB
  • Rugged
$4,735.65$5,550.72Save $815.07

In stockShips from the US

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Zebra TC78 (TC78A1-3T1K6B1A10-NA) is a rugged Android mobile computer for workers who spend the day outdoors and on the move. This North America Standard configuration pairs sub-6 5G and CBRS private LTE with Wi-Fi 6E. It runs on a Qualcomm 6490 octa-core processor with 8 GB RAM and 128 GB UFS flash. The SE55 Advanced Range scan engine reads 1D/2D barcodes in hand or up to 40 ft away. It is built for 10 ft drops to concrete with IP65 and IP68 sealing.

  • Sub-6 5G WWAN with CBRS private LTE/5G support (US), Nano SIM plus eSIM
  • Wi-Fi 6E 2x2 MU-MIMO and Bluetooth 5.2
  • SE55 1D/2D Advanced Range scan engine with IntelliFocus, reading up to 40 ft (12.2 m)
  • Qualcomm 6490 octa-core 2.7 GHz processor with 8 GB RAM, 128 GB UFS flash and microSD up to 2 TB
  • 6.0-inch Full HD+ (1080 x 2160) Gorilla Glass touch display usable wet, gloved or with stylus
  • 10 ft drops to concrete per MIL-STD 810H, 2,000 tumbles, IP65 and IP68 sealing
  • 4680 mAh fast-charging Li-Ion battery with PowerPrecision+ metrics and warm swap
  • Keep drivers and field crews connected outdoors on 5G, and switch to Wi-Fi 6E inside depots and warehouses

The Zebra TC78 is Zebra's ultra-rugged 5G handheld mobile computer and the successor to the TC77. It is built for couriers, route drivers, field service teams and warehouse staff who need one device for scanning, voice, apps and data. This SKU, TC78A1-3T1K6B1A10-NA, is the Standard-tier North America configuration. It has sub-6 5G with CBRS support, Wi-Fi 6E, a 6.0-inch display, 8 GB RAM, 128 GB flash, the SE55 scan engine and an 8 MP front camera.

The Qualcomm 6490 octa-core processor runs at 2.7 GHz, and a user-accessible microSD slot accepts cards up to 2 TB. The 6.0-inch Full HD+ (1080 x 2160) display is optically bonded and covered in Corning Gorilla Glass. It works when wet and responds to a bare or gloved finger or a conductive stylus. The SE55 Advanced Range engine with IntelliFocus captures barcodes from in hand to as far as 40 ft (12.2 m), depending on symbology type and size. A 16 MP autofocus rear camera with flash handles proof-of-delivery and proof-of-condition photos.

Connectivity covers indoor and outdoor work. On North American networks it supports 5G FR1, 4G, 3G and 2G bands, plus CBRS private LTE/5G in the US. It has a Nano SIM and an eSIM, 2x2 MU-MIMO Wi-Fi 6E and Bluetooth 5.2. Dual-band GNSS provides accurate location. For voice work, it has noise-suppressing microphones, dual speakers, HD Voice, VoLTE EVS and a dedicated push-to-talk button.

The TC78 is rated for multiple 10 ft drops to concrete per MIL-STD 810H and 2,000 1 m tumbles. It carries IP65 and IP68 sealing and operates from -4° F to 122° F. The 4680 mAh standard battery fast-charges over USB-C and supports warm swap. It is TAA compliant and ships with a Quick Start Guide and Regulatory Guide. Zebra's spec sheet, accessory guide and Product Reference Guide document the platform. Zebra warrants the TC78 for 1 year from the date of shipment.

Ideal for

  • Parcel delivery with proof of pickup and delivery photos and signatures
  • Direct store delivery and route accounting on 5G
  • Warehouse and distribution scanning of high-shelf labels up to 40 ft away
  • Airline under-wing asset management and track-and-trace
  • Field service and field operations teams using voice, push-to-talk and enterprise apps

Specifications

General

MPN
TC78A1-3T1K6B1A10-NA
Brand
Zebra Technologies
Model
Zebra TC78 Mobile Computer
Replaces
Replaces Zebra TC77

Package

IN The Box
TC78 mobile computer, Regulatory Guide, Quick Start Guide
Shipping Weight
5.00 lb shipping weight
Battery Included
Battery included

Sensors

Gyro
Gyroscope
Light Sensor
Ambient light sensor
Magnetometer
Magnetometer
Motion Sensor
3-axis accelerometer with MEMS gyro
Pressure Sensor
Pressure sensor (altitude)
Proximity Sensor
Proximity sensor

Support

Warranty
1-year Zebra hardware warranty
Mobility Dna
Zebra Mobility DNA software tools
Product Lifecycle
5 years availability, 10 years support
Recommended Services
Zebra OneCare Essential/Select, VisibilityIQ Foresight

Data Capture

NFC
NFC with HCE, contactless payment, Apple VAS and Google Smart Tap
Camera
8 MP front, 16 MP autofocus rear with flash and HDR
Scanning
SE55 1D/2D, up to 40 ft (12.2 m)

Wireless LAN

Radio
Wi-Fi 6E 802.11ax, 2x2 MU-MIMO, dual band simultaneous
Fast Roam
PMKID, CCKM, 802.11r, OKC
Data Rates
Up to 2402 Mbps (5/6 GHz), 286.8 Mbps (2.4 GHz)
Certifications
Wi-Fi Alliance: Wi-Fi 6, WPA3, Voice-Enterprise, Agile Multiband and more
Operating Channels
2.4, 5 and 6 GHz channels; 20/40/80/160 MHz bandwidth
Security And Encryption
WPA2/WPA3 Personal and Enterprise (192-bit), EAP-SIM/AKA, OWE

Wireless Pan

Bluetooth
Bluetooth 5.2 Class 2, BLE beaconing (BLE battery)

Wireless WAN

CBRS
CBRS (US only)
GNSS
Dual-band GNSS (GPS, GLONASS, Galileo, BeiDou, QZSS), a-GPS, XTRA
Multimedia
WMM and WMM-PS with TSPEC
Private Networking
Private LTE/5G support
North America 2g Bands
2G (NA): 850/1900 MHz
North America 3g Bands
3G (NA): B2/4/5
North America 4G Bands
4G LTE (NA): B2/4/5/7/12/13/14/17/25/26/29/38/41/48/66/71
North America 5G Bands
5G FR1 (NA): n2/5/7/12/13/14/25/26/29/38/41/48/66/71/77/78
China Japan Variant Bands
China/Japan TC78 variant bands (not this NA SKU)
Rest OF World Variant Bands
Rest of World TC78 variant bands (not this NA SKU)

Certifications

General
TAA compliant, ARCore certified
Environmental
RoHS compliant

User Environment

Esd
±15 kV air, ±8 kV direct/indirect discharge
Sealing
IP65 and IP68 (with battery)
Humidity
5%–95% non-condensing
Vibration
4 g PK sine, 0.04 g²/Hz random, 60 min per axis, 3 axes
Drop Specification
10 ft (3.05 m) drops to concrete; 8 ft (2.4 m) across operating temp; MIL-STD 810H
Storage Temperature
-40° F to 158° F (-40° C to 70° C)
Tumble Specification
2,000 x 1.0 m tumbles (IEC)
Operating Temperature
-4° F to 122° F (-20° C to 50° C)

Sku Configuration

Tier
Standard tier
Radios
Sub-6 5G WAN with CBRS; Wi-Fi 6E
Region
North America
Scan Engine
SE55 Advanced Range scan engine
Display Size
6.0 in display
Front Camera
8 MP front camera
Memory Storage
8 GB RAM / 128 GB UFS flash

Physical Characteristics

SIM
1 Nano SIM + 1 eSIM
Power
Li-Ion with PowerPrecision+; standard 4680 mAh (18.01 Wh), optional extended 7000 mAh, BLE and Qi wireless batteries; fast charging; warm swap on standard SKUs
Keypad
On-screen keypad and Zebra Enterprise Keyboard
Weight
12.3 oz (349 g) with standard battery
Buttons
Dual scan buttons, push-to-talk, volume, Trigger Handle support (all programmable)
Display
6.0 in Full HD+ 1080 x 2160, LED backlight, optically bonded
Grip Area
3.179 in W x 0.80 in H (80.75 x 20.3 mm)
Dimensions
6.96 in L x 3.38 in W x 1.12 in H (176.8 x 85.8 x 28.4 mm)
Touch Panel
Multi-mode capacitive touch, glove and stylus capable, Gorilla Glass, water droplet rejection, anti-smudge
Imager Window
Corning Gorilla Glass imager window
Notifications
Audible tone, multi-color LEDs, haptic feedback
Expansion Slot
microSD, up to 2 TB
Interface Ports
USB 2.0 Back I/O (host) + USB-C 3.0 SuperSpeed (host/client)
Voice And Audio
Noise-suppression mics, dual speakers, speakerphone, HD Voice, VoLTE EVS, VoIP with SWB audio, wired PTT and Bluetooth headsets
Network Connections
WWAN 5G, WLAN, Bluetooth

Performance Characteristics

CPU
Qualcomm 6490 octa-core 2.7 GHz
RAM
8 GB RAM
Storage
128 GB UFS flash
Security
Secure Boot and Verified Boot; FIPS 140-2 via custom SKU
Operating System
Android

Questions buyers ask

Is this TC78 built for US networks?

Yes. The -NA suffix marks the North America configuration. It supports North American 5G FR1 bands including n2, n5, n41, n66, n71 and n77, plus LTE bands such as B2, B4, B12, B13, B66 and B71. CBRS support applies in the US.

How far can the SE55 scanner read barcodes?

The SE55 Advanced Range engine with IntelliFocus captures 1D and 2D barcodes from in hand to as far as 40 ft (12.2 m). Actual distance depends on symbology type and size.

Can I swap the battery without shutting down?

This Standard-tier SKU supports warm swap battery mode. It includes a 4680 mAh standard battery, and the batteries are fast charging over any standard USB-C cable. Zebra also offers extended 7000 mAh, BLE and Qi wireless-charge batteries for the TC78.

How rugged is the TC78?

It withstands multiple 10 ft (3.05 m) drops to concrete per MIL-STD 810H and 2,000 1 m tumbles. It carries IP65 and IP68 sealing and operates from -4° F to 122° F (-20° C to 50° C).

What comes in the box?

The mobile computer with its battery, a Regulatory Guide and a Quick Start Guide. Zebra's spec sheet, accessory guide and Product Reference Guide cover setup and accessories.
