ZebraPhones

Zebra TC27 5G Mobile Computer with SE4710 Scanner, 8GB/128GB, BLE Battery, 8-Pin, North America

5GMPN WCMTA-T27B8ABD8-NA
  • 128 GB
  • Rugged
$1,470.85$2,162.00Save $691.15

In stockFree 2-day shipping

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The Zebra TC27 (WCMTA-T27B8ABD8-NA) is a 5G Android mobile computer for field and retail teams. This North America configuration pairs the SE4710 1D/2D scan engine with 8 GB RAM and 128 GB flash on a 6 in. Full HD+ display. It also has a 3800 mAh BLE battery that supports device locating with Zebra Device Tracker, an 8-pin rear connector, NFC tap-to-pay, and a Nano SIM plus eSIM.

  • 5G NR Sub-6 (NSA/SA), Gigabit LTE-A and VoLTE with 1 Nano SIM + 1 eSIM, plus private 5G and CBRS support (US only)
  • SE4710 1D/2D scan engine with dual dedicated scan buttons
  • 8 GB RAM / 128 GB UFS flash on a Qualcomm 5430 hex-core 2.1 GHz CPU, microSD up to 2 TB
  • 3800 mAh / 14.63 Wh removable BLE battery with secondary BLE beaconing
  • 6.0 in. FHD+ (1080 x 2160) 450-nit display with Corning Gorilla Glass
  • NFC with contactless payment support, Apple VAS and Google Smart Tap certified
  • IP68/IP65 sealing and MIL-STD-810H drop testing; 8-pin rear connector
  • Run heavier app stacks and store more offline data with 8 GB RAM and 128 GB flash

The Zebra TC27 is the 5G model of Zebra's third-generation TC2x Series and the successor to the TC26. SKU WCMTA-T27B8ABD8-NA is the higher-memory North America build. It combines 8 GB RAM and 128 GB UFS flash with the SE4710 1D/2D scan engine, 16 MP rear and 5 MP front cameras, an 8-pin rear connector and Google Mobile Services. A microSD slot accepts cards up to 2 TB.

This configuration uses the 3800 mAh / 14.63 Wh BLE battery. It carries a secondary Bluetooth Low Energy radio for beaconing, so missing devices can be tracked and located even when the battery is dead. That capability requires a separate Zebra Device Tracker licence. Like every TC27 battery, it is user-removable, so a device does not have to leave service to charge.

For connectivity, the TC27 offers: - 5G NR Sub-6 (NSA and SA), Gigabit LTE-A, VoLTE and dual SIM/dual standby using one Nano SIM and one eSIM - Private 5G and CBRS private LTE support (CBRS in the US only) - 2x2 MU-MIMO Wi-Fi 6, with Wi-Fi 6E enabled through the Mobility DNA Enterprise License - Bluetooth 5.2

NFC supports contactless payments and is Apple VAS and Google Smart Tap certified. A programmable button can be assigned to push-to-talk.

A Qualcomm 5430 hex-core 2.1 GHz processor drives a 6.0 in. 1080 x 2160, 450-nit display under Corning Gorilla Glass. The device is sealed to IP68 and IP65 and drop-tested to MIL-STD-810H, and it operates from 14°F to 122°F. Mobility DNA Professional tools are preloaded at no cost for staging, app control and barcode-to-app data entry.

Ideal for

  • Courier and last-mile delivery with proof-of-delivery photos and payment on delivery
  • Field service and facilities teams running data-heavy apps offline
  • Retail inventory, price checks, click-and-collect and mPOS
  • Staff communications with push-to-talk on the programmable button
  • Fleets that need BLE-based device locating with Zebra Device Tracker

Specifications

General

MPN
WCMTA-T27B8ABD8-NA
Brand
Zebra Technologies
Model
Zebra TC27 Mobile Computer
Region
NA (North America) configuration
Replaces
Replaces Zebra TC26
IN The Box
TC27 Mobile Computer
Sku Radios
WWAN 5G, Wi-Fi 6, Bluetooth, NFC
Sku Back I/O
8-pin rear connector
Sku Battery
Standard 3800 mAh battery with BLE
Sku Software
Google Mobile Services (GMS)
Sku Scan Engine
SE4710 1D/2D scan engine

Services

Recommended Services
Zebra OneCare Special Value (SV); Zebra VisibilityIQ Foresight; Professional Services Video on Device

Software

Mobility Dna
Mobility DNA Professional preloaded and pre-licensed at no cost; full Mobility DNA suite requires Mobility DNA Enterprise License; Device Tracker requires a separate licence

Warranty

Hardware Warranty
1 year from date of shipment against defects in workmanship and materials, per Zebra hardware warranty statement

Compliance

General Certifications
ARCore Google certified
Environmental Compliance
RoHS Directive 2011/65/EU, Amendment 2015/863; REACH SVHC 1907/2006

Data Capture

NFC
NFC ISO 14443 Type A and B; Mifare, FeliCa and ISO 15693 cards; NFC Forum tags 2, 3, 4, 5; Host Card Emulation; contactless payment support; VAS and wallet support; Apple ECP1.0 and ECP2.0; Apple VAS and Google Smart Tap certified; VAS Library/SDK
Scanning
SE4710 1D/2D scan engine
Uhf Rfid
Supports RFD40 UHF RFID Sled and RFD90 Ultra-Rugged UHF RFID Sled
Rear Camera
16 MP rear camera
Front Camera
5 MP front camera

Wireless LAN

Fast Roam
PMKID caching; Cisco CCKM; 802.11r; OKC
Data Rates
6 GHz 802.11ax 20/40/80/160 MHz up to 2402 Mbps; 5 GHz 802.11a/n/ac/ax 20/40/80/160 MHz up to 2402 Mbps; 2.4 GHz 802.11b/g/n/ax 20 MHz up to 286.8 Mbps
Wlan Radio
IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax; 2x2 MU-MIMO; Wi-Fi 6 Certified; Wi-Fi 6E (802.11ax, requires Mobility DNA Enterprise License); dual band simultaneous; IPv4, IPv6
Certifications
Wi-Fi CERTIFIED n, ac and 6; Enhanced Open; WPA2/WPA3 Personal and Enterprise (incl. 192-bit); Protected Management Frames; Agile Multiband; WMM, WMM-Power Save, WMM Admission Control; Voice-Enterprise; Wi-Fi Direct; QoS Management; OCE
Operating Channels
Channel 1-13 (2401-2483 MHz); Channel 36-165 (5150-5850 MHz); Channel 1-233 (5925-7125 MHz); bandwidth 20/40/80/160 MHz; actual channels depend on regulatory rules
Security Encryption
WEP (40/104 bit); Enhanced Open (OWE); WPA/WPA2 Personal (TKIP, AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP, AES); WPA3 Enterprise (AES) with EAP-TTLS, EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3 Enterprise 192-bit (GCMP256) EAP-TLS; EAP-SIM, EAP-AKA, EAP-AKA Prime on WWAN models

Wireless Pan

Bluetooth
Class 2, Bluetooth v5.2; secondary BLE for beaconing within BLE battery

Wireless WAN

GNSS
GPS, GLONASS, Galileo, BeiDou, QZSS; dual-band GNSS concurrent L1/G1/E1/B1 + L5/E5a/BDSB2a; a-GPS; supports XTRA
3g Bands
North America 3G: B2/4/5
4G Bands
North America 4G: B2/4/5/7/12/13/14/17/25/26/29/38/41/48/66/71
5G Bands
North America 5G FR1: n2/5/7/12/13/14/25/26/29/38/41/48/66/71/77/78
Wwan Features
Dual SIM/Dual Standby, VoLTE, Gigabit LTE-A, 5G NR Sub-6 (NSA, SA), LTE/NR carrier aggregation, private networking (LTE/5G)
Private Networks
5G private network and CBRS private LTE (CBRS US only)

User Environment

Esd
+/-15 kV air discharge, +/-8 kV direct discharge, +/-8 kV indirect discharge
Sealing
IP68 and IP65, with battery, per applicable IEC sealing specifications
Humidity
5% - 95% non-condensing
Drop Spec
Multiple 5 ft./1.5 m drops to concrete over operating temp with protective boot per MIL-STD-810H; multiple 4.5 ft/1.3 m drops to tile over concrete over operating temp per MIL-STD-810H
Tumble Spec
500 tumbles, 1.6 ft./0.5 m; 500 tumbles, 3.3 ft./1.0 m with optional protective boot
Storage Temperature
-40°F to 158°F / -40°C to 70°C
Operating Temperature
14°F to 122°F / -10°C to 50°C

Physical Characteristics

SIM
1 Nano SIM and 1 eSIM
Audio
Two microphones with noise cancellation; dual speakers; Bluetooth wireless headset support; high quality speakerphone; PTT headset (Zebra USB-C) support; HD Voice incl. Super-wideband, Wideband and Fullband
Power
User removable, rechargeable Li-Ion, PowerPrecision real-time battery metrics; BLE battery: 3800 mAh / 14.63 Wh
Keypad
On-screen keypad
Weight
Published: 8.32 oz/236 g (TC22 with 3800 mAh battery); 9.24 oz/262 g with 5200 mAh battery
Buttons
Dual dedicated scan buttons; programmable button for PTT or other use; volume up/down; power
Display
6.0 in. color Full High Definition+ (1080 x 2160); LED backlight; 450 nits; Corning Gorilla Glass
Dimensions
6.5 in. L x 3.0 in. W x 0.49 in. D; 165 mm L x 76.3 mm W x 12.5 mm D
Touch Panel
Multi mode capacitive touch with bare or light gloved fingertip input
Imager Window
Corning Gorilla Glass
Notifications
Audible tone; multi-color LEDs; vibration
Expansion Slot
User accessible microSD card, supports up to 2 TB
Interface Ports
USB 3.1 (bottom Type-C) SuperSpeed, host and client; 8-pin rear connector
Network Connections
WWAN, WLAN, WPAN

Performance Characteristics

CPU
Qualcomm 5430 hex-core, 2.1 GHz
Memory
8 GB RAM / 128 GB UFS Flash
Operating System
Android with GMS; supported versions listed at zebra.com/android-versions

Interactive Sensor Technology

Light Sensor
Automatically adjusts display backlight brightness
Magnetometer
eCompass to detect direction
Motion Sensor
3-axis accelerometer with MEMS gyro
Pressure Sensor
Altitude for locating (TC27 North America)
Proximity Sensor
Disables display and touch input when held to the head during calls

Questions buyers ask

What does the BLE battery do?

It is a 3800 mAh / 14.63 Wh removable battery with a secondary Bluetooth Low Energy radio for beaconing. With a separately licensed Zebra Device Tracker, missing devices can be located even when the battery is dead.

How much memory does WCMTA-T27B8ABD8-NA have?

It has 8 GB RAM and 128 GB UFS flash, and a user-accessible microSD slot supports cards up to 2 TB.

Which scanner is in this model?

It uses the Zebra SE4710 1D/2D scan engine, operated with dual dedicated scan buttons.

Does the TC27 support Wi-Fi 6E?

The WLAN radio is Wi-Fi 6 certified. Wi-Fi 6E operation in the 6 GHz band requires the Mobility DNA Enterprise License.

Is this model intended for North America?

Yes. The -NA suffix denotes the North America configuration, which supports 5G bands n2/5/7/12/13/14/25/26/29/38/41/48/66/71/77/78 and LTE bands B2/4/5/7/12/13/14/17/25/26/29/38/41/48/66/71.
