InHand Networks IR315 Industrial 4G LTE Cat 6 Router with 5 Ethernet Ports and I/O (North America)

4G LTEMPN IR315-FF39
$200.46$239.00Save $38.54

Backordered · ships as soon as it arrives

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The InHand Networks IR315-FF39 is a multi-port industrial router for unattended sites and IoT networks in North America. It combines an LTE Cat 6 cellular module, including Bands 66 and 71, with dual Nano-SIM switching. It has five 10/100 Mbps RJ45 ports with 1.5 kV isolation and four configurable DI/DO channels. The router also supports OSPF, VRRP and a full VPN suite. The fanless IP30 metal enclosure mounts on a DIN rail and runs on 9-36V DC.

  • North American LTE Cat 6 cellular module including Bands 66 and 71
  • Five 10/100 Mbps RJ45 ports with WAN/LAN/VLAN roles and 1.5 kV isolation protection
  • 4 configurable DI/DO channels with edge-triggered status reporting
  • Dual Nano-SIM switching on signal, packet-loss and dial-failure thresholds; cellular/WAN link backup and VRRP
  • Static and OSPF routing; IPsec (up to 10 tunnels), DMVPN, OpenVPN, WireGuard, ZeroTier, GRE, L2TP, PPTP
  • Fanless IP30 metal enclosure, DIN rail mount, 9-36V DC, -35°C to 70°C (extended -40°C to 75°C)
  • Connect a whole cabinet of controllers, cameras and HMIs through five isolated Ethernet ports without a separate switch
  • Monitor alarms and drive relays directly from the router using four DI/DO channels that report to the cloud

The IR315 is InHand Networks' multi-port industrial router for industrial and commercial IoT deployments that need several wired devices on one cellular uplink. The IR315-FF39 is the North American LTE Cat 6 configuration with I/O. Its cellular module includes LTE Bands 66 and 71. The FF39 holds PTCRB and IC certificates, and the IR315 family certifications include FCC, AT&T, Verizon, T-Mobile, UL and C1D2. This base configuration has no Wi-Fi, serial or GNSS options. It uses the default I/O interface.

The five 10/100 Mbps RJ45 ports have 1.5 kV isolation-transformer protection and can be assigned as WAN, LAN or VLAN in Access or Trunk mode. The WAN port supports Static IP, DHCP, PPPoE and IP Passthrough. The four DI/DO channels support edge-triggered status reporting to the cloud. Dual Nano-SIMs share one drawer and switch on signal threshold, packet loss or dial-failure count. Link backup between cellular and wired WAN runs in hot-backup, cold-backup or load-balancing mode, with VRRP for gateway redundancy.

The router supports static and OSPF routing. VPN options are IPsec (IKEv1/IKEv2, AES256-SHA512, up to 10 tunnels), DMVPN, GRE, L2TP, PPTP, OpenVPN, WireGuard and ZeroTier. Security features include an SPI firewall, DoS protection, ACLs, 802.1x, IP-MAC binding, MAC filtering and signed firmware. Fleets can be managed through InHand Device Manager or InConnect. Local and scripted management uses SNMP v1/v2c/v3 with traps, SSH/Telnet, a local console and an HTTP/HTTPS API.

The fanless metal enclosure is rated IP30 and tested for shock, vibration and drop. It measures 127 x 108.2 x 35 mm and weighs 454 g. It operates from -35°C to 70°C, or -40°C to 75°C in the extended range. The IR315 datasheet is available.

Ideal for

  • Cellular WAN for multi-device control cabinets at pump stations, substations and pipelines
  • Primary or failover connectivity for retail, kiosk and branch equipment
  • Digital I/O monitoring of alarms, door contacts and relays at unattended sites
  • Multi-site private networks using DMVPN, OSPF or WireGuard
  • Hazardous-location deployments where C1D2 approval matters

Specifications

VPN

Gre
GRE
L2tp
L2TP over IPsec
Pptp
PPTP client/server
Dmvpn
DMVPN
Ipsec
IPsec IKEv1/IKEv2, AES256-SHA512, up to 10 tunnels
Openvpn
OpenVPN with AES-256-GCM
Zerotier
ZeroTier
Wireguard
WireGuard
Certificate Management
CA and PKCS12 certificates

Power

Peak Current
320 mA @ 12V
Input Voltage
9-36V DC with overcurrent and reverse polarity protection
Standby Current
120-200 mA @ 12V
Operating Current
150-320 mA @ 12V

General

MPN
IR315-FF39
Brand
InHand Networks
Model
IR315 Industrial Router
Configuration
North America, LTE Cat 6, I/O (no Wi-Fi, serial or GNSS)
Shipping Weight
0.95 lb (shipping)

Routing

Nat
NAT with port and virtual IP mapping
Ddns
DDNS with HTTPS update
Ospf
OSPF dynamic routing
Static Routing
Static routing with priority

Cellular

Bands
North America, including LTE Bands 66 and 71
SIM Card
1 drawer holding 2 x Nano-SIM
Technology
4G LTE Cat 6 (FF39, North America)
Dialing Mode
PPP, QMI, ECM (model dependent)
Network Access
APN, VPDN
Connection Mode
Always online, on-demand or manual dialing
Signal Reporting
RSRP, RSRQ, SINR, RSSI, RSCP, Ec/Io, PCI, band reporting
Antenna Connector
4G: SMA x1
Pdp Configuration
IPv4 / IPv4v6
Dual SIM Switching
SIM switching on signal, packet loss or dial failures
Access Authentication
CHAP/PAP
Operator Configuration
Built-in operator APNs including T-Mobile, AT&T, Verizon

Firewall

Acl
Access control lists
Dmz
DMZ host
8021x
802.1x
Port Mapping
Port mapping
Spi Firewall
SPI firewall
Mac Filtering
MAC address filtering
Dos Protection
DoS protection
IP Mac Binding
IP-MAC binding
Content Filtering
Domain content filtering
Device Access Control
Device access control

Industrial

Dtu
DTU transparent transmission
I/O Control
4 x DI/DO with edge-triggered reporting
Modbus Bridge
Modbus RTU to TCP bridge

Interfaces

I/O
4 x configurable DI/DO
Reset Button
Pinhole reset button
Ethernet Ports
5 x 10/100 Mbps RJ45, WAN/LAN/VLAN, 1.5 kV isolation
LED Indicators
Power, System, Network, Wi-Fi, Signal
Power Interface
2-pin terminal, 9-36V DC, overcurrent/reverse polarity protection
Grounding Terminal
Grounding terminal

Management

Snmp
SNMP v1/v2c/v3 with traps
Console
Local console
Http API
HTTP/HTTPS API
Inconnect
InConnect remote access
Ssh Telnet
SSH/Telnet
Device Manager
InHand Device Manager
Firmware Signature
Signed firmware
Configuration Management
Config import/export

Mechanical

Weight
454 g (1 lb)
Mounting
DIN rail
Enclosure
Metal shell, fanless
Dimensions
127 x 108.2 x 35 mm (5 x 4.26 x 1.38 in)
Protection Rating
IP30

CPU Storage

CPU
580 MHz
RAM
128 MB DDR2
Flash
64 MB SPI

Link Backup

Vrrp
VRRP with virtual MAC
Watchdog
Embedded watchdog
Link Backup
Cellular/WAN hot backup, cold backup or load balancing
Icmp Detection
Configurable ICMP link detection

Logs Alarms

Syslog
Remote Syslog (UDP 514)
SMS Alarm
SMS status query and restart
System Alarm
System alarms
Traffic Alarm
Traffic threshold alarms
Status Reporting
Status reporting incl. GPIO

Wired Network

Vlan
VLAN Access/Trunk modes
Port Roles
Flexible WAN/LAN/VLAN roles
WAN Protocol
Static IP, DHCP, PPPoE
Gratuitous Arp
GARP with configurable count and timeout
IP Passthrough
IP Passthrough to LAN device
Isolation Protection
1.5 kV isolation transformer

Network Services

Dns
DNS proxy and forwarding
Ntp
NTP server
Qos
QoS bandwidth and IP rate limiting
Dhcp
DHCP server/client, 200 static bindings
Portal
Captive portal authentication
Sip Alg
SIP ALG
Scheduled Tasks
Scheduled restart
Maintenance Tools
Ping, traceroute, speed test, packet capture

Environment Certifications

Emc
EN61000-4-2/-3/-4/-5/-6/-12 level 3, -8 above level 2
Humidity
5-95% non-condensing
Physical Testing
Shock, vibration and drop tested (IEC 60068)
Ff39 Certificates
IR315-FF39 PTCRB and IC certificates
Storage Temperature
-40°C to 85°C
Family Certifications
IR315 family: CE, E-MARK, FCC, IC, PTCRB, AT&T, Verizon, T-Mobile, UL, C1D2, IEC 62443-4-2 and more
Operating Temperature
-35°C to 70°C standard; -40°C to 75°C extended

Questions buyers ask

Does the IR315-FF39 include Wi-Fi or GNSS?

No. The IR315-FF39 is the North American LTE Cat 6 configuration with 4 x I/O. Wi-Fi is ordered with the -WLAN suffix, and GNSS with the -G suffix.

Can I have both serial ports and I/O?

No. On the IR315 the serial option (-S, 1 x RS-232 + 1 x RS-485) and the 4 x I/O interface are mutually exclusive. The IR315-FF39 uses the default I/O.

How do I set up cellular WAN failover?

With both links working, go to Network > Link Backup. Set WAN as the main link and cellular as the backup, then choose Hot Backup or Cold Backup. Set an ICMP detection server and click Apply.

Do I need to configure the APN manually?

In most cases, no. The IR315 auto-detects the carrier and applies the matching APN. If the link does not come up, set the APN under Network > Cellular. A steady green NET LED means the router is connected.

What is the default management address?

Connect a computer to a LAN port using DHCP or a 192.168.2.x static IP. Browse to http://192.168.2.1 and log in with the credentials printed on the device label.
