Cradlepoint5G & LTE Routers

Cradlepoint E3000 5G Branch Router with Wi-Fi 6 and 5-Year NetCloud Enterprise Branch Essentials Plan

5GMPN BF05-30005GB-GN
  • Wi-Fi 6
  • Dual SIM
  • 5+ × 2.5 Gb+ Ethernet
  • GPS/GNSS
  • PoE out
  • FirstNet Ready
$3,448.85$3,769.00Save $320.15

In stockShips from the US

Included subscription · 5 years
1 year−$1,061.473 years−$469.854 years+$420.935 years6 years+$110.15
Compliance · Standard
StandardTAA compliant+$420.15
Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans
Compare all 19 configurations

Datasheets & documents

Overview

The Cradlepoint E3000 (BF05-30005GB-GN) is an all-in-one enterprise branch router for fixed offices, healthcare, financial services and retail sites. This U.S. & Canada package pairs the E3000 with an embedded 5G modem, Wi-Fi 6 and a 5-year NetCloud Enterprise Branch Essentials plan. The modem supports 5G NR NSA/SA with LTE Advanced Pro Cat 20 and dual SIM slots. The router adds 11 wired ports including 2.5GbE and 10GbE SFP+, four 802.3bt PoE ports, and cloud management through NetCloud Manager for the full term.

  • Embedded 5G modem supporting 5G FR1 NSA/SA and LTE Advanced Pro Category 20, with dual 2FF SIM slots
  • Dual-band, dual-concurrent 4x4 MU-MIMO Wi-Fi 6 (802.11ax) at 1,148 Mbps (2.4 GHz) and 2,400 Mbps (5 GHz)
  • 9 x GbE RJ45, 1 x 2.5GbE RJ45 and 1 x 10GbE SFP+, all LAN/WAN switchable
  • 4 x 802.3bt PoE Type 3/4 ports at up to 90 W per port, with a 140 W total budget
  • 2 Gbps stateful firewall, 1.5 Gbps IPS/application-aware services and 20 concurrent VPN tunnels
  • MC400 modular modem slot for dual-modem operation, plus VRRP router pairing
  • 5-year NetCloud Enterprise Branch Essentials plan with NetCloud Manager, updates and 24x7 support
  • Bring a new branch online from day one over 5G, without waiting for a wired circuit

The Ericsson Cradlepoint E3000 is built for medium-size branch locations that need routing, security, switching, PoE and Wi-Fi in one metal chassis. This package, part number BF05-30005GB-GN, combines the E3000 in its 5GB configuration with Wi-Fi and a 5-year NetCloud Enterprise Branch Essentials plan for the U.S. and Canada. The embedded 5G modem provides connectivity on day one, before a wired circuit arrives. Once broadband is installed, the router can terminate that wired link as primary and keep 5G or LTE as failover.

The 5GB modem supports 5G FR1 in NSA and SA modes across 19 NR bands, including n41, n71 and n77. It also supports LTE Advanced Pro Category 20 with up to 7 downlink carriers, dual 2FF SIM slots, 4x4 MIMO and CBRS Band 48 for private cellular networks. Four 600 MHz to 6 GHz paddle antennas are included. On the wired side, the E3000 has nine GbE ports, one 2.5GbE port and one 10GbE SFP+ port, all LAN/WAN switchable. Four 802.3bt PoE ports deliver up to 90 W each, from a 140 W total budget. The dual-band 4x4 MU-MIMO Wi-Fi 6 radios support WPA3.

Rated performance includes a 2 Gbps stateful firewall, 1.5 Gbps IPS and application-aware services, 400 Mbps IPsec VPN, 20 concurrent VPN tunnels and 130,000 TCP sessions for about 100 typical clients. An MC400 slot adds a second modem for dual cellular connectivity. VRRP pairing supports hardware redundancy.

The Essentials plan covers NetCloud Manager, software and firmware updates, and 24x7 support for the full five years. It also covers the hardware under a limited lifetime warranty while the subscription is active. That support includes weekday phone support around the clock, emergency response on weekends, 24x7 web and 24x5 chat. NetCloud Advanced can be added at any time.

Ideal for

  • Fixed branch offices that need routing, firewall, switching, PoE and Wi-Fi in a single device
  • Healthcare clinics and financial branches requiring IPS, VPN and resilient primary/failover WAN
  • Retail stores that must open on 5G before wired broadband is installed
  • Multi-site enterprises standardizing on zero-touch deployment and cloud-orchestrated hub-and-spoke VPN
  • Public safety or private CBRS networks using FirstNet Trusted and Band 48 support

Specifications

Plan

Term
5-year subscription term
Tier
Essentials
Support
24x7 support for the full subscription term
Warranty
Limited lifetime hardware warranty with an active plan
Plan Name
5-Year NetCloud Enterprise Branch Essentials Plan
Available Terms
Plan family available in 1, 3 and 5-year terms
Service Add Ons
NetCloud Exchange, NetCloud Advanced
Software Updates
Software and firmware updates for the full term
Device Management
NetCloud Manager for the full term

Modem

3g
WCDMA/UMTS/HSPA+
SIM
Dual 2FF SIM slots
SMS
SMS supported
GNSS
Passive GNSS
MIMO
4x4 MIMO
3g Bands
WCDMA bands 1, 2, 3, 4, 5, 6, 8, 9, 19
Antennas
4 x 600 MHz-6 GHz paddle antennas (included)
Modulation
Up to 256 QAM DL/UL
Regulatory
FCC, IC, CE, RCM
Technology
5G NR NSA/SA, LTE Advanced Pro Cat 20 (3GPP Rel. 15)
5G NR Bands
n1 (2100), n2 (1900), n3 (1800), n5 (850), n7 (2600), n8 (900), n12 (700), n20 (800), n25 (1900), n28 (700), n38 (2600), n40 (2300), n41 (2500), n48 (3500), n66 (1700/2100), n71 (600), n77 (3700), n78 (3500), n79 (4900)
Peak Uplink
Up to 660 Mbps
LTE Fdd Bands
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71
LTE Tdd Bands
B34, B38, B39, B40, B41, B42, B43, B46, B48
Peak Downlink
Up to 4.14 Gbps
Transmit Power
5G NR 23 dBm ±1.5; EN-DC 20 dBm ±1; LTE 23 dBm ±1; HPUE 25 dBm ±1 (B41 SA)
Private Cellular
Private cellular incl. CBRS Band 48
Carrier Aggregation
LTE: up to 7 CA DL / 2 CA UL; EN-DC: 1 CA DL / 1 CA UL
Network Operator Standards
PTCRB, GCF
Public Safety Certifications
FirstNet Trusted, T-Mobile Connecting Heroes, Verizon Frontline Verified
Network Operator Certifications
AT&T, EE, T-Mobile, Verizon

Power

Consumption
17 W idle / 19 W typical / 24 W heavy
Power Supply
External PSU (included), 100-240 VAC in, 54 VDC 3.34 A out

General

MPN
BF05-30005GB-GN
UPC
UPC 810007806167
Brand
Cradlepoint (Ericsson Enterprise Wireless)
Model
Cradlepoint E3000
Region
U.S. & Canada
Category
Branch router
Form Factor
Metal enclosure
Cloud Management
Cloud-managed via NetCloud Manager
Special Features
5G embedded or paired with W-Series Adapters, dual modem, FirstNet Ready, private cellular, NetCloud Exchange, PoE+, 2.5 GbE, SFP+, WPA3
Dual Modem Support
Dual-modem support
Hardware Configuration
E3000-5GB with Wi-Fi
Private Cellular Network
CBRS, 4G LTE, 5G

Physical

Weight
1.98 kg (4 lb 6 oz)
Dimensions
160 x 320 x 44 mm (6.3 x 12.6 x 1.7 in)
Shipping Weight
8.00 lb shipping weight

Interfaces

PoE
4 x 802.3bt PoE (up to 90 W/port, 140 W total)
USB
1 x USB 2.0 Type A
Wi-Fi
Dual-band concurrent 4x4 MU-MIMO Wi-Fi 6 with DFS
Modem
Embedded 5G modem with 4 x SMA connectors; optional second MC400 modem
Console
1 x RJ45 console
Ethernet
9 x GbE, 1 x 2.5GbE, 1 x 10GbE SFP+ (LAN/WAN switchable)
Expansion
1 x expansion slot (MC20BT Bluetooth LE module)
Modem Slot
1 x MC400 modem slot (1 Gbps peak)
Supported SFP
Finisar FTLF8519P3BNL, FTLF1318P3BTL
Wi-Fi Antennas
External 4x4 Wi-Fi antennas
Wi-Fi Security
WPA3 Personal/Enterprise, 802.11k/v
Wi-Fi Data Rates
1,148 Mbps (2.4 GHz) / 2,400 Mbps (5 GHz)
Supported SFP Plus
Finisar FTLX8574D3BCL, FTLX1475D3BCL, FCBG110SD1Cxx

Wi-Fi Power

IC
26.22 / 21.70 / 28.65 dBm conducted
Fcc
26.22 / 28.63 / 28.65 dBm conducted

Performance

Vlans
Up to 64 L2/L3 VLANs
Stateful Firewall
2 Gbps
Typical Client Count
100 clients
Concurrent VPN Tunnels
20 tunnels
Concurrent Tcp Sessions
130,000 sessions
Point TO Point Ipsec VPN
400 Mbps
Sase Secure Connect SD-WAN
IPsec 400 Mbps / Microtunnel 600 Mbps
Ips App Aware Client Analytics
1.5 Gbps

Reliability

MTBF
E3000-5GB: 997,468 hours (Telcordia SR332 at 25 °C)

Environmental

Storage Humidity
5% to 95%
Operating Humidity
10% to 90%
Storage Temperature
-20 °C to 85 °C (-4 °F to 185 °F)
Operating Temperature
0 °C to 50 °C (32 °F to 122 °F)

Certifications

Safety
UL/cUL, CB Scheme, EN 62368-1
Security
FIPS 140-3 applies to E3000 FIPS models only
Substance Compliance
WEEE, RoHS, REACH, California Prop 65

Questions buyers ask

What is included with part number BF05-30005GB-GN?

It includes the Cradlepoint E3000 router in its 5GB-with-Wi-Fi configuration and a 5-year NetCloud Enterprise Branch Essentials plan. The router ships with an external power supply and four cellular paddle antennas. The plan covers NetCloud Manager, software updates and 24x7 support for the full term.

Which market is this SKU for?

This package is the Americas version for the U.S. and Canada.

Does the E3000-5GB support 5G standalone?

Yes. The embedded modem supports 5G FR1 in both NSA and SA modes across 19 NR bands, including n41, n71 and n77. It also supports LTE Advanced Pro Category 20.

Can I add a second cellular connection?

Yes. The E3000 has an MC400 modular modem slot for dual-modem operation. It can also be paired with a mirrored router using VRRP for hardware redundancy.

What warranty coverage applies?

Cradlepoint hardware carries a limited lifetime warranty for as long as the router has an active NetCloud Service Plan subscription. For this package, that covers the included 5-year term.
