InHand Networks5G & LTE Routers

InHand Networks IR624 Industrial 5G Router with Wi-Fi 5, Gigabit Ethernet and Serial – North America

5GMPN IR624-NRQ3-WLAN-S
  • Rugged
$514.27$599.00Save $84.73

Backordered · ships as soon as it arrives

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The InHand Networks IR624-NRQ3-WLAN-S is a North American 5G NR industrial router rated for up to 3.4 Gbps downlink with LTE fallback. It combines dual-band Wi-Fi 5, four gigabit Ethernet ports, one RS-232 and one RS-485 port, and a dual Nano-SIM slot. The fanless IP30 DIN-rail housing accepts 9–48 V DC. The NRQ3 model is certified with Verizon (NSA), AT&T, T-Mobile and FirstNet, and is managed through InHand DeviceLive.

  • 5G NR SA/NSA up to 3.4 Gbps downlink with LTE/WCDMA fallback (North American NRQ3 module)
  • Dual-band Wi-Fi 5, IEEE 802.11ac Wave2 MU-MIMO, up to 300 Mbps (2.4 GHz) / 867 Mbps (5 GHz)
  • 4 × 10/100/1000 Mbps Ethernet ports configurable as WAN/LAN/VLAN with 1.5 kV isolation
  • 1 × RS-232 + 1 × RS-485 with 15 kV ESD protection, DTU mode and Modbus RTU-to-TCP bridge
  • Dual Nano-SIM failover, interface backup, heartbeat link detection and embedded watchdog
  • IPsec, L2TP, OpenVPN and WireGuard VPN with firewall, policy-based routing and 802.1X
  • Fanless IP30 metal DIN-rail housing, 9–48 V DC input, -35 °C to 70 °C standard operation
  • Delivers 5G bandwidth for video, telemetry and data-heavy edge applications at remote sites

The InHand Networks IR624-NRQ3-WLAN-S is the North American 5G version of the IR624 industrial router, configured with Wi-Fi and serial interfaces. It is built for industrial sites, edge deployments and enterprise IoT networks that need high bandwidth and low latency in a compact DIN-rail unit. The NRQ3 module supports 5G NR in SA and NSA modes at up to 3.4 Gbps downlink, with fallback to LTE and WCDMA. InHand lists certification with Verizon (NSA), AT&T, T-Mobile and FirstNet (5G), plus FCC, IC and PTCRB.

On the local side, four 10/100/1000 Mbps Ethernet ports can be assigned as WAN, LAN or VLAN, each with 1.5 kV isolation. Dual-band Wi-Fi 5 (IEEE 802.11ac Wave2 MU-MIMO) delivers up to 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz, in AP or Client mode. One RS-232 and one RS-485 port, both with 15 kV ESD protection, handle TCP/UDP transparent DTU transmission and Modbus RTU-to-TCP bridging.

Resilience comes from interface backup, dual-SIM failover, heartbeat link detection with auto-redial and an embedded watchdog. Security includes firewall filtering, policy-based routing and 802.1X, with IPsec, L2TP, OpenVPN and WireGuard VPN. Routing supports static routes and BGP, and QoS traffic shaping and link monitoring (delay, jitter, packet loss) are built in.

The router runs on an 880 MHz CPU with 256 MB RAM and 128 MB flash, in a 544 g fanless metal housing. It accepts 9–48 V DC and operates from -35 °C to 70 °C, or -40 °C to 75 °C on extended versions. The standard package lists the router, a power supply, antennas, an Ethernet cable and a DIN-rail kit, though contents vary by order code. The IR624 Datasheet V1.0 is available.

Ideal for

  • High-bandwidth 5G WAN for industrial automation cells and edge computing
  • Video surveillance and data backhaul from remote or temporary sites
  • Primary or failover connectivity for branch, retail and kiosk networks
  • Public-safety and critical infrastructure deployments on FirstNet
  • Serial PLC and meter integration with Modbus RTU-to-TCP bridging

Specifications

Wi-Fi

Protocol
IEEE 802.11 ac/a/b/g/n Wave2 MU-MIMO (Wi-Fi 5)
Security
WPA/WPA2, WEP/TKIP/AES, Wi-Fi Portal support
Max Bandwidth
Up to 300 Mbps (2.4 GHz) / 867 Mbps (5 GHz)
Operating Mode
AP/Client modes
Transmit Power
5 GHz: 17 dBm; 2.4 GHz: 17 dBm
Radio Frequency
2.4 GHz / 5 GHz
Antenna Connectors
2 × RP-SMA
Transmission Distance
50 m line of sight (depends on site environment)

Power

Peak Current
530 mA @ 12 V
Input Voltage
DC 9~48 V, over-current and reverse-polarity protection
Standby Current
370-480 mA @ 12 V
Working Current
415-530 mA @ 12 V

General

MPN
IR624-NRQ3-WLAN-S
Brand
InHand Networks
Model
IR624 Industrial Router (InRouter624)
Region
North American 5G NR variant (NRQ3)
Configuration
5G NR with Wi-Fi and RS-232/RS-485 serial

Package

Documentation
IR624 Datasheet V1.0
Shipping Weight
1.20 lb
Standard Contents
IR624 router, power supply, 4 × 5G antennas, 2 × 4G antennas, Ethernet cable, DIN rail mounting kit (varies by order code)

Cellular

SIM Slot
Dual Nano-SIM drawer slot (1.8V/3V), optional eSIM
Technology
5G NR SA/NSA with LTE fallback
Max Downlink
Up to 3.4 Gbps downlink
Network Type
WCDMA / TDD LTE / FDD LTE / 5G NR (SA/NSA)
Network Access
APN/VPDN
Antenna Connectors
4 × SMA for 5G
Access Authentication
CHAP/PAP
Carrier Certifications
Verizon (NSA), AT&T, T-Mobile, FirstNet (5G), FCC, IC, PTCRB

Security

Data Security
IPsec VPN, L2TP VPN, OpenVPN, WireGuard VPN
Network Security
Access control, firewall filtering (MAC/IP/port/protocol), policy-based routing, 802.1X

Industrial

Dtu
DTU TCP/UDP transparent mode
Bridge
Modbus RTU-to-TCP bridge

Interfaces

Serial
1 × RS-232 + 1 × RS-485, 15 kV ESD protection
Ethernet
4 × 10/100/1000 Mbps (WAN/LAN/VLAN), 1.5 kV isolation
Reset Button
Reset button
Power Interface
DC 9~48 V with over-current and reverse-polarity protection

Mechanical

Weight
544 g (1.2 lb)
Housing
Fanless metal housing
Mounting
DIN-rail mounting
Dimensions
127 × 108.2 × 35 mm (5 × 4.26 × 1.38 in)
Protection Rating
IP30

CPU Storage

CPU
880 MHz
RAM
256 MB
Flash
128 MB

Environment

Emc
EN61000-4-2, -3, -4, -5, -6, -12 level 3; EN61000-4-8 400 A/m (>level 2)
Humidity
5~95% RH, non-condensing
Physical
IEC60068-2-27 shock; IEC60068-2-6 vibration; IEC60068-2-32 free fall
Certifications
CE, E-MARK, ECE R118, FCC, IC, PTCRB, AT&T, T-Mobile, Verizon (NSA)
Storage Temperature
-40 °C ~ 85 °C (-40 °F ~ 185 °F)
Operating Temperature
Normal: -35 °C ~ +70 °C (-31 °F ~ +158 °F); Extended: -40 °C ~ +75 °C (-40 °F ~ +167 °F)

Reliability

Backup
Interface backup
Dual SIM
Dual-SIM failover
Watchdog
Embedded watchdog
Link Detection
Heartbeat link detection with auto-redial

Network Features

Nat
NAT, port mapping
IP Routing
Static routing, BGP
LAN Protocol
ARP, Ethernet
WAN Protocol
Static IP, DHCP, PPPoE
IP Applications
TCP/UDP/IPv4/IPv6/ICMP/NTP/DNS/HTTP/HTTPS/SSL/TLS/VRRP/PPP/PPPoE/SSH, DHCP server/relay/client, DDNS, Telnet, IP passthrough

Network Management

Qos
QoS traffic shaping
Logs
System logs, diagnostic logs, device events
Cloud
DeviceLive batch management, remote O&M and equipment monitoring
Monitoring
Dashboard device info, interface status, traffic statistics; link delay, jitter, packet loss, throughput
Configuration
Web/CLI remote access, config import/export
Maintenance Tools
Ping, Traceroute, network packet capture

Questions buyers ask

Which US carriers is the IR624-NRQ3 certified with?

InHand lists the NRQ3 model as certified with Verizon (NSA), AT&T, T-Mobile and FirstNet (5G), along with FCC, IC and PTCRB.

Is this the right IR624 for North America?

Yes. NRQ3 is the North American 5G NR variant. The IR624-NRF4 targets Europe/APAC, the FQ58 is a Europe/APAC LTE Cat 4 model, and the NRF2 serves China.

What comes in the box?

The standard package lists the IR624 router, a power supply, four 5G antennas, two 4G antennas, an Ethernet cable and a DIN rail mounting kit. InHand notes that package contents vary by order code.

How do I add the router to InHand DeviceLive?

In your DeviceLive tenant, click Add Device and enter the serial number and credentials from the device label. Once the IR624 has internet access, it connects to DeviceLive automatically.

Where do I configure the RS-485 port?

In the web GUI, go to Industrial Interface > DTU. There you can set up serial-to-IP tunneling or Modbus RTU-to-TCP conversion, and match the baud rate, parity, stop bits and data bits to the connected device.
