InHand Networks VG710-H 5G Vehicle Gateway (IVG710-NRQ5) with Wi-Fi 5, GNSS and CAN Bus

5GMPN IVG710-NRQ5
  • 1 Gb Ethernet
  • GPS/GNSS
  • Rugged
$940.50$1,099.00Save $158.50

Backordered · ships as soon as it arrives

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Datasheets & documents

Overview

The InHand Networks VG710-H (IVG710-NRQ5) is a rugged 5G vehicle gateway for connected fleets. It combines a global multiband 5G SA/NSA radio rated up to 2.1 Gbps with four Gigabit Ethernet ports, dual-band Wi-Fi 5 and Bluetooth 4.1. It adds CAN, J1708, LIN and serial vehicle interfaces, multi-constellation GNSS with dead reckoning, and a programmable edge platform. All of this sits in a die-cast aluminum IP64 housing rated for -30 °C to +70 °C.

  • 5G NR SA/NSA with LTE and WCDMA fallback, global multiband 3GPP Rel-16 radio, speeds up to 2.1 Gbps
  • 4 × Gigabit Ethernet RJ45, dual-band Wi-Fi 5 (AP/Client) and Bluetooth 4.1
  • Vehicle interfaces: 2 × CAN bus, J1708, LIN, RS-232, RS-485, DI/DO/AI, audio and 1-Wire
  • GPS/GLONASS/Galileo/Beidou GNSS with accelerometer and gyroscope dead reckoning, 2.5 m CEP
  • Programmable edge platform: Python, C/C++, Docker, Node-RED, Azure IoT Edge SDK
  • IP64 die-cast aluminum housing, -30 °C to +70 °C operation, 9–36 V DC input with ignition sensing
  • Dual-SIM (2FF) with VRRP, link backup, heartbeat detection and offline data caching
  • Put high-bandwidth 5G in every vehicle, with LTE and WCDMA fallback where 5G coverage ends

The InHand Networks VG710-H is a rugged 5G vehicle gateway built for connected fleets in public transport, logistics, emergency services and heavy-duty trucking. Part number IVG710-NRQ5 corresponds to InHand's VG710-H-NRQ5 configuration. It uses a global multiband 3GPP Release 16 radio covering 5G NR SA/NSA, LTE-FDD/LTE-TDD and WCDMA, with speeds up to 2.1 Gbps. InHand lists the NRQ5 as certified with Verizon, AT&T, T-Mobile and FirstNet (5G), as well as FCC, IC and PTCRB.

Inside the vehicle, four Gigabit Ethernet RJ45 ports connect cameras, displays and onboard systems. Dual-band Wi-Fi 5 (AP or client) and Bluetooth 4.1 handle crew devices and wireless sensors. For telematics, the gateway provides 2 × CAN bus, J1708, LIN, RS-232 and RS-485. It also has digital and analog I/O, audio (R, L, mic) and 1-Wire for driver ID or temperature probes. A GPS, GLONASS, Galileo and Beidou receiver is rated at 2.5 m CEP. It pairs with an onboard accelerometer and gyroscope for dead reckoning, so position tracking continues through tunnels and urban canyons.

An ARM Cortex-A7 platform with 1 GB DDR3 and 8 GB eMMC runs Python, C/C++ and Docker workloads, including Node-RED images. It comes with Python 3, Docker and Azure IoT Edge SDKs and supports MQTT, DDS, AMQP, REST and CoAP. Security covers IPsec, L2TP, GRE and OpenVPN, plus an SPI firewall and RADIUS, TACACS+ or LDAP authentication.

The die-cast aluminum IP64 housing operates from -30 °C to +70 °C on 9–36 V DC input. Ignition-sense power control and transient protection come built in, and standby draw is 0.006 W. Dual 2FF SIM slots, VRRP, heartbeat link detection and an offline data cache keep telemetry flowing when coverage drops.

Ideal for

  • Transit buses and coaches needing onboard Wi-Fi, CCTV backhaul and passenger information connectivity
  • Logistics and trucking fleets collecting CAN/J1708 diagnostics and live GNSS location
  • Emergency and public-safety vehicles on FirstNet requiring rugged 5G connectivity
  • Utility and field-service vehicles running edge applications for telemetry and asset tracking
  • Heavy-duty and specialty vehicles integrating cameras, sensors and third-party equipment into one telematics system

Specifications

Wi-Fi

Protocol
Wi-Fi 5
Frequency
2.4 / 5 GHz dual-band
Max Output
2.4 GHz: 17 dBm; 5 GHz: 17 dBm
Working Mode
AP / Client

Wlan

Protocol
IEEE 802.11 b/g/n/a/ac
Security
Shared key, WPA/WPA2, WEP/TKIP/AES

Power

Peak Power
18.20 W peak
Protection
Built-in voltage transient protection with delayed ignition induction
Input Voltage
9–36 V DC (configurable to 7–36 V DC)
Standby Power
0.006 W
Pin Definition
V+, V-, ignition signal, NC (4 pins)
Operating Power
12.00 W average

General

MPN
IVG710-NRQ5
Brand
InHand Networks
Model
VG710-H 5G Vehicle Gateway
Region
Global
Configuration
VG710-H-NRQ5: 5G NR SA/NSA + LTE-FDD/LTE-TDD + WCDMA (global multiband), 3GPP Rel-16
Max Cellular Speed
Up to 2.1 Gbps (5G)
Carrier Certifications
Verizon, AT&T, T-Mobile, FirstNet (5G)

Package

Standard Package
VG710-H Vehicle Gateway ×1, VG710-H Power Cable ×1 (contents vary by standard order code)

Security

Aaa
Local authentication, RADIUS, TACACS+, LDAP
VPN
IPsec VPN, L2TP, GRE, OpenVPN, CA
Firewall
SPI, DoS defense, multicast/Ping filter, ACL, NAT/PAT/DMZ/port mapping/virtual server
User Level
Administrator / read-only
CA Certificate
PEM, PKCS12, SCEP

Reliability

Backup
Floating routing, VRRP, interface backup
Watchdog
Self-detection and auto-repair
Link Detection
Heartbeat detection, auto redial
Offline Storage
Built-in cache when network unavailable

Connectivity

Antenna
SMA-K: Cellular/GNSS; RP-SMA-K: 2 × Wi-Fi + BLE
Microsd
microSD up to 32 GB
Cellular
5G SA/NSA Sub-6 (this model)
Ethernet
4 × 10/100/1000 Mbps RJ45
Bluetooth
Bluetooth 4.1

Edge Computing

Ide
Visual Studio Code
Sdk
Python 3 SDK, Docker SDK, Azure IoT Edge SDK
Programmable
Python, C/C++, Docker
Docker Images
Node-RED, Ubuntu, Docker for ARM 32, etc.
Edge Platform
Integrated edge computing platform
Iot Architecture
MQTT, DDS, AMQP, XMPP, JMS, REST, CoAP
Third Party Cloud
MS Azure, SmartFleet and APIs for third-party platforms

Network Features

Upgrade
Local/remote WEB, DM, TFTP, FTP, SFTP server
IP Routing
Static routing, RIP, OSPF, BGP, IGMP Proxy
Diagnostics
Ping, Traceroute, Sniffer
LAN Protocol
ARP, Ethernet
Configuration
Local/remote HTTP, HTTPS, Telnet, SSH
Authentication
CHAP/PAP/MS-CHAP/MS-CHAP V2
IP Application
IPv6, Ping, Traceroute, DHCP server/relay/client, DNS relay, DDNS, Telnet, SSH, HTTP, HTTPS, TFTP, FTP, SFTP, Portal
Network Access
APN, VPDN

Vehicle Interfaces

Other
1-Wire (driver ID / temperature)
DO DI AI
2 × DO, 4 × DI/AI or 2 × DI/AI
Audio Voice
R, L, Mic
Diagnostics
2 × CAN bus, 1 × J1708, 1 × LIN bus
Serial Port
1 × RS-232, 1 × RS-485

Performance Metrics

CPU
ARM Cortex-A7
RAM
1 GB DDR3
Storage
8 GB eMMC
Main Frequency
717 MHz

Application Services

Event Alarm
Customizable alarms for DI, network, service, power, temperature, voltage
Message Push
SMS, email, app, digital output
Cloud Services
Device Manager and InConnect
Vehicle Telemetry
Rich interfaces for telemetry and asset tracking

Satellite Navigation

GNSS Receiver
GPS, GLONASS, Galileo, Beidou
Built IN Sensor
Accelerometer + gyroscope, supports dead reckoning
Position Accuracy
2.5 m CEP
Tracking Sensitivity
-160 dBm
Navigation Update Rate
Max 10 Hz

Mechanical Environment

SIM
Dual-SIM, 2FF
Weight
775 g (1.71 lb)
Cooling
Radiation cooling
Housing
Die-cast aluminum
Humidity
95% RH @ 60 °C
Dimensions
188.1 × 140.5 × 48.8 mm (7.41 × 5.53 × 1.92 in) W × D × H
Installation
Wall-mounting
Protection Rating
IP64
Startup Temperature
-35 °C
Storage Temperature
-40 °C to +85 °C (-40 °F to +185 °F)
Operating Temperature
-30 °C to +70 °C (-22 °F to +158 °F)

Standards Certifications

Warranty
3 years
Certification
CE, E-Mark, ITxPT, FCC, IC, PTCRB, RoHS, Verizon, AT&T, T-Mobile
Rail Standard
EN50155, EN50121, EN61373
Fire Prevention
EN45545-2:2020
Vehicle Standard
ECE-R10, R118

Core Technical Specifications

Weight
775 g (1.71 lb)
Dimensions
188.1 × 140.5 × 48.8 mm (7.41 × 5.53 × 1.92 in)
VPN Security
IPsec/L2TP/GRE/OpenVPN with SPI firewall, ACL, AAA and certificate management
Edge Computing
Supports Python, C/C++ and Docker; provides Python 3, Docker and Azure IoT Edge SDKs
Wlan Bluetooth
Dual-band Wi-Fi 5 (AP/Client) + Bluetooth 4.1
Cellular Network
5G SA/NSA Sub-6, with LTE/3G fallback (model dependent)
Protection Rating
IP64
Input Voltage Range
9–36 V DC (configurable to 7–36 V DC)
Interface Capability
4× Gigabit Ethernet, 2× CAN, J1708, LIN, RS-232, RS-485, DI/DO/AI, 1-Wire
Cloud Iot Integration
Supports MQTT, DDS, AMQP, REST and CoAP; compatible with Azure and third-party platforms
Operating Temperature
-30 °C to +70 °C (-22 °F to +158 °F), minimum startup at -35 °C
Positioning Capability
GPS/GLONASS/Galileo/Beidou + inertial navigation (DR)

Questions buyers ask

Which carriers is the IVG710-NRQ5 certified with?

InHand lists the VG710-H-NRQ5 (5G NR, global, 3GPP Release 16) as certified with Verizon, AT&T, T-Mobile and FirstNet (5G). It also carries FCC, IC, PTCRB, CE, E-Mark, ITxPT and RoHS approvals.

How is the VG710-H powered on in a vehicle?

The gateway needs the ignition (IGT) signal to power on. Wire the IGT pin on the 4-pin power connector to the vehicle's ignition-controlled circuit; input voltage is 9–36 V DC. Ignition delay and delayed power-off behavior are set under Administration > System > Basic Setup.

Do I need to configure an APN?

Usually not. Insert the SIM with the unit powered off, then apply ignition. The VG710-H auto-detects the carrier and applies the matching APN in most cases. If the link does not come up, log in at http://192.168.2.1 and go to Network > Cellular > Cellular to set the APN, authentication and dual-SIM options.

How does the VG710-H differ from the VG710-M?

The VG710-H uses RJ45 Ethernet and SMA antenna connectors and is designed for commercial fleets and standard in-vehicle deployments. The VG710-M uses M12 X/D-coded Ethernet and FAKRA connectors for vibration-resistant cabling in rail, public transit and heavy-duty vehicles.

Can I run my own applications on the gateway?

Yes. The integrated edge platform supports Python, C/C++ and Docker, including Node-RED and Ubuntu images. InHand provides Python 3, Docker and Azure IoT Edge SDKs, with Visual Studio Code as the supported IDE.
