Taoglas Raptor X RAPX.4.4C.2M.S2.B 4-in-1 5G/4G MIMO Screw-Mount Antenna, 2m SMA Male

5GMPN RAPX.4.4C.2M.S2.B
  • 4x4 MIMO
  • 1–3 m
$127.13$151.35Save $24.22

In stockShips from the US

1
Request a quote · volume, multi-site or with plans
Compare all 2 configurations

Datasheets & documents

Overview

The Taoglas Raptor X RAPX.4.4C.2M.S2.B is a 4-in-1 permanent screw-mount antenna with four 5G/4G MIMO elements covering 617MHz to 6GHz, for 4x4 cellular routers and gateways. The 350 x 70 x 40mm enclosure is IP67 and IP69K waterproof and IK10 impact rated, for exposed outdoor and vehicle installs. This variant ships with 2m TGC-200 leads terminated in four SMA male connectors, suited to short runs to nearby equipment.

  • 4-in-1 antenna with 4x 5G/4G MIMO elements in one enclosure
  • Covers 617MHz to 5925MHz, worldwide 5G/4G bands with 3G/2G fallback
  • 5G NR n77, n78 and n79 and CBRS Band 48 coverage with up to 7.74dBi peak gain
  • IP67 and IP69K waterproof, IK10 impact-rated 350 x 70 x 40mm enclosure
  • Permanent screw mount, -40°C to +85°C operation
  • 2m TGC-200 leads with four SMA male connectors
  • Drive all four antenna ports on a 4x4 MIMO 5G router from one housing
  • Keep coverage from 600MHz low band through 5G mid-band and 5.9GHz with every element

The Raptor X MA890 houses four 5G MIMO antennas in one compact enclosure. It is designed for routers and gateways that use four cellular antenna ports to raise throughput across multiple uplink and downlink bands. Taoglas lists digital signage, transportation and autonomous vehicles, private 5G networks and public safety as typical applications.

Each of the four elements covers 617MHz to 5925MHz, with 3G and 2G fallback. That spans 5G NR/LTE Band 71, bands 12, 13, 14, 17, 28 and 29, bands 5, 8, 18, 19, 20, 26 and 27 (including NB-IoT and Cat-M), 1427-1518MHz, 1710-2200MHz, bands 7, 30, 38, 40 and 41, and 3300-5000MHz covering bands 22, 42, 48, n77, n78 and n79. It also covers 5150-5925MHz. Peak gain reaches up to 7.74dBi in the 3.3-5GHz range, and each port handles 2W to 10W of input power.

The enclosure is IK10 impact rated and IP67 and IP69K waterproof, so it can sit where it takes direct rainfall, such as a bus-stop roof or the top of a digital display. It operates from -40°C to +85°C.

RAPX.4.4C.2M.S2.B is a cable and connector variant of the standard MA890.A.BIVW.001. It has four 2m TGC-200 leads, each ending in an SMA male connector, a direct fit for SMA-female router ports close to the mounting point. The Taoglas MA890.A.BIVW.001 datasheet documents the full electrical performance.

Ideal for

  • Digital signage with 4x4 MIMO 5G routers
  • Transportation and autonomous vehicles
  • Private 5G networks
  • Public safety and first-responder installations
  • Bus shelters and other exposed outdoor mounts

Specifications

Cabling

Cable Type
TGC-200
Connectors
4x SMA male
Cable Length
2 m

General

MPN
RAPX.4.4C.2M.S2.B
Brand
Taoglas
Elements
4x 5G/4G MIMO
Technology
External combination antenna
Product Name
Raptor X MA890 4-in-1 5G/4G MIMO Antenna
Standard Model
Variant of standard model MA890.A.BIVW.001

Compliance

Environmental Compliance
RoHS and REACH compliant

Mechanical

Weight
950 g
Dimensions
350 x 70 x 40 mm
Enclosure Impact Rating
IK10

Environmental

Temperature Range
-40°C to +85°C
Waterproof Rating
IP67 and IP69K

LTE Electrical

Band 71
36.4-49.8%, up to 2.25 dBi
Impedance
50 Ω
698 824mhz
35.4-50.3%, up to 2.94 dBi
824 960mhz
4G/3G/NB-IoT/Cat M 824-960 MHz (B5/8/18/19/20/26/27): 37.5-50.8%, up to 2.64 dBi
1427 1518mhz
24.5-27.9%, up to 1.21 dBi
1710 2200mhz
4G/3G 1710-2200 MHz (B1/2/3/4/9/23/25/35/39): 42.5-53.7%, up to 5.63 dBi
2300 2690mhz
45.2-56.8%, up to 6.97 dBi
3300 5000mhz
5G NR/4G 3300-5000 MHz (B22/42/48/n77/n78/n79): 55.6-58.9%, up to 7.74 dBi
5150 5925mhz
40.1-48.9%, up to 6.48 dBi
Polarization
Linear
Test Condition
Tested with 0.3 m of cable
Max Input Power
2W to 10W
Radiation Pattern
Omnidirectional

Product Attributes

Rohs
Yes
Vswr
<2
Width
70 mm
Height
40 mm
Length
350 mm
Weight
455 g
Gain Max
4.6 dBi
Impedance
50 Ω
IP Rating
IP67
Polarization
Linear
Mounting Style
Screw
Frequency Range
600 - 6000 MHz
Max Operating Temperature
85°C
Min Operating Temperature
-40°C

Questions buyers ask

How many cellular ports does it support?

Four. It has four 5G/4G MIMO elements, each on its own 2m TGC-200 lead with an SMA male connector.

What frequency range does it cover?

617MHz to 5925MHz on every element. That includes Band 71, the low bands, mid bands, Bands 41 and 48, and 5G NR n77, n78 and n79.

Can it be installed outdoors?

Yes. The enclosure is IP67 and IP69K waterproof and IK10 impact rated, and operates from -40°C to +85°C.

How is it mounted?

It is a permanent screw-mount antenna in a low-profile 350 x 70 x 40mm housing.

Are longer cable versions available?

Yes. The same Raptor X 4-in-1 antenna is offered with 5m (RAPX.4.4C.5M.S2.B) and 8m (RAPX.4.4C.8M.S2.B) TGC-200 SMA male leads.
