Ubiquiti Mobile Router Ultra (UMR-Ultra-US) Compact LTE Cat 4 IoT Router with Failover

4G LTEMPN UMR-ULTRA-US
$145.51

Backordered · ships as soon as it arrives

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Overview

The Ubiquiti Mobile Router Ultra (UMR-Ultra-US) is an ultra-compact managed LTE Cat 4 router for IoT applications. It pairs an LTE radio rated at 150 Mbps down and 50 Mbps up with wired and Wi-Fi WAN, automatic priority fallback, OpenVPN and WireGuard clients, and IPsec or WireGuard site-to-site VPN. At 84 x 82 x 26 mm and 5.7W maximum draw, it runs from USB-C or 9-30V DC and mounts on DIN rail or wall.

  • LTE Cat 4 radio, bands B2/B4/B5/B12/B13/B14/B25/B26/B66/B71, rated 150 Mbps down / 50 Mbps up
  • Cellular, Ethernet and Wi-Fi WAN with priority and fallback; LTE passthrough and bridge modes
  • OpenVPN and WireGuard clients; IPsec and WireGuard site-to-site VPN; firewall and static routes
  • Two Fast Ethernet RJ45 ports and 1x1 Wi-Fi 4 (2.4 GHz, up to 150 Mbps)
  • USB-C (5V/2A) or 4-pin ATX DC (9-30V DC) power; 5.7W max consumption
  • 84 x 82 x 26 mm, 200 g; DIN rail and wall mounts included
  • Certified FCC, IC, PTCRB, GCF, AT&T, T-Mobile, Verizon, Wi-Fi Alliance; NDAA compliant
  • Fits inside kiosks, cabinets and control panels where larger routers will not

The Mobile Router Ultra is Ubiquiti's smallest managed LTE router, built for IoT endpoints, kiosks, signage, vending and control panels where space and power are limited. It holds FCC, IC, PTCRB, GCF, AT&T, T-Mobile, Verizon and Wi-Fi Alliance certifications, and it is NDAA compliant.

Its LTE Cat 4 radio supports bands B2, B4, B5, B12, B13, B14, B25, B26, B66 and B71 with rated throughput of 150 Mbps download and 50 Mbps upload, using a nano SIM. Cellular, Ethernet and Wi-Fi can each serve as WAN with priority and fallback, so a site can run on a wired connection and switch to LTE automatically. LTE passthrough and Ethernet bridge modes are available, along with OpenVPN and WireGuard clients, IPsec and WireGuard site-to-site VPN, firewall, port forwarding and static routes.

Local connectivity comes from two Fast Ethernet RJ45 ports and 1x1 Wi-Fi 4 on 2.4 GHz at up to 150 Mbps. Antennas are external, two LTE on SMA female and one Wi-Fi on RP-SMA female, so they can be relocated for better signal. Power is flexible: USB Type-C at 5V/2A or a 4-pin ATX DC input accepting 9-30V DC, with a maximum consumption of just 5.7W.

The polycarbonate enclosure measures 84 x 82 x 26 mm without antennas and weighs 200 g. A steel DIN rail mount and polycarbonate wall mount are included, and the router operates from -30 to 70 °C at 10 to 90% noncondensing humidity.

Ideal for

  • Cellular connectivity for kiosks, digital signage and vending machines
  • Primary or failover WAN for IoT gateways and PLCs in DIN rail panels
  • Low-power remote monitoring on solar or battery supplies via 9-30V DC
  • Secure VPN back-haul for small unattended equipment sites
  • Vehicle installations needing a compact LTE router

Specifications

General

MPN
UMR-ULTRA-US
Brand
Ubiquiti
Model
Mobile Router Ultra (UMR-Ultra-US)
Region
US

Features

Firewall
Yes
WAN Wi-Fi
Yes
WAN Cellular
Yes
WAN Ethernet
Yes
Static Routes
Yes
Wi-Fi Standard
Wi-Fi 4 (2.4 GHz, 20/40 MHz)
Port Forwarding
Yes
VPN Client Openvpn
Yes
Ethernet Bridge Mode
Yes
LTE Passthrough Mode
Yes
VPN Client Wireguard
Yes
Site TO Site VPN Ipsec
Yes
WAN Priority And Fallback
Yes
Site TO Site VPN Wireguard
Yes

Hardware

Buttons
(1) Factory reset
Wi-Fi MIMO
1 x 1
Management
Ethernet; Wi-Fi
Antenna Type
(2) external LTE; (1) external Wi-Fi
Max TX Power
17 dBm
Power Method
USB-C (5V DC/2A); 4-pin ATX DC (9-30V DC)
Antenna Ports
Mobile 1 SMA-F (1Rx); Mobile 2 SMA-F (1Tx/1Rx); Wi-Fi RP-SMA-F
Certifications
FCC, IC, PTCRB, GCF, AT&T, T-Mobile, Verizon, Wi-Fi Alliance
Ndaa Compliant
Yes
LTE Throughput Speed
150 Mbps down / 50 Mbps up
Max Power Consumption
5.7W
Ambient Operating Humidity
10 to 90% noncondensing
Ambient Operating Temperature
-30 to 70 °C (-22 to 158 °F)

Overview

SIM
Nano SIM
Mounting
DIN rail, wall (mounts included)
LTE Bands
B2, B4, B5, B12, B13, B14, B25, B26, B66, B71
Dimensions
84 x 82 x 26 mm (3.3 x 3.2 x 1 in) without antennas; 193.5 x 82 x 26 mm (7.6 x 3.2 x 1 in) with antennas
Networking Interface
(2) Fast Ethernet RJ45, LTE Cat 4 radio, Wi-Fi 4

Mechanical

Weight
200 g (7.1 oz) device; 20 g (0.7 oz) mounts
Mount Material
Wall mount: polycarbonate; DIN rail mount: steel
Enclosure Material
Polycarbonate

Networking

Data Rates 802 11b
1, 2, 5.5, 11 Mbps
Data Rates 802 11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
Data Rates 802 11n
6.5-150 Mbps (MCS0-MCS7, HT 20/40)

Questions buyers ask

What Ethernet ports does the Mobile Router Ultra have?

It has two Fast Ethernet (FE) RJ45 ports.

How is the Mobile Router Ultra powered?

Through USB Type-C at 5V DC/2A or a 4-pin ATX DC input that accepts 9-30V DC. Maximum power consumption is 5.7W.

Does it support automatic failover?

Yes. Cellular, Ethernet and Wi-Fi can all act as WAN with priority and fallback configured between them.

Which LTE bands does it support?

B2, B4, B5, B12, B13, B14, B25, B26, B66 and B71, on an LTE Cat 4 radio rated at 150 Mbps down and 50 Mbps up.

What mounting hardware is included?

A steel DIN rail mount and a polycarbonate wall mount are included.
