Cisco Meraki MX68CW LTE and 802.11ac Wi-Fi Security Appliance, North America (MX68CW-HW-NA)

4G LTEMPN MX68CW-HW-NA
  • Wi-Fi 5
  • 5+ × 1 Gb Ethernet
  • PoE out
$1,845.75$3,429.93Save $1,584.18

Backordered · ships as soon as it arrives

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans

Overview

The Cisco Meraki MX68CW-HW-NA is the North American model of the MX68CW, an all-in-one branch appliance. It combines a cloud-managed firewall and SD-WAN edge with a built-in Cat 6 LTE modem, 802.11ac Wave 2 Wi-Fi and ten GbE LAN ports, two of them PoE+. It is sized for small branches of up to 50 devices. Cisco has designated this model end-of-life.

  • Built-in Cat 6 LTE modem (SIM required) with FDD-LTE bands 2, 4, 5, 12/17, 13 and 29
  • 802.11ac Wave 2 Wi-Fi, 2x2 MU-MIMO, up to 1.3 Gbps
  • 2 dedicated GbE WAN ports; 8 GbE LAN ports plus 2 GbE PoE+ LAN ports
  • 700 Mbps stateful firewall and 400 Mbps next-generation firewall throughput
  • IDS/IPS, content filtering, AMP malware protection and 802.1X
  • SD-WAN over Meraki Auto VPN with WAN link balancing and automatic failover
  • North America model managed from the Cisco Meraki dashboard
  • Replace a separate firewall, switch, access point and LTE modem with one appliance

The Cisco Meraki MX68CW combines a security appliance, SD-WAN router, LTE modem, wireless access point and small PoE+ switch in one desktop or wall-mount unit. It is aimed at small branches, retail stores and remote offices that want the fewest boxes possible. This SKU, MX68CW-HW-NA, is the North America model, and Cisco has designated it end-of-life.

The built-in Cat 6 LTE modem requires a SIM card. It covers FDD-LTE bands 2, 4, 5, 12/17, 13 and 29, with two-carrier downlink aggregation up to 40 MHz and HSPA+ fallback. It is PTCRB certified and carrier certified by Verizon, AT&T and T-Mobile. Bring the unit online through a wired WAN port first so it can retrieve the update that enables integrated cellular. The fixed antennas serve both Wi-Fi and LTE and cannot be removed.

Wired connectivity is generous for the class. It has two dedicated GbE WAN ports for dual uplinks, eight GbE LAN ports, and two more GbE LAN ports with PoE+ to power a phone, camera or access point. The 802.11ac Wave 2 radio uses 2x2 MU-MIMO with two spatial streams and a maximum data rate of 1.3 Gbps. Cisco rates the appliance at 700 Mbps stateful firewall throughput and 400 Mbps next-generation firewall throughput. It lists 300 Mbps site-to-site VPN throughput and 400 Mbps maximum VPN throughput.

Security and management follow the Meraki MX platform. That includes a layer 3/7 firewall, content filtering, IDS/IPS, Advanced Malware Protection, 802.1X for wired and wireless clients, Auto VPN SD-WAN, and zero-touch provisioning from the Cisco Meraki dashboard. Support for third-party USB cellular modems on the MX ends on June 30, 2026.

Ideal for

  • All-in-one network for a small branch, store or remote office
  • Branch sites that need LTE failover plus staff and guest Wi-Fi
  • Powering IP phones or cameras from built-in PoE+ ports
  • Expanding or maintaining existing MX68CW deployments

Specifications

General

MPN
MX68CW-HW-NA
UPC
810979015567
Brand
Cisco Meraki
Model
MX68CW
Region
North America model
Lifecycle Status
End-of-life model
Country OF Origin
Taiwan

Features

VPN
Auto VPN, IPsec VPN endpoint, client VPN
Firewall
L3/L7 stateful firewall, geo rules, 1:1 and 1:Many NAT
Identity
Active Directory, 802.1X
Management
Meraki dashboard with automatic firmware upgrades
Networking
VLANs, DHCP, static routing
Visibility
Traffic shaping, client usage history, NetFlow, Syslog, packet capture
WAN Features
Link balancing, automatic failover, Auto VPN SD-WAN
Security Services
Content filtering, AMP, IDS/IPS

Physical

Weight
2.61 lb / 1.18 kg
Humidity
5% to 95%
Dimensions
1.1 x 7.0 x 11.2 in / 27 x 178 x 284 mm (h x d x w)
Mount Type
Desktop or wall mount
Power Load
19 W idle / 89 W max
Power Supply
100 W DC
Operating Temperature
32°F to 113°F (0°C to 45°C)

Accessories

MA Pwr 100wac
Replacement power adapter, 100 W AC (MX68 / 68W / 68CW)
MA Simtray 2c
Two SIM card trays (MX67C / MX68CW)
MA Simtray 5c
Five SIM card trays (MX67C / MX68CW)
MA Pwr Cord US
AC power cable, US plug

LAN Interface

LAN PoE Plus
2x dedicated GbE RJ45 PoE+
LAN Dedicated
8x dedicated GbE RJ45

WAN Interface

WAN Cellular
Built-in cellular uplink or third-party USB modem
WAN Ethernet
2x dedicated GbE RJ45

Cellular Interface

Gsm Bands
GSM 850/900/1800/1900
SIM Slots
1 SIM
LTE Category
LTE Cat 6 (SIM required)
Fdd LTE Bands
FDD-LTE 2, 4, 5(*), 12/17, 13, 29
Certifications
PTCRB (US)
Hspa Plus Bands
HSPA+ 2, 4, 5
Certified Carriers
Verizon, AT&T, T-Mobile
Carrier Aggregation
2x DL-CA up to 40 MHz: 2+17, 4+17, 2+29, 4+29, 4+5, 2+5

Wireless Interface

Radio
802.11ac Wave 2, 2.4 or 5 GHz, 2x2 MU-MIMO
Antennas
2x2 MU-MIMO, two spatial streams (fixed, non-removable, shared with LTE)
Max Data Rate
1.3 Gbps

Throughput And Capabilities

Cellular Uplink
Built-in LTE; third-party USB modem supported
Dual WAN Uplinks
Yes
PoE Capabilities
PoE+ on 2 GbE LAN ports
Maximum VPN Throughput
400 Mbps
Recommended Device Count
Small branch with up to 50 devices
Ngfw Detection Throughput
400 Mbps next-generation firewall (detection)
Site TO Site VPN Throughput
300 Mbps site-to-site VPN
Stateful Firewall Throughput
700 Mbps

Questions buyers ask

Can I replace the antennas on the MX68CW?

No. The MX68CW has fixed antennas that serve both Wi-Fi and LTE connectivity and cannot be removed.

How many devices can the PoE+ ports power?

Two of the ten GbE LAN ports provide PoE+. The appliance is powered by a 100 W DC supply with a maximum load of 89 W.

What Wi-Fi does the MX68CW provide?

It has an 802.11ac Wave 2 radio operating on 2.4 or 5 GHz, with 2x2 MU-MIMO, two spatial streams and a maximum data rate of 1.3 Gbps.

Which carriers support the built-in LTE modem?

Verizon, AT&T and T-Mobile have certified the MX68CW. The modem covers FDD-LTE bands 2, 4, 5, 12/17, 13 and 29.

Is the MX68CW-HW-NA a current model?

No. Cisco has designated it end-of-life. It remains a fit for maintaining or expanding existing MX68CW deployments.
