Lantronix5G & LTE Routers

Lantronix E214G LTE Cat-1 Industrial IoT Router for AT&T and T-Mobile, North America (E214G000S)

LTE Cat 1MPN E214G000S
  • Dual SIM
  • 2–4 × 100 Mb Ethernet
$163.25

Backordered · ships as soon as it arrives

Region · North America
North AmericaAPAC+$7.78EMEA + APAC+$8.39
Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans
Compare all 4 configurations

Datasheets & documents

Overview

The Lantronix E214G000S is the North American AT&T and T-Mobile variant of the E210 Series industrial IoT router. It connects on 4G LTE Cat-1 bands 2, 4, 5 and 12 with 3G fallback. It combines dual SIM failover, two 10/100 Ethernet ports, Wi-Fi 4, an RS-232 serial port, two configurable I/Os and GPS in a compact brushed-aluminum housing. Use it for industrial automation, payment terminals, smart buildings and remote monitoring sites that need an always-on cellular link.

  • 4G LTE Cat-1 on bands B2, B4, B5 and B12 (North America, AT&T and T-Mobile) with 3G fallback
  • Dual SIM, single standby via two mini-SIM trays, with QoS-based or scripted switching
  • Two 10/100 Ethernet ports (WAN reconfigurable as a second LAN) and 1T1R Wi-Fi 4 via an RP-SMA connector
  • Full RS-232 serial port, two configurable digital I/Os and GPS on a dedicated SMA connector
  • Industrial protocol conversion covering Modbus, DNP3, IEC 60870-5-101/104, and Modbus to MQTT/Azure/Cumulocity
  • Cloud-ready with TR-069, MQTT/s, TLS 1.3 and Lantronix Percepxion device management
  • Keep remote sites online: dual SIM plus Ethernet, cellular and Wi-Fi failover or load balancing reduce the risk of lost communication
  • Connect legacy PLCs, meters and payment equipment directly over RS-232, or over isolated RS-485 with the optional SNAP CAP

The Lantronix E214G000S is a compact, industrial-grade LTE Cat-1 router from the E210 Series. This part number is the North America variant for AT&T and T-Mobile. It operates on LTE bands B2, B4, B5 and B12 with 3G fallback. It is built for M2M and enterprise IoT work where connectivity has to stay up, such as industrial automation, Industry 4.0, smart buildings, smart city infrastructure, transportation and point-of-sale payments.

Connectivity is flexible. Two mini-SIM trays provide dual SIM, single-standby operation, and switching can be based on quality of service or on your own scripted conditions. You also get one WAN and one LAN 10/100 Ethernet port, and the WAN port can be reassigned as a second LAN. Wi-Fi 4 runs through an RP-SMA antenna connector in client or access point mode. Ethernet, cellular and Wi-Fi can each be configured for failover or load balancing. A full RS-232 port on a 9-pin sub-D connector links legacy equipment, and the optional SNAP CAP SC485 adapter converts it to isolated RS-485. Two user-configurable digital I/Os and GPS on a dedicated SMA connector complete the interface set.

The router runs Lantronix's Linux-based ePack software suite. It supports VPN via OpenVPN, IPsec (up to 4 channels), WireGuard, L2TP, GRE and PPTP client. Security includes a zone-based firewall, VLAN, DMZ and HTTPS management. Built-in converters translate Modbus RTU/TCP, IEC 60870-5-101/104 and DNP3, and can forward data to MQTT, Azure, Cumulocity, FTP or HTTP. For remote fleets, it supports TR-069, SMS/OTA configuration and Lantronix Percepxion device management. A microSD slot supports local logging and edge processing, and custom packages can be built with the G520 SDK in Python or C/C++.

The unit accepts 8 to 32 V DC and operates from -20 °C to +70 °C. Lantronix publishes an E210 Series User Guide, an E214G Quick Start Guide and a product brief for this model.

Ideal for

  • Industrial automation and Industry 4.0 PLC and sensor connectivity over RS-232 or Modbus
  • Point-of-sale payment terminals and ATM monitoring needing cellular failover
  • Smart building and smart city infrastructure telemetry
  • Transportation and remote asset connectivity with GPS location
  • Utility and energy sites that need IEC 104 or DNP3 protocol conversion

Specifications

I/O

Digital Input
0 V DC ~ 1 V DC = ZERO; 1.4 V ~ 36 V DC = ONE
Digital Output
open collector, 100 mA max, 36 V DC max
User Configurable I/O
2 user-configurable I/Os via the 4-pin Micro-Fit power connector (lower row)

Power

Input Voltage
8 ~ 32 V DC, with slow start
Power Off Timekeeping
Dedicated RTC with 100-day data retention (approx. 15 mWh lithium manganese battery, not functional below -20 °C)

Serial

Rs232
RS-232 full implementation via 9-pin sub-D header
Rs485
RS-485 via SNAP CAP SC485 adapter (sold separately); isolated half- or full-duplex on 5-pin, 3.5 mm pitch COMBICON header

General

MPN
E214G000S
UPC
783384240810
Brand
Lantronix
Model
E214G
Series
E210 Series
Regional Variant
North America (AT&T, T-Mobile)

Cellular

SIM
Dual SIM, single standby; via two mini-SIM held in trays
Fallback
3G fallback
LTE Bands
LTE Cat-1: B2, B4, B5, B12
Technology
4G LTE Cat-1

Ethernet

Ports
2 x 10/100 Ethernet
Configuration
One LAN and one WAN (reconfigurable as second LAN); RJ-45 headers fitted with two LEDs

Physical

Size
92.5 x 57.2 x 22.5 mm without connectors
Weight
Approx. 150 g
Material
Brushed aluminum alloy
Status Leds
Seven: POWER; blue SIM, Wi-Fi; amber Activity, Network, Signal; red ALERT
Shipping Weight
0.44 lb

Software

Sdk
G520 SDK for custom packages and firmware images using Python or standard C/C++
VPN
PPTP client, L2TP, OpenVPN client/server/passthrough, GRE, IPsec (up to 4 channels), WireGuard
Cloud
TR-069, MQTT/s, TLS 1.3, Percepxion integration
Routing
DHCP, static routing, port forwarding, traffic routing, static/dynamic DNS, DNS proxy, NAT, STP
Security
Secure HTTPS web UI; zone-based firewall, VLAN, DMZ, HTTPS local and remote connection, SIM PIN
Redundancy
Ethernet, Cellular, Wi-Fi – configurable as failover or load balancing
Resilience
Configurable network connectivity watchdog, internal application watchdog
Wi-Fi Software
Client or Access point (approx. 12 users), WEP, WPA, WPA-PSK / WPA2-PSK, WPA3-PSK security modes
Administration
Web-based UI, setup wizard, console log viewer, save/load configuration, NTP, SMS/OTA remote configuration, TR-069-capable
Device Management
Lantronix Percepxion platform or third-party platforms
Industrial Protocols
Modbus RTU/TCP to IEC-60870-5-104, Modbus master, Modbus RTU to TCP, Modbus to MQTT/Cumulocity/FTP/Azure/HTTP, Serial to FTP, IEC-60870-5-101 to 104, Modbus to DNP3, I/O to Modbus, I/O to IEC 104, I/O toggling through SMS
Performance Fault Management
Real-time processor load and interface (WAN/LAN/Wi-Fi) traffic analysis, ICMP, trace-route, NS lookup

CPU Memory

CPU
MIPS32 24KEc CPU at 580 MHz
RAM
DDR SDRAM 128 MB
Flash
SPI Flash 32 MB
User Storage
External via microSD card (not provided)

Positioning

GPS
GPS via a dedicated SMA antenna connector

Temperature

Storage
-40 °C ~ +85 °C; up to 95% RH
Operating
-20 °C ~ +70 °C; up to 95% RH

Wi-Fi Bluetooth

Wi-Fi Modes
Client or Access point (approx. 25 users), WEP, WPA, WPA-PSK / WPA2-PSK security mode
Wi-Fi Radio
1T1R Wi-Fi 4; via an RP-SMA antenna connector

Questions buyers ask

Which carriers and bands does the E214G000S support?

It is the North America variant for AT&T and T-Mobile, operating on LTE Cat-1 bands B2, B4, B5 and B12 with 3G fallback. For Verizon, Lantronix offers the E214G001S.

Does the router have dual SIM?

Yes. It has two mini-SIM trays in dual SIM, single-standby mode. Switching can be based on quality of service or on your own scripted conditions.

Can it connect RS-485 devices?

The built-in serial port is a full RS-232 port on a 9-pin sub-D connector. The Lantronix SNAP CAP SC485 adapter, sold separately, converts it to an isolated half- or full-duplex RS-485 port.

What power input does it need?

The E214G000S accepts 8 to 32 V DC, with slow start.

Which VPN protocols are supported?

PPTP client, L2TP, OpenVPN client/server/passthrough, GRE, IPsec with up to 4 channels, and WireGuard.
