Cisco Meraki MG41 LTE Cat 18 Cellular Gateway with Dual SIM and IP67 Housing (MG41-HW)

4G LTEMPN MG41-HW
  • Dual SIM
  • 2–4 × 1 Gb Ethernet
  • PoE powered
$1,245.88$1,814.63Save $568.75

In stock · only 4 leftFree 2-day shipping

Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans
Compare all 2 configurations

Datasheets & documents

Overview

The Cisco Meraki MG41 is a cloud-managed LTE Cat 18 cellular gateway. It converts a cellular signal into an Ethernet handoff for any Meraki or non-Meraki router or firewall. It combines up to 1.2 Gbps / 150 Mbps throughput, dual nano SIM slots with automatic failover, and an IP67-rated housing that mounts on a wall, ceiling or pole. It can be powered over 802.3af PoE, so it can sit where the signal is strongest.

  • Embedded Cat 18 LTE-A Pro modem rated up to 1.2 Gbps down / 150 Mbps up
  • Four internal antennas with 4x4 DL MIMO and downlink 5CA / uplink 2CA carrier aggregation
  • Dual nano (4FF) SIM slots with automatic SIM failover and dashboard SIM switching
  • Two GbE RJ45 ports: one dedicated LAN, one convertible LAN/WAN
  • Powered by 802.3af PoE (10 W max) or 12V DC
  • IP67-rated housing with included wall, ceiling and pole bracket
  • Cloud management through the Cisco Meraki dashboard with API support
  • Add a cellular uplink to any router or firewall, Meraki or not, through a simple Ethernet handoff

The Cisco Meraki MG41 (MG41-HW) is a cellular gateway for organizations that need a dependable wireless WAN uplink, either as the primary internet connection where wired service is unavailable or as a failover path when the main circuit drops. It takes LTE from a cellular provider and hands it off over Gigabit Ethernet. It works with any routing or switching device, including Meraki MX appliances.

Inside is an embedded Cat 18 LTE-A Pro modem with four internal antennas, 4x4 downlink MIMO and up to five-carrier downlink aggregation (5CA), rated up to 1.2 Gbps down and 150 Mbps up. Two nano (4FF) SIM slots support automatic SIM failover. APN settings and SIM switching are handled from the dashboard or the local status page. The modem covers worldwide LTE bands, including Band 14 for FirstNet, Bands 66 and 71, and CBRS for private LTE. Certified carriers include AT&T, AT&T FirstNet, Verizon and T-Mobile in the US.

Because the MG41 accepts 802.3af PoE as well as 12V DC, you can mount it away from the network closet wherever cellular reception is best. The IP67 housing is rated for -30°C to 50°C and ships with an all-in-one bracket for walls, ceilings or poles. Two GbE ports, one dedicated LAN and one convertible LAN/WAN, let two MX appliances in an HA pair share the same cellular uplink.

Management runs through the Cisco Meraki dashboard. It supports zero-touch provisioning, scheduled firmware updates, remote visibility of IMEI, ICCID, APN, RSRP and RSRQ, alerts, packet capture and an extensive API. Cisco Meraki backs MG41 hardware with a full lifetime warranty and next-day advanced replacement. Enterprise licensing is available in 1-, 3-, 5-, 7- and 10-year terms.

Ideal for

  • Primary WAN for sites where wired internet is unavailable
  • Cellular failover uplink for a Meraki MX or third-party router
  • Secondary WAN for SD-WAN VPN tunnels
  • Shared cellular uplink for an MX high-availability pair
  • Outdoor or pole-mounted placement where cellular coverage is strongest

Specifications

General

MPN
MG41-HW
UPC
810979017868
Brand
Cisco Meraki
Model
MG41
Product Type
LTE cellular gateway

Cellular

MIMO
4x4 downlink MIMO
LTE Bands
B1 (2100), B2 (1900), B3 (1800), B4 (1700), B5 (850), B7 (2600), B8 (900), B12 (700ac), B13 (700c), B14 (700PS), B17 (700b), B18 (800), B19 (800), B20 (800DD), B25 (1900), B26 (US 850 Ext), B28 (700 APAC), B29 (US 700de Lower), B30 (2300 WCS), B32 (1500), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B42 (TDD 3500), B43 (TDD 3600), B46 (TDD 5200), B48 (3600), B66 (AWS-3), B71 (600)
Band 66 71
Band 66 and 71 supported
Umts Bands
B1 (2100), B2 (1900), B4 (AWS), B5 (850), B8 (900), B9 (1700), B19 (800)
LTE Category
Cat 18 LTE-Advanced Pro
CA 5ca Combos
CA_1A-3A-7C-28A, CA_1A-3C-7C, CA_1A-3C-40C, CA_2A-46A-46C-66A, CA_2A-46D-66A, CA_3A-28A-40D, CA_3C-7C-28A, CA_3A-40E
UL 2ca Combos
2UL CA: UL_1A-7A, UL_1A-8A, UL_1A-28A, UL_3A-7A, UL_3A-8A, UL_3A-20A, UL_3A-28A, UL_4A-7A, UL_3C, UL_7C, UL_38C, UL_39C, UL_40C, UL_41C, UL_42C
Certifications
PTCRB (US), RCM (ANZ, APAC), GCF (EU)
Firstnet Band 14
FirstNet Band 14 supported
Private LTE CBRS
Private LTE (CBRS) supported
Certified Carriers
AT&T, AT&T FirstNet (Capable, Certified), Verizon Wireless, T-Mobile, Optus, Telstra, Bell, Telus, Spark NZ, Vodafone NZ, DoCoMo
Bands And CA Combos
Full 2CA/3CA/4CA combination list in the MG41 datasheet
Carrier Aggregation
Downlink 5CA, uplink 2CA
Beta Tested Carriers
AT&T, Verizon, Rogers, Telus, Bell, Deutsche Telekom, Sunrise, Vodafone (NZ, UK, DE, IE), Telstra, Optus, NTT docomo, KDDI

Features

Highlights
Built-in Cat 18, dual SIM, two downstream router connections, small form factor, PoE or DC power, IP67
Management
Meraki dashboard, self-configuring, scheduled firmware upgrades, extensive API
SIM Switch
SIM switch via dashboard / local status page
Dual SIM Info
Dual SIM info
Auto SIM Failover
Auto SIM failover
Remote Diagnostics
Alerts, ping/traceroute/cable test, packet capture, searchable logs, DM logging
CA Info ON Dashboard
Carrier aggregation info on dashboard
Custom Apn Via Dashboard
Custom APN configuration via dashboard
Idle Telemetry Data Usage
6 to 8 MB per day when idle
DM Logging Local Status Page
Troubleshooting tools (DM logging) on local status page

Warranty

Hardware
Full lifetime hardware warranty with next-day advanced replacement
Accessories
1 year (mounting kits, antennas, power cords)

Licensing

Lic 1y
Meraki MG41 Enterprise License and Support, 1YR
Lic 3y
Meraki MG41 Enterprise License and Support, 3YR
Lic 5y
Meraki MG41 Enterprise License and Support, 5YR
Lic 7y
Meraki MG41 Enterprise License and Support, 7YR
Lic 10y
Meraki MG41 Enterprise License and Support, 10YR

Interfaces

SIM Type
Nano SIM (4FF)
PoE Ports
2
SIM Slots
2 SIM slots
LAN Dedicated
1x dedicated GbE RJ45
WAN Interface
1x Cat 18 cellular modem
LAN Interfaces
2x Gigabit Ethernet
LAN Convertible
1x convertible LAN/WAN GbE RJ45

Physical Specifications

Weight
670 g (without accessories)
Antennas
Four internal antennas
Humidity
5% to 95% non-condensing
Mounting
Ceiling, wall or pole with included all-in-one bracket
Dimensions
168 x 168 x 35 mm (w x d x h)
Power Load
10 W maximum (PoE 802.3af)
MTBF AT 25c
1,931,000 (at 25°C)
Power Supply
12V/1A or 48-57V DC/0.35A
Product Category
LTE Cat 18
Ingress Protection
IP67
Storage Temperature
-22°F to 158°F (-30°C to 70°C)
Operating Temperature
-22°F to 122°F (-30°C to 50°C)
Max Wireless Data Rate
1.2 Gbps down / 150 Mbps up

Questions buyers ask

Does the Meraki MG41 support 5G?

No. The MG41 uses a Cat 18 LTE-Advanced Pro modem rated up to 1.2 Gbps down and 150 Mbps up. It is an LTE gateway.

Can I use the MG41 with a non-Meraki firewall?

Yes. The MG41 provides an Ethernet handoff of the cellular connection and works with any routing or switching device, Meraki or non-Meraki.

How is the MG41 powered?

It can be powered by 802.3af PoE (10 W maximum) or a 12V/1A DC supply. This lets you run a single Ethernet cable to the location with the best signal.

Which US carriers have certified the MG41?

Cisco Meraki lists AT&T, AT&T FirstNet, Verizon Wireless and T-Mobile as certified US carriers. The modem also supports FirstNet Band 14, Bands 66 and 71, and CBRS private LTE.

How much data does the MG41 use on its own?

When idle, the MG41 uses about 6 to 8 MB per day for dashboard telemetry and connection monitoring.
