Fortinet FortiWiFi 50G-5G-II 5G Firewall with Wi-Fi 6 and 1-Year Unified Threat Protection Bundle

5GMPN FWF-50G-5G-II-A-BDL-95012
  • 1 year included
$2,758.39$3,757.80Save $999.41

Backordered · ships as soon as it arrives

Included subscription · 1 year
Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

Compare all 5 configurations

Overview

The Fortinet FortiWiFi 50G-5G-II is a desktop next-generation firewall for branch sites. It pairs FortiOS security and SD-WAN with dual-band 802.11ax Wi-Fi and an embedded Telit Cinterion 5G modem with two nano-SIM slots. This bundle (SKU FWF-50G-5G-II-A-BDL-95012, region code A) includes a 1-year (12-month) FortiCare Premium and FortiGuard Unified Threat Protection subscription. The services cover IPS, anti-malware with cloud sandbox, web and DNS filtering, anti-spam, application control and inline CASB.

  • Embedded Telit Cinterion FN990A28-HP 5G modem with dual nano-SIM (active/passive)
  • Dual-radio 2.4 GHz/5 GHz 802.11ax Wi-Fi with 2x2 MU-MIMO, up to 1201 Mbps at 5 GHz
  • Five GE RJ45 ports: 1 WAN, 3 internal, 1 FortiLink
  • Up to 5 Gbps firewall, 4.5 Gbps IPsec VPN and 1.1 Gbps threat protection throughput
  • SD-WAN and network controller included for up to 8 FortiSwitches and 16 FortiAPs
  • 1-year (12-month) FortiCare Premium and FortiGuard Unified Threat Protection subscription included
  • Brings a site online over 5G, or provides cellular failover, with two SIM slots for carrier redundancy
  • Consolidates router, firewall and Wi-Fi access point into one 2.4 lb desktop unit

The FortiWiFi 50G-5G-II combines firewalling, SD-WAN, a network controller and wireless access in a compact desktop appliance for distributed enterprise sites. It runs FortiOS on Fortinet's SD-WAN-based ASIC. Fortinet rates it at up to 5 Gbps firewall throughput, 4.5 Gbps IPsec VPN, 2.25 Gbps IPS, 1.25 Gbps NGFW and 1.1 Gbps threat protection, with logging enabled for the inspection figures. It handles 720,000 concurrent TCP sessions and 200 site-to-site IPsec tunnels.

Cellular connectivity comes from an embedded Telit Cinterion FN990A28-HP 5G modem with two nano-SIM slots (active/passive). It covers a wide range of 5G NR and LTE bands, including n41, n71, n77 and n78. Fortinet lists it as PTCRB, AT&T and Verizon certified and FirstNet capable, with T-Mobile certification targeted for Q4 2026. The unit can run a site entirely on 5G or keep traffic moving when a wired circuit goes down. On the LAN side it offers five GE RJ45 ports (one WAN, three internal, one FortiLink) and dual-radio 2x2 Wi-Fi 6 rated up to 1201 Mbps at 5 GHz. It also includes USB and RJ45 console ports, Bluetooth Low Energy and a Trusted Platform Module.

This bundle includes 12 months of FortiCare Premium and FortiGuard Unified Threat Protection. The services cover: • IPS and malicious/botnet URL blocking • Anti-malware with FortiGate Cloud Sandbox and content disarm and reconstruct • URL, DNS and video filtering • Anti-spam • Application control and inline CASB • Core FortiGuard services such as GeoIP, botnet IP and anti-phishing feeds

The appliance also manages up to 8 FortiSwitches and 16 FortiAPs, and supports active-active, active-passive and clustering high availability. The FortiGate/FortiWiFi 50G Series Data Sheet is available for full specifications.

Ideal for

  • Branch and retail sites needing a 5G primary or failover WAN with firewall and Wi-Fi in one appliance
  • Pilot deployments and proof-of-concept rollouts where a 1-year security term fits the evaluation window
  • Temporary sites, events and construction offices without wired broadband
  • Public-safety and critical-operations locations using FirstNet-capable connectivity
  • Small offices extending coverage with FortiSwitch and FortiAP under one controller

Specifications

General

MPN
FWF-50G-5G-II-A-BDL-95012
Brand
Fortinet
Model
FortiWiFi 50G-5G-II
Region Code
Region code A
Operating System
FortiOS

Modem 5G

MIMO
Yes
Wcdma
B1, B2, B4, B5 (B6, B19), B8 (EU and APAC regions only)
Regions
All Regions
Bands 5G
n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29 (SDL), n30, n38, n40, n41, n48, n66, n71, n75 (SDL), n76 (SDL), n77, n78, n79 (PC1.5 on n41, n77, n78, n79)
Diversity
Yes
GNSS Bias
Yes
LTE Bands
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29 (SDL), B30, B32 (SDL), B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71
Modem Model
Telit Cinterion FN990A28-HP (2 SIM slots, active/passive)
Max TX Power
23 dBm (PC3), 26 dBm (PC2 in B41/n41)
Gsm Gprs Edge
—
Umts Hspa Plus
B1, B2, B4, B5, B6, B8, B19
Cdma 1xrtt Evdo
—
Carrier Certifications
PTCRB, AT&T, Verizon; T-Mobile targeted Q4 2026; FirstNet capable

Dimensions

Weight
2.4 lbs (1.1 kg)
Form Factor
Desktop
Height Width Length IN
1.7 x 8.5 x 7.0 in
Height Width Length MM
42 x 216 x 178 mm

Subscription

Term
1 year (12 months)
Bundle
FortiCare Premium + FortiGuard Unified Threat Protection
Bundle Code
950
Included Services
IPS, AMP, URL/DNS/Video Filtering, Anti-Spam, Application Control, Inline CASB, FortiCare Premium and core FortiGuard services

System Performance

Max Fortiaps
16 total / 8 tunnel mode
Max Fortitokens
500
Virtual Domains
5 default / 5 maximum
Capwap Throughput
3.8 Gbps (HTTP 64K)
Firewall Policies
2,000
High Availability
Active-Active, Active-Passive, Clustering
Max Fortiswitches
8
Ssl Inspection Cps
699 (IPS, avg. HTTPS)
Ssl VPN Throughput
—
Concurrent Sessions Tcp
720,000
Firewall Throughput Pps
6 Mpps
Concurrent Ssl VPN Users
—
Ssl Inspection Throughput
1.3 Gbps (IPS, avg. HTTPS)
New Sessions Per Second Tcp
85,000
Firewall Latency 64 Byte Udp
2.42 μs
Ipsec VPN Throughput 512 Byte
4.5 Gbps
Application Control Throughput
2.8 Gbps (HTTP 64K)
Ssl Inspection Concurrent Sessions
74,000 (IPS, avg. HTTPS)
Client TO Gateway Ipsec VPN Tunnels
250
Firewall Throughput 1518 512 64 Udp
5 / 5 / 4 Gbps
Gateway TO Gateway Ipsec VPN Tunnels
200

Radio Specifications

MU MIMO
2x2 MU-MIMO
Max TX Power
21.0 dBm/chain @ 2.4 GHz, 19.5 dBm/chain @ 5 GHz
Max Wi-Fi Speeds
1201 Mbps @ 5 GHz, 574 Mbps @ 2.4 GHz

Operating Environment

Humidity
10% to 90% non-condensing
Compliance
FCC, IC, CE, UL/cUL, CB
Noise Level
21.73 dBA
Power Rating
12 VDC, 3 A
Certifications
USGv6/IPv6
Power Required
External DC power adapter, 100–240V AC, 50/60 Hz
Maximum Current
100V AC / 0.4 A, 240V AC / 0.2 A
Heat Dissipation
80.44 BTU/hr
Operating Altitude
Up to 10,000 ft (3048 m)
Storage Temperature
-31°F to 158°F (-35°C to 70°C)
Operating Temperature
32°F to 104°F (0°C to 40°C)
Power Consumption Avg Max
20.43 W / 23.59 W

Hardware Specifications

USB Ports
1x USB
GE WAN Ports
1x hardware-accelerated GE WAN
GE Rj45 Ports
3x hardware-accelerated GE RJ45
SIM Slots Nano
2x nano-SIM
Internal Storage
—
Antenna Ports Sma
3x SMA
Console Port Rj45
1x RJ45 console
Wireless Interface
Dual radio 2.4/5 GHz, 802.11 a/b/g/n/ac/ax
Bluetooth Low Energy
Yes
GE Rj45 Fortilink Ports
1x hardware-accelerated GE RJ45 FortiLink (default)
Trusted Platform Module
Yes
Signed Firmware Hardware Switch
Yes

System Performance Enterprise Traffic Mix

Ips Throughput
2.25 Gbps
Ngfw Throughput
1.25 Gbps
Threat Protection Throughput
1.1 Gbps

Questions buyers ask

What is included with FWF-50G-5G-II-A-BDL-95012?

The FortiWiFi 50G-5G-II hardware plus 12 months (1 year) of FortiCare Premium and FortiGuard Unified Threat Protection. The services include IPS, anti-malware with cloud sandbox, URL/DNS/video filtering, anti-spam, application control and inline CASB.

How does UTP differ from Enterprise Protection?

Fortinet's Enterprise Protection bundle includes everything in UTP and adds AI-based inline malware prevention, data loss prevention, attack surface security (IoT detection and virtual patching) and a FortiConverter configuration conversion service.

Which carriers is the 5G modem certified for?

Fortinet lists the Telit Cinterion FN990A28-HP modem as PTCRB, AT&T and Verizon certified and FirstNet capable. T-Mobile certification is targeted for Q4 2026.

Can it use two SIM cards?

Yes. It has two nano-SIM slots operating in active/passive mode for carrier redundancy.

What are the appliance's physical dimensions?

It is a desktop unit measuring 1.7 x 8.5 x 7.0 in (42 x 216 x 178 mm) and weighing 2.4 lbs (1.1 kg). It is powered by an external 12 VDC adapter.
