Fortinet FortiGate Rugged 70G-5G-DUAL Industrial Firewall with Dual 5G + 5-Year Enterprise Protection

5GMPN FGR-70G-5G-DUAL-BDL-80960
  • Dual SIM
  • 5+ × 1 Gb Ethernet
  • GPS/GNSS
  • Rugged
  • 5 years included
$21,542.87$29,348.25Save $7,805.38

Backordered · ships as soon as it arrives

Included subscription · 5 years
Hardware only−$12,971.631 year−$9,919.493 years−$4,730.835 years
Add a Cloud Care data plan

First month charged today · No contract · Cancel anytime

1
Request a quote · volume, multi-site or with plans
Compare all 13 configurations

Datasheets & documents

Overview

The FortiGate Rugged 70G-5G-DUAL is a fanless, DIN-rail next-generation firewall for industrial and OT networks. It carries two embedded 5G modems with active/active SIMs, passive GPS, 6 GE RJ45 ports, 2 SFP slots and a bypass port pair, runs from redundant 12V to 125V DC inputs, and operates from -40°C to 75°C. This bundle (FGR-70G-5G-DUAL-BDL-80960) includes a 5-year FortiCare Premium and FortiGuard Enterprise Protection subscription.

  • Fanless, IP40, DIN-rail appliance rated for -40°C to 75°C operation
  • Two embedded 5G modems (Telit Cinterion FN990A28-HP) with 2 active/active SIM slots, 8 external SMA WWAN antennas and passive GPS
  • 6 GE RJ45 ports, PORT1-2 bypass pair, 2 SFP slots, RJ45 serial and console, USB-A 2.0, MicroSD and digital I/O
  • FortiSP5 processor: up to 8 Gbps firewall, 7.1 Gbps IPsec VPN, 2.5 Gbps IPS and 1.3 Gbps threat protection
  • Redundant 12V to 125V DC power inputs with 25 W average consumption
  • Certified to IEC 61850-3, IEEE 1613, EN 50155 and IEC 60945 with DNV Type Approval
  • 5-year FortiCare Premium and FortiGuard Enterprise Protection subscription included
  • Keep industrial sites online with two independent 5G modems and active/active SIMs for carrier diversity

The Fortinet FortiGate Rugged 70G-5G-DUAL is an industrially rugged next-generation firewall built for operational technology sites, substations, rail, maritime and remote field locations where office-grade appliances do not survive. The fanless, IP40, DIN-rail enclosure operates from -40°F to 167°F (-40°C to 75°C), and the unit is certified to IEC 61850-3 and IEEE 1613 for the electric power industry, EN 50155 for rolling stock, and IEC 60945 with DNV Type Approval for maritime use.

Connectivity is built around two embedded Telit Cinterion FN990A28-HP 5G modems with two SIM slots running active/active, eight external SMA WWAN antennas and passive GPS with its own SMA antenna. The modems cover a broad 5G NR and LTE band set, carry PTCRB, AT&T, T-Mobile and Verizon certification, and support AT&T FirstNet (5G), T-Mobile T-Priority and Verizon Frontline public safety networks. Wired interfaces include 6 GE RJ45 ports (4 LAN, 2 WAN), a PORT1-2 bypass pair, 2 SFP slots, RJ45 serial and console ports, USB-A 2.0, a MicroSD slot and a digital I/O module.

The FortiSP5 secure processor delivers up to 8 Gbps IPv4 firewall throughput, 7.1 Gbps IPsec VPN, 2.5 Gbps IPS, 1.5 Gbps NGFW and 1.3 Gbps threat protection, with built-in Secure SD-WAN and Active-Active, Active-Passive or clustering high availability.

This bundle adds 60 months of FortiCare Premium and FortiGuard Enterprise Protection, covering IPS, anti-malware with FortiGate Cloud Sandbox, URL, DNS and video filtering, application control, inline CASB, data loss prevention, anti-spam, AI-based inline malware prevention and IoT attack surface security. The five-year term suits long-lifecycle industrial deployments. The FortiGate Rugged Series Data Sheet and the 70G-5G-DUAL QuickStart Guide are available as documentation.

Ideal for

  • Electric utility substations requiring IEC 61850-3 and IEEE 1613 certified security
  • Rolling stock and rail wayside networks needing EN 50155 compliance and dual 5G backhaul
  • Maritime and offshore vessels with DNV Type Approval requirements
  • Long-lifecycle remote OT sites such as pipelines, water treatment and oil and gas pads
  • Public safety and first responder deployments on FirstNet, T-Priority or Frontline

Specifications

General

MPN
FGR-70G-5G-DUAL-BDL-80960
Brand
Fortinet
Model
FGR-70G-5G-DUAL
Bundle
FortiCare Premium + FortiGuard Enterprise Protection (EP)
Bundle Code
809
Product Name
FortiGate Rugged 70G-5G-DUAL
Product Type
Rugged next-generation firewall (NGFW)
Subscription Term
5 years (60 months)

Package

DC Cables
DC cables not included
GPS Antenna
1x external SMA GPS antenna
Documentation
FortiGate Rugged Series Data Sheet; FortiGate Rugged 70G-5G-DUAL QuickStart Guide
Wwan Antennas
8x external SMA WWAN antennas

Overview

Atp
1.3 Gbps
Ips
2.5 Gbps
Ngfw
1.5 Gbps

Cellular Wireless

MIMO
Yes
Wcdma
B1, B2, B4, B5 (B6, B19), B8 (for EU and APAC regions only)
Regions
All Regions
5G Bands
n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29 (SDL), n30, n38, n40, n41, n48, n66, n71, n75 (SDL), n76 (SDL), n77, n78, n79 (PC1.5 support on n41, n77, n78, n79 bands)
Diversity
Yes
GNSS Bias
Yes
LTE Bands
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29 (SDL), B30, B32 (SDL), B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71
SIM Slots
2 SIM slots, Active/Active
Modem Model
Telit Cinterion FN990A28-HP (2 SIM Slots, Active/Active)
Gsm Gprs Edge
Not supported
Umts Hspa Plus
B1, B2, B4, B5, B6, B8, B19
Cdma 1xrtt Evdo
Not supported
Maximum TX Power
23 dBm (Power Class 3), 26 dBm (Power Class 2 in B41/n41)

Security Services

Base Services
Device/OS Detection, GeoIPs, Trusted CA Certificates, Internet Services and Botnet IPs, DDNS (v4/v6), Local Protection, PSIRT Check, Anti-Phishing
Included Services
IPS (Malicious/Botnet URLs); Anti-Malware Protection (AV, Botnet Domains, Mobile Malware, Virus Outbreak Protection, Content Disarm and Reconstruct, AI-based Heuristic AV, FortiGate Cloud Sandbox); URL, DNS and Video Filtering (Malicious Certificate); Anti-Spam; AI-based Inline Malware Prevention; Data Loss Prevention; Attack Surface Security (IoT Device Detection, IoT Vulnerability Correlation and Virtual Patching, Security Rating, Outbreak Check); Application Control; Inline CASB; FortiConverter Service for One Time Configuration Conversion; FortiCare Premium

Industry Compliance

RF
EN 301 908-1 V15.2.1 (2023-01); EN 301 908-2 V13.1.1 (2020-06); EN 301 908-13 V13.2.1 (2022-02); Draft EN 301 908-25 V15.1.1; EN 300 328 V2.2.2 (2019-07); EN 303 413 V1.2.1 (2021-04); EN 18031-1:2024; EN IEC 62311:2020; EN 50665:2017; FCC Part 15 Subpart C 15.247; FCC 47 CFR Part 2.1091; ISED RSS-247 Issue 3; RSS-102 Issue 6
Emc
EN 55032:2015 + A1:2020, Class A; EN 55035:2017 + A11:2020; ETSI EN 301 489-1 V2.2.3 (2019-11); ETSI EN 301 489-17 V3.2.4 (2020-09); ETSI EN 301 489-19 V2.1.1 (2019-04); ETSI EN 301 489-52 V1.2.1 (2021-11)
Rohs
EN IEC 63000:2018; EN 50581:2012
Health And Safety
IEC 62368-1:2014, 2nd Ed.; EN 62368-1:2014; IEC 62368-1:2018, 3rd Ed.; EN IEC 62368-1:2020
Maritime Industry
IEC 60945, 4th Edition (2002); IACS UR E10, Edition 10; DNV Type Approval
Regulatory Compliance
FCC Part 15 Class A, RCM, VCCI Class A, CE, UL/cUL, CB; USGv6/IPv6
Rolling Stock Industry
EN 50155:2021; EN 50121-1:2017; EN 50121-3-2:2016 + A1:2019; EN 50121-4:2016 + A1:2019; EMC, Environmental, Shock and Vibration Certified
Electric Power Industry
IEC 61850-3 and IEEE 1613 Certified

Dimensions And Power

Weight
4.63 lbs (2.1 kg)
IP Rating
IP40
Form Factor
DIN-rail
Antenna Size
205 mm x 25 mm (H x W)
Power Supply
12V to 125V DC redundant dual inputs, 2 pins per terminal block, negative or positive ground, DC cables not included
Dimensions IN
5.47 x 4.1 x 4.8 in (H x W x L)
Dimensions MM
139 x 104 x 122 mm (H x W x L)
Maximum Current
12V DC / 3A
Heat Dissipation
89 BTU/h
Power Consumption
25 W / 26.2 W (average/maximum)

Modem Certifications

Module Certifications
FCC, IC, RED, NCC, JATE/TELEC, KC, NCC+, RCM, GCF, PTCRB, AT&T, FirstNet, KDDI, KT, Telstra, T-Mobile US, Verizon

Operating Environment

Humidity
5% to 95% non-condensing
Operating Altitude
Up to 10,000 ft (3048 m)
Storage Temperature
-40°F to 185°F (-40°C to 85°C)
Operating Temperature
-40°F to 167°F (-40°C to 75°C)

Carrier Certifications

Att
Yes
Ptcrb
Yes
Verizon
Yes
T Mobile
Yes

Enterprise Traffic Mix

Ips Throughput
2.5 Gbps
Ngfw Throughput
1.5 Gbps
Threat Protection Throughput
1.3 Gbps

Interfaces And Modules

Processor
FortiSP5
Console Port
1 RJ45
Cellular Modem
Dual 5G, GPS
Serial Interface
1 RJ45
Digital I/O Module
Yes
Microsd Card Slot
Yes
USB Client Server
1 USB-A 2.0
Bypass GE Port Pair
PORT1-2 RJ45
Bluetooth Low Energy
Yes
GE LAN WAN Interfaces
6 RJ45 (4x LAN, 2x WAN)
Transceivers Included
None
Dedicated GE SFP Slots
2
Trusted Platform Module
Yes

Public Safety Networks

Att Firstnet
FirstNet Capable (5G)
Verizon Frontline
Yes
T Mobile T Priority
Yes

System Performance And Capacity

Max Fortiaps
96 / 48 (total/tunnel)
Max Fortitokens
500
Virtual Domains
10 / 10 (default/maximum)
Firewall Latency
5.82 μs (64 byte, UDP)
Firewall Policies
5,000
High Availability
Active-Active, Active-Passive, Clustering
Max Fortiswitches
24
Ssl Inspection Cps
715 (IPS, avg. HTTPS)
Ssl VPN Throughput
—
Ipsec VPN Throughput
7.1 Gbps (512 byte)
Concurrent Sessions Tcp
1.4 M
Firewall Throughput Pps
12 Mpps
Concurrent Ssl VPN Users
—
Ipv4 Firewall Throughput
8/8/8 Gbps (1518/512/64 byte UDP)
Ssl Inspection Throughput
1.4 Gbps (IPS, avg. HTTPS)
New Sessions Per Second Tcp
85,000
Application Control Throughput
3.6 Gbps (HTTP 64K)
Client TO Gateway Ipsec Tunnels
500
Gateway TO Gateway Ipsec Tunnels
200
Ssl Inspection Concurrent Sessions
1.4 M (IPS, avg. HTTPS)

Questions buyers ask

What is included in this bundle?

The FortiGate Rugged 70G-5G-DUAL hardware with 8 external SMA WWAN antennas and 1 external SMA GPS antenna, plus a 5-year (60-month) FortiCare Premium and FortiGuard Enterprise Protection subscription. DC power cables are not included.

Can both 5G modems be used at the same time?

Yes. The unit has two embedded Telit Cinterion FN990A28-HP 5G modems with two SIM slots operating active/active, so two carrier links can run simultaneously for redundancy or SD-WAN load sharing.

What power does it need?

It accepts 12V to 125V DC on redundant dual terminal-block inputs, with negative or positive ground. Average consumption is 25 W and maximum is 26.2 W.

Which carriers and public safety networks does it support?

The cellular module is PTCRB, AT&T, T-Mobile and Verizon certified, and it supports AT&T FirstNet (5G), T-Mobile T-Priority and Verizon Frontline.

Does it support SSL VPN?

Fortinet notes that SSL VPN is not supported starting with FortiOS v7.6.0 and recommends the FortiOS v7.2.x LTS release where that feature is required. IPsec VPN supports up to 200 gateway-to-gateway and 500 client-to-gateway tunnels.
